InvisaPC DTX1002-R
Quick Install Guide
Follow these instructions to install your InvisaPC DTX1002-R
Figure A
Figure A illustrates the front and back panel of the unit. Table A describes its components.
Table A
Number
1
2
3
4
5
6
7
8
9
Contact
Information
A4
1
6
Component
Description
Powers on and off unit. LED indicates power status.
On/Off Button
USB Connector
Connects to USB Peripheral
USB Connector
Connects to USB Peripheral
Microphone
Connect to audio microphone
Audio Line Out
Connect to speakers
5V DC Power in
Connect to supplied power adaptor
Dual USB Connector
RJ-45 Port
DVI Video
Connect to Monitor
Order toll-free in the U.S. or for FREE 24/7 Technical Support: Call 877-877-BBOX
(outside U.S. call 724-746-5500) www.blackbox.com • info@blackbox.com
BLACK BOX
2
7
Connect to USB peripherals
Connect to LAN
4
3
®
8
DTX1002-R
5
9
600-0007-003A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Black Box InvisaPC DTX1002-R
Summary of Contents for Black Box InvisaPC DTX1002-R
-
Page 1: Black Box
DTX1002-R InvisaPC DTX1002-R Quick Install Guide Follow these instructions to install your InvisaPC DTX1002-R BLACK BOX ® Figure A Figure A illustrates the front and back panel of the unit. Table A describes its components. Table A Number Component Description Powers on and off unit. -
Page 2: Connecting Power
Connecting Power Locate the power supply adaptor and AC line cord. Plug the DC connector of the power supply into the matching socket on the rear of the appliance. Attach the AC line cord to the power supply adaptor. Connecting the Peripherals Attach the monitor, keyboard, mouse, USB and audio devices to the DTX1002-R.
