- Page 1 Instruction Manual PopMaxx with Lighted Sign Model No. 2552-00-001 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2017 Gold Medal Products Co. Part No. 110131...
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 2552-00-001: 12 oz. PopMax Popper with an LED lighted sign, and equipped with a PowerOff Control feature. - Page 5 PopMaxx with Lighted Sign Model No. 2552-00-001 Setup This unit has been tested at the factory. 1. Remove all packaging and tape prior to operation. 2. Place the unit on a sturdy, level base. 3. The Popper blower vents out the top of unit, allow adequate clearance for airflow.
-
Page 6: Electrical Requirements
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable). 5. Install the unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614 gmpopcorn.com... -
Page 7: Controls And Their Functions
PopMaxx with Lighted Sign Model No. 2552-00-001 OPERATING INSTRUCTIONS Controls and Their Functions KETTLE HEAT SWITCH Two position, ON/OFF lighted rocker switch - supplies power to the heating elements in the popping kettle. The green switch light ON indicates there is power to the kettle heating element. -
Page 8: Amount Of Popcorn And Oil
PopMaxx with Lighted Sign Model No. 2552-00-001 Popping Corn This section describes instructions for popping Standard (salted popcorn). Amount of Popcorn and Oil Your new popper is equipped with a corn, salt, and oil measure. We recommend flavored and colored coconut oil. Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in your kettle like other oils. -
Page 9: Care And Cleaning
2. Every night, mix Gold Medal’s Heat’n Kleen solution (Item No. 2095), 2 tablespoons per gallon of water. It is not necessary to use the entire gallon at once; only use enough to fill the kettle 1/2 inch deep. -
Page 10: Filter Cleaning Instructions
DO NOT use oven cleaners or abrasive materials as they will damage parts of the machine. 5. Clean the glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended. Ammonia cleaners will damage the plastic doors. Use only non-ammonia cleaners, such as Gold Medal Watchdog Glass Cleaner (Item No. -
Page 11: Troubleshooting
PopMaxx with Lighted Sign Model No. 2552-00-001 Troubleshooting Issue Possible Cause Solution No Power to the Unit A. No Power to the Unit A. Make sure the unit’s power cord is plugged in. Kettle Does Not Heat A. Power to the Kettle A. - Page 12 PopMaxx with Lighted Sign Model No. 2552-00-001 Agitator Set Collar Adjustment The following instructions describe how to properly adjust set collars on an agitator assembly with a floating stir rod. Steps to Adjust Set Collars Gear Block Needle Bearing Step 1: Turn machine OFF, unplug unit, and...
-
Page 13: Maintenance Instructions
PopMaxx with Lighted Sign Model No. 2552-00-001 MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. -
Page 14: Ordering Spare Parts
PopMaxx with Lighted Sign Model No. 2552-00-001 ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. (General images may be used in manual for reference only.) 2. Use only approved replacement parts when servicing this unit. -
Page 15: Replacing Broken Glass
Model No. 2552-00-001 Replacing Broken Glass Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be obtained from a local glass shop, always purchase tempered glass. GLASS DIMENSIONS (Height x Width x Thickness) Front and Side Glass: 21 1/4”... - Page 16 PopMaxx with Lighted Sign Model No. 2552-00-001 12/14 oz. Kettle Assembly (58014) – Agitator Assembly View Overall Ket tle 61 05 4E X Crossbar Assem bly 56 00 0 *See Parts List note. 16, 14 See Kettle Bottom Assembly. Complete Kettle Assembly...
- Page 17 PopMaxx with Lighted Sign Model No. 2552-00-001 12/14 oz. Kettle Assembly (58014) – Kettle Bottom View 582 20 Ke tt le Bot tom Assem bly 582 20 Elem e nt V ie w Kettle Bottom Assembly Element View Top Lock Nut - Fastens each thermostat and ground.
- Page 18 PopMaxx with Lighted Sign Model No. 2552-00-001 Cabinet Exterior – Front View See Lighted Sign Section For Glass Panels, See Kettle see Replacing Assembly Glass section. Section 5, 6 Model 2552-00-001 Item Part Description Part No. 8-32 X 3/8 SLT. HWH M/S...
- Page 19 Safety Labels Section 10, 11 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or General image shown similarly qualified persons in order to avoid a hazard. for parts reference only.
- Page 20 PopMaxx with Lighted Sign Model No. 2552-00-001 Door Hardware Kits – Individual Component Breakdown Complete Right Hand Door Complete Left Hand Door Hardware Kit (P/N 47055) Hardware Kit (P/N 47054) (contains all parts shown above) (contains all parts shown above)
- Page 21 PopMaxx with Lighted Sign Model No. 2552-00-001 Cabinet Interior – Controls View 2387- 00- 010 13*, 14 Data Plate General image shown for parts reference only. For Labels, see Safety Labels section. Item Part Description Part No. SMALL SWITCH BOX...
- Page 22 Model No. 2552-00-001 Cabinet Bottom – Corn Pan Element View 2552 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. See Labels 6, 7 General image shown for parts reference only.
-
Page 23: Motor Plate Assembly
PopMaxx with Lighted Sign Model No. 2552-00-001 Motor Plate Assembly 255 2- 00 -0 10 Im ag e Sh own. Male Cordset shown (see Lighted Sign Assy. for Female Cordset) 11, 12 See Controls View General image shown for parts reference. - Page 24 PopMaxx with Lighted Sign Model No. 2552-00-001 Lighted Sign Assembly Light Box Assembly (111421) – Front View 10 11 12, 13 Male Cordset (not shown) is included in Light Box Assembly, see Motor Plate Assy. Power Supply mounts on section for image motor plate, see Motor reference.
-
Page 25: Safety Labels
PopMaxx with Lighted Sign Model No. 2552-00-001 Safety Labels Kettle Lead In Label Unit Labels Power Cord Labels Item Part Description Part No. UNIVERAL POPPER DECAL 41019 MAIN GROUND LABEL 42375 SURFACE CONTACT WARNING 87087 POWER OFF LABEL 55436 CONDUIT WARNING LABEL... -
Page 26: Wiring Diagram
PopMaxx with Lighted Sign Model No. 2552-00-001 Wiring Diagram Model 2552-00-001 gmpopcorn.com Page 26... - Page 27 © 2017 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
