Soyal AR-821EF User Manual

SOYAL
AR-821EF
Contents
AR-821EF User Guide
Installation
Steps
1.Using a screwdriver to screw the mounting plate to the wall.
2.Pull cable ends through the access hole in the mounting plate.
3.Attach AR-821EF to the mounting plate and install screws (supplied) into the
holes on the bottom with the alley key (supplied).
4.Apply power. LED (green) will light up with one beep.
Notices
Tubing – the communication wires and power line should not be housed in
Cable selection – use AWG 22-24 "Shielded Twisted Pair" to avoid star wiring.
Power supply – do not connect the reader and lock to the same power supply.
Connectors Description
Gear
Wire
1
2
CN1 CN2
P1 P2
3
4
5
6
7
8
Front
Wire
P4
1
2
3
4
P3
5
6
7
Terminal Cables Allen Key and Screws
the same electrical conduit or tubing. They should always be installed
in separate tubes.
Lock activation may cause reader power instability and might
affect the reader function. The standard connection of power
supply is the door relay and the lock use the same power supply;
the reader user independent power supply.
Wire
1
2
Wire
1
2
3
SOYAL
Front Panel & Indicator
Menu Tree
Command List
Wiring Diagram
Strike Lock
Magnet Lock
(or Bolt Lock)
Lock Power
N.C.
Magnetic Door Contacts
N.O.
Push Button
Power
1. System will automatically exit from Programming Mode when
inactivates for 30 seconds.
2. LED status indicates controller's mode and status.
Busy (red) – blinking constantly when operates in Programming Mode
– or flashing an existed card in card learn mode,
it comes 2 beeps warning and LCD panel displays
"Same Card: user address / card number"
Error (red) – invalid card with 2 beeps warning and LCD panel displays
"Card Number Err!"
– or in anti-pass-back mode, when violates the access,
it comes one beep warning and LCD panel displays
"Anti-pass Error!"
Arming (green) – arming on status
Alarm (red) – any abnormal condition occurs
3. Keypad will be locked up when constantly entering incorrect
pin code or master code.
4. Maximum error times of pin code and master code can be
changed via the software 701Server (default: 3 times)
WG1WG0 BZ LED LED
V- V+
GR RED
V-
V-
A+
RS232/RS-485
B-
or USB/RS-485
RS-232
V-
Converter
V+
v071224
12V
CTL
COM
N.O
N.C
