Quick Installation Guide
GS-7324| 24-Port Gigabit Ethernet Switch + 2 SFP
A
Understanding your Switch
This switch contains LEDs to show the activities and status of the ports, including the POWER LED and LINK/ACT LEDs.
Please refer to the front panel of the switch for the positions of the LEDs :
Look at the following table for the description of the LEDs:
POWER
LINK/ACT
1-24
Rear Panel
LED
Status
Steady Green
Off
Steady Green
Blinking
Off
Steady Green
SFP
Blinking
Off
Operation
The switch is powered on
The switch is powered off
1000Mbps connected
Data transmitting
Port disconnected or link fail
Port Connected
Data transmitting
Port disconnected or link fail
