Related Manuals for Gold Medal PopMaxx 2552
Summary of Contents for Gold Medal PopMaxx 2552
- Page 1 Instruction Manual PopMaxx 12/14 oz. Popper Model No. 2552, 2552KC 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2016 Gold Medal Products Co. Part No. 49749...
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. (Gold Medal Products Co. does not assume any liability for injury due to careless handling and/or reckless operation of this equipment.) gmpopcorn.com...
-
Page 4: Installation Instructions
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). - Page 5 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Setup This unit has been tested at the factory. 1. Remove all packaging and tape prior to operation. Remove accessories and carefully remove kettle packed in cabinet interior. 2. Place unit on a sturdy, level base. 3.
-
Page 6: Electrical Requirements
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable). 5. Install unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614 gmpopcorn.com... -
Page 7: Controls And Their Functions
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC OPERATING INSTRUCTIONS Controls and Their Functions KETTLE HEAT SWITCH Two position, ON/OFF lighted rocker switch - supplies power to the heating elements in the popping kettle. The green switch light ON indicates there is power to the kettle heating element. -
Page 8: Popping Corn Instructions
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Popping Corn Instructions This section describes instructions for popping Standard (salted) popcorn, and for popping Pappy’s Kettle Corn. Amount of Popcorn and Oil The popper is equipped with a corn, salt, and oil measure. We recommend flavored and colored coconut oil. - Page 9 Diamond Crystal Popcorn Salt (Item No. 2070CT, 12 oz. container). DO NOT use popcorn seasoning salt when popping Pappy’s Kettle Corn. Gold Medal recommends white coconut oil for popping Pappy’s Kettle Corn (colored oil can change the popcorn color). Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in the kettle like other oils.
-
Page 10: Care And Cleaning
2. Every night, mix Gold Medal’s Heat’n Kleen solution (Item No. 2095), 2 tablespoons per gallon of water. It is not necessary to use the entire gallon at once; only use enough to fill the kettle 1/2 inch deep. -
Page 11: Filter Cleaning Instructions
Gold Medal Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive materials as they will damage parts of machine. 5. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended. -
Page 12: Troubleshooting
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Troubleshooting Issue Possible Cause Solution Power to the Unit A. Power to the Unit A. Make sure the unit’s power cord is plugged in. Kettle Does Not Heat A. Power to the Kettle A. - Page 13 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Agitator Set Collar Adjustment The following instructions describe how to properly adjust set collars on an agitator assembly with a floating stir rod. Steps to Adjust Set Collars Step 1: Make sure machine is OFF and unplugged, then allow unit to cool completely Agitator’s Spur Gear before attempting to adjust the agitator height.
-
Page 14: Maintenance Instructions
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. -
Page 15: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to: Parts Department Gold Medal Products Co. 10700 Medallion Drive Cincinnati, Ohio 45241-4807 Or, place orders by phone or online:... -
Page 16: Replacing Broken Glass
Model No. 2552 and 2552KC Replacing Broken Glass Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be obtained from a local glass shop, always purchase tempered glass. GLASS DIMENSIONS (Height x Width x Thickness) Front and Side Glass: 21 1/4”... - Page 17 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC 12/14 oz. Kettle Assembly (58014, 58014KC) – Agitator Assy. View Overall Ket tle 61 05 4E X Crossbar Assem bly 56 00 0 *See Parts List note. 16, 14 See Kettle Bottom Assembly.
- Page 18 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC 12/14 oz. Kettle Assembly (58014, 58014KC) – Kettle Bottom View Kettl e Bot tom Assem bly 5 82 20 Elem en t V iew 58 22 0 Kettle Bottom Assembly Element View Top Lock Nut - Fastens each thermostat and...
- Page 19 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Cabinet Exterior – Front View 2552- 00- 001 For Glass Panels, See Kettle see Replacing Assembly Glass section. Section 6, 7 General image shown for parts reference only. Part Number Item Part Description 2552 2552KC...
- Page 20 Safety Labels Section 10, 11 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly General image shown qualified persons in order to avoid a hazard. for parts reference only.
- Page 21 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Door Hardware Kits – Individual Component Breakdown Complete Right Hand Door Complete Left Hand Door Hardware Kit (P/N 47055) Hardware Kit (P/N 47054) (contains all parts shown above) (contains all parts shown above) Part Number Item Part Description...
- Page 22 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Cabinet Interior – Controls View 2387- 00- 010 11*, 12 Data Plate *See Parts List Note. General image shown for parts reference only. For Labels, see Safety Labels section. Item Part Description Part No.
- Page 23 Model No. 2552 and 2552KC Cabinet Bottom – Corn Pan Element View 2552 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. See Labels 6, 7 General image shown for parts reference only.
-
Page 24: Motor Plate Assembly
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Motor Plate Assembly 255 2 Im ag e See Labels See Controls View General image used for parts reference only. Item Part Description Part No. LIGHT SHIELD CONICAL 40589 LAMP HOLDER 47047 BLOWER PLUG AND CORD 47199... - Page 25 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Safety Labels Unit Labels Kettle Lead In Label Power Cord Labels Item Part Description Part No. UNIVERAL POPPER DECAL 41019 MAIN GROUND LABEL 42375 SURFACE CONTACT WARNING 87087 CONDUIT WARNING LABEL 82840 CORD WARNING LABEL 68720...
- Page 26 PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Accessories Part Number Item Part Description 2552 2552KC STAMPED ALUMINUM SCOOP 2071 2071 14.7 CC MEASURE 47679 47679 1/2 CUP MEASURE 47149 47149 12 OZ CORN MEASURE 47148 47148 SALT SHAKER 63016 TIMER, LCD RESETABLE 63012...
-
Page 27: Wiring Diagram
PopMaxx 12/14 oz. Popper Model No. 2552 and 2552KC Wiring Diagram Model 2552, 2552KC gmpopcorn.com Page 27... - Page 28 © 2016 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
