MS6531
SERIES
INFRARED THERMOMETER
User's Manual
5. Distance to Spot Ratio
The distance to spot ratio (D:S) for this meter is: 12:1.
Example: Measurement from a distance of 300mm away
will produce a measurement spot of approx. 25mm in
diameter. Figure 1 shows a diagram of how distance to
spot ratio works.
6. Technical Specifications
MS6531ABC
MS6531A
IR: -60~500°C/-76~932°F
MS6531B/C IR: -40~800°C/-40~1472°F
MS6531A/C TK: -40~1080°C/-40~1976°F
IR: -60~0°C/-76~32°F: ±4°C/7.2°F
IR: 0~400°C/32~752°F: ±1.5%, ±2°C/3.6°F
Accuracy
IR: 400~800°C/752~1472°F: ±2%, ±2°C/3.6°F
TK: -40~1080°C/-40~1976°F: ±1.5%, ±3°C/5.4°F
12:1
02
7. Buttons and Components
9. Operating Instructions
9.1 Measurement
1. Point the meter at the object to be measured.
2. Hold down the trigger to begin measurement.
The "
"symbol flashes on the top of the display
1. Laser Sight
to indicate measurement is taking place.
3. The main measurement display show the current
2. Infrared Sensor
temperature reading of the measured surface.
3. Measurement Trigger
4. Release the trigger and "HOLD"symbol will appear in the
4. Battery Cover
upper left corner and the display will hold the last reading.
5. Type-K Thermocouple Jack
5. The meter's auto off function will turn off the meter
6. Mode Button
30s after releasing the trigger.
7. Laser/Backlight Button
Note:
8. Temp. Unit Button
- Environmental temperature can affect the accuracy of
9. LCD Display
the reading. It is recommended the meter be place in the
measurement environment for 30 min.
prior to taking measurement.
8. Display Description
- Laser can be turned off for measurements at close
1. Display Hold
range to conserve battery power.
2. Main Measurement Display
3. Mode
9.2 Settings
4. Secondary Measurement Display
Emissivity: default emissivity is 0.95
5. Fahrenheit
6. Celsius
To change emissivity: press "MODE" until the bottom left
shows the "E" symbol with two arrows pointing up and down.
7. Low Battery
Press the up and down buttons to adjust the emissivity.
8. Low Alarm Indication
Emissivity range: 0.1-1.0.
9. High Alarm indication
10. Buzzer Indication
Memory:
11. Measurement Indication
To save readings: press "MODE" unit "MEM" appears in the
bottom left corner of the display. Press the trigger to save
12. Measurement Lock
the displayed reading.
13. Laser Pointers On/Off
04
05
