HIKVISION DS-K5603-Z Quick Start Manual

Face recognition terminal
Hide thumbs Also See for DS-K5603-Z:
Table of Contents

Advertisement

Quick Links

Face Recognition Terminal
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-K5603-Z and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-K5603-Z

Summary of Contents for HIKVISION DS-K5603-Z

  • Page 1 Face Recognition Terminal Quick Start Guide...
  • Page 2 This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 Face Recognition Terminal·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Face Recognition Terminal·Quick Start Guide 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
  • Page 5 Face Recognition Terminal·Quick Start Guide Warnings Follow Cautions Follow these these safeguards to precautions to prevent prevent serious potential injury injury or death. material damage. Warnings  All the electronic operation should be strictly compliance with the electrical safety regulations, fire prevention regulations and other related regulations in your local region.
  • Page 6 Face Recognition Terminal·Quick Start Guide  Please keep all wrappers after unpack them for future use. In case of any failure occurred, you need to return the device to the factory with the original wrapper. Transportation without the original wrapper may result in damage on the device and lead to additional costs. ...

  • Page 7: Table Of Contents

    Face Recognition Terminal·Quick Start Guide Table of Contents Chapter 1 Overview ......................... 1 Introduction ......................... 1 Main Features ........................1 Chapter 2 Appearance ......................3 Chapter 3 Installation ......................4 Chapter 4 Wiring ........................7 Chapter 5 Device Activation ..................... 8 Activating via Device ......................
  • Page 8 Face Recognition Terminal·Quick Start Guide A.2 Posture ..........................23 A.3 Size ............................ 23...

  • Page 9: Chapter 1 Overview

    Face Recognition Terminal·Quick Start Guide Chapter 1 Overview 1.1 Introduction DS-K5603-Z Face recognition terminal, designed with TX1 system, can be applied in the scenarios of examination hall, railway station, bank, building, hotel, etc., which needs identity verification. 1.2 Main Features ...
  • Page 10 Face Recognition Terminal·Quick Start Guide  Exports face pictures and events from the device via the USB interface  Communication with access controller via RS-232 communication mode and communication with the third party devices via RS-485 communication mode  Uploads offline events ...

  • Page 11: Chapter 2 Appearance

    Face Recognition Terminal·Quick Start Guide Chapter 2 Appearance The device appearance, dimensions and descriptions are as follows. Table 2-1 Appearance Description Description Supplement Light Display Screen Power Button Cameras...

  • Page 12: Chapter 3 Installation

    Face Recognition Terminal·Quick Start Guide Chapter 3 Installation Installation Environment:  Avoid backlight and direct sunlight.  If installing outdoors, install a sun shield over the device.  The device should be installed on the pedestals of the barriers. Before you start: ...
  • Page 13 Face Recognition Terminal·Quick Start Guide 2. Wire the cable with the terminals in the barrier pedestal. 3. Raise the pipe and make sure the pipe and the pedestal top panel are vertical. 4. Secure the pipe with hex socket screws. 1) Rotate the pipe and align the four holes on the round panel with the holes on the pedestal top panel.
  • Page 14 Face Recognition Terminal·Quick Start Guide 1) Move the cover on the round panel that secured on the barrier’s pedestal. 2) Rotate the cover and hide the hole on the cover and align the hole with one of the four small parts on the round panel. 3) Secure the cover and the round panel with one supplied M2 screw.

  • Page 15: Chapter 4 Wiring

    Face Recognition Terminal·Quick Start Guide Chapter 4 Wiring The picture displayed below describes the wiring of the device.

  • Page 16: Chapter 5 Device Activation

    Face Recognition Terminal·Quick Start Guide Chapter 5 Device Activation Purpose: You are required to activate the device first before using it. Activation via device, activation via SADP, and activation via client software are supported. The default values of the control terminal are as follows. ...
  • Page 17 Face Recognition Terminal·Quick Start Guide password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the control panel. Steps: 1. Run the SADP software to search the online devices. 2.

  • Page 18: Activating Via Client Software

    Face Recognition Terminal·Quick Start Guide 6. Input the password and click the Modify button to activate your IP address modification. 5.3 Activating via Client Software The client software is versatile video management software for multiple kinds of devices. Get the client software from the supplied disk or the official website, and install the software according to the prompts.
  • Page 19 Face Recognition Terminal·Quick Start Guide 2. Click Device Management to enter the Device Management interface. 3. Check the device status from the device list, and select an inactive device. 4. Check the device status from the device list, and select an inactive device. 5.
  • Page 20 Face Recognition Terminal·Quick Start Guide 7. Click OK button to start activation. 8. Click the Modify Netinfor button to pop up the Network Parameter Modification interface. 9. Change the device IP address to the same network segment with your computer by either modifying the IP address manually.

  • Page 21: Chapter 6 Basic Operation

    Face Recognition Terminal·Quick Start Guide Chapter 6 Basic Operation Purpose: After entering the administrative backend, you can manage users, set communication parameters, change device password, manage and maintain data, and view device information. 6.1 Enter Administrative Backend Purpose: You should enter the de administrative backend before setting other parameters. Steps: 1.

  • Page 22: System Settings

    Face Recognition Terminal·Quick Start Guide the baud rate, you can connect the device to other access control devices via RS-232 protocol or RS-485 protocol. For details about device linkage, see 6.11 Linking Access Control Device. Steps: 1. Tap COM in the Communication Settings page to enter the COM tab. 2.

  • Page 23: User Management

    Face Recognition Terminal·Quick Start Guide authentication mode. QR Code Scanning Enable or disable the QR code scanning function. If enabling, the device camera can scan the QR code to authenticate instead of swiping card. Notes:  By default, the function is disabled. ...

  • Page 24: Searching User

    Face Recognition Terminal·Quick Start Guide You can manually input the user information to add the user. Manually Adding Steps: 1. In the backend, tap to enter the User Management page. 2. Tap Add User to enter the Add User page. 3.

  • Page 25: Editing User

    Face Recognition Terminal·Quick Start Guide select the search type. 2. Input the user name or card No. for search. 3. Tap to start search. The result will display in the user list. 6.4.3 Editing User Purpose: You can change the added user information by follow the steps below. Steps: 1.
  • Page 26 Face Recognition Terminal·Quick Start Guide Parameter Item Description value when face picture authentication. Other percentages, distances and angles in this table should also meet their conditions. Recommended Value: 14 Min. Detection Area When the distance between the camera and the user is long, (Height) the parameter represents the minimum percentage of the facial height in the total height of the recognition area.

  • Page 27: Changing Password

    Face Recognition Terminal·Quick Start Guide Parameter Item Description recognition. The actual resolution should be larger than the configured value. By default, the resolution is 40. Score Set the face picture’s score when recognition. The device will score the captured picture according to the yaw angle, pitch angle, and pupillary distance.

  • Page 28: Maintaining System

    Face Recognition Terminal·Quick Start Guide 6.8 Maintaining System Purpose: You can restore to default settings or factory settings. You can also upgrade the system. 6.8.1 Restoring Device Parameters Purpose: You can restoring the device parameters to the default or to the factory. Steps: 1.

  • Page 29: Authenticating Via 1:1 Matching

    Face Recognition Terminal·Quick Start Guide identity authentication. The system will authenticate person according to the configured authentication mode. You can authenticate identity via 1:1 matching or 1:N matching. Note: If you require a higher security level, do not use single authentication mode. 1:N Matching: Compare the captured face picture with all face pictures stored in the terminal.

  • Page 30: Linking Access Control Device

    Face Recognition Terminal·Quick Start Guide 6.11 Linking Access Control Device Purpose: The face recognition terminal can connect to an access control device via RS-232 protocol and transmit authentication information to the access control device at the same time. The access control device can control the door status according to authentication result and the access control device authentication mode, and transmit the door events to the control client or other systems.

  • Page 31: Appendix Atips When Collecting/Comparing Face Picture

    Face Recognition Terminal·Quick Start Guide Appendix ATips When Collecting/Comparing Face Picture A.1 Expression  Keep your expression naturally when collecting or comparing face pictures, just like the expression in the picture below.  Do not wear hat, sunglasses, or other accessories that can affect the facial recognition function. ...
  • Page 32 Face Recognition Terminal·Quick Start Guide UD09213B...

This manual is also suitable for:

Ds-k5603t-z
