- Page 1 RocketStor 6314A ™ Thunderbolt 2 Hardware RAID 4-Bay Storage Enclosure Quick Installation Guide V1.01...
-
Page 2: Table Of Contents
Table of Contents ..................2 HighPoint RocketStor 6314A ..............3 Kit Contents .................... 4 RocketStor 6314A Hardware ..............4 Setup Enclosure..................6 Setup the RocketStor 6314A under Mac ..........9 Setup RocketStor 6314A under Windows ..........11 Customer Support ................. 13... -
Page 3: Highpoint Rocketstor 6314A
HighPoint RocketStor 6314A 6314A Thunderbolt™ Storage Solution delivers HighPoint's RocketStor up to 32 terabytes of high-performance, hardware RAID storage from a single cable connection! The fully integrated hardware RAID controller and removable disk modules were designed for today's fastest 6Gb/s storage devices - perfect for professional, I/O intensive applications such as digital content creation and media post production. -
Page 4: Kit Contents
Thunderbolt™ cable x 1 Power Cord x 1 RocketStor 6314A Hardware Panel Layout-Front View Device Present & Active LED: Solid/Flash Blue - HDD Access Indicator Device Status LED: Solid/Flash Red - Device Failure / Rebuilding Indicator Enclosure Power LED: Solid Blue - Power on Indicator... - Page 5 Panel Layout-Rear View Thunderbolt connectors: Connecting Thunderbolt cables AC Power IN receptacle: Connecting AC power cord. Power switch: Enclosure power switch.
-
Page 6: Setup Enclosure
Setup Enclosure Place the RocketStor 6314A on a level surface and remove each disk tray. Carefully insert the 3.5” or 2.5” disk into each disk tray and secure them with the provided mounting screws. For 3.5” disk: Use the 3.5” screw (black color) to mount the disk to... - Page 7 For 2.5” disk: Use the 2.5” screw (silver color) to mount the disk to the disk tray on the bottom Connect the RocketStor 6314A to the host system with the Thunderbolt cable, and then connect the RocketStor 6314A with a power source.
- Page 8 RocketStor 6314A). RocketStor 6314A is designed to be powered on and powered off simultaneously with the HOST system, when the RocketStor 6314A is connected to the HOST system with the Thunderbolt cable. Therefore, power on HOST first – the RocketStor 6314A will...
-
Page 9: Setup The Rocketstor 6314A Under Mac
Setup the RocketStor 6314A under Mac Verify the RocketStor 6314A’s RAID Controller driver. Following step 1, check to make sure the “Driver Installed” status for the is “Yes”. If you are using OS X RocketRAID 4520 SAS Controller 10.9.x (Mavericks), the driver is natively supported by the OS. If you are using OS X 10.8.x (Mountain Lion) or earlier, you will... - Page 10 Use the default user name: RAID and password: hpt to login. To learn how to use the WebGUI, please visit: http://www.highpoint-tech.com/help/en/r_content.html#logical1 After the new RAID volume has been configured, OS X will display a pop-up window.
-
Page 11: Setup Rocketstor 6314A Under Windows
Computer. Right-click the RAID volume and then select Eject to safely eject the RAID volume from the computer. Setup RocketStor 6314A under Windows Driver Installation: Windows Boot up the Windows operating system. Make sure the host system’s Thunderbolt™ driver has been installed. - Page 12 Download the Windows driver package from HighPoint website. Extract the package and click the setup.exe program to install the driver. The installation program will install the RS6314A driver, automatically. After rebooting the system, the RocketRAID 4520 will be recognized by Device Manager, and listed under “Storage Controllers”.
-
Page 13: Customer Support
Customer Support If you encounter any problems while utilizing the HighPoint RocketStor 6314A, or have any questions about this or any other HighPoint Technologies, Inc. product, feel free to contact our Customer Support Department. Web Support: http://www.highpoint-tech.com/websupport/...
