Soyal AR-821EF User Manual

SOYAL
ACCESS CONTROL SYSTEM

Contents

AR-821EF [Fingerprint]
1 Products
or
DO
AR-821EV [Finger Vein]
1 Products

Installation

A.

Notice

1. Tubing: The communication wires and power line should not be housed in the same electrical conduit or tubing.
They should always be installed in separate tubes.
2. Cable selection: Use AWG 22-24 "Shielded Twisted Pair" to avoid star wiring.
3. Power supply: Do not connect the reader and lock to the same power suppy. While the lock activates, it will cause the reader's power to be unstable
and affect the readers operation. The standard connection of power supply is to have the door relay and the lock use one supply;
the reader uses an independent supply.

Connector Table

P1 P2
P4
P3
Front Panel & Indicator
Power
(Green)
Busy
(Red)
Alarm
(Red)
®
AR-821EF / AR-821EV
2 User Guide
MT
2 User Guide
B.
1
2
P1.
Wire Color
Wire Application
Door Relay 1 Blue White
2 Purple White
Common-COM-Point 3 White
Door Sensor 4 Orange
Exit Switch 5 Purple
Alarm Relay 6 Gray
Power 7 Thick Red
8
Thick Black
P3.
Wire Application Wire Color
Tamper Switch 1 Red
2 Orange
3 Yellow
Card Present/ Arming
OK
(Green)
Error
(Red)
Fingerprint or Finger-Vein
Scan Area
3 Terminal Cables
P1
3 Terminal Cables
P1
Use a screwdriver to screw the mounting plate to the wall.
Pull cables ends through the access hole in the mounting plate.
Attach AR-821EF or AR-821EV to the mounting plate and install screws (supplied) into the
holes at the bottom with the allen key (supplied).
Apply power. LED (green) will light up with one beep.
P2.
Description
Wire Application
(N.O.)DC24V1Amp
Networking
(N.C.)DC24V1Amp
(COM)DC24V1Amp
Wiegand
Negative Trigger Input
Negative Trigger Input
N.O./N.C. Optional
(by jumper)
Buzzer
DC 12V
LED
DC 0V
P4.
Description
Wire Application
N.C.
Serial Port
COM
N.O.
(Green)
4 Allen Key and Screws
P2 P3 P4
4 Allen Key and Screws
P2 P3 P4
Wire Color Description
1 Thick Green RS-485 (B-)
2 Thick Blue RS-485 (A+)
3 Blue WG DAT: 1 Inpu
ABA Clock Input
4 Green WG DAT: 0 Input
ABA Data Input
5 Pink Buzzer Output 5V/100mA, MAX
6 Brown LED Green Output 5V/20mA, MAX
7 Yellow LED Red Output 5V/20mA, MAX
Wire Color Description
1
Black Signal Ground
2 Blue TTL Serial Data Output in
4800, N, 8, 1
V091028
