- Page 1 USER MANUAL AVX-HDMI2-FO-HDB-KIT HDMI 2.0 EXTENDER OVER FIBER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM TX RX G RS232 IR IN IR OUT WITCH DC 12V HDMI IN RS232 TX RX G RS232 IR IN IR OUT WITCH DC 12V...
-
Page 2: Table Of Contents
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TABLE OF CONTENTS TECHNICAL SUPPORT 1.877.877.2269 IMPORTANT SAFETY INSTRUCTIONS ............................3 1. SPECIFICATIONS ................................... 4 2. OVERVIEW ...................................... 6 2.1 Introduction .......................................6 2.2 Features ........................................6 2.3 What’s Included ......................................7 2.4 Additional Items You Will Need ................................7 2.5 Hardware Description ....................................8 2.5.1 Transmitter .......................................... -
Page 3: Important Safety Instructions
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 IMPORTANT SAFETY INSTRUCTIONS TECHNICAL SUPPORT 1.877.877.2269 1. Do not expose this apparatus to rain, moisture, dripping or splashing liquids. Do not place any objects filled with liquids, such as vases, on the apparatus. -
Page 4: Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1. SPECIFICATIONS SPECIFICATION DESCRIPTION Transmitter Video Input (1) HDMI female Input Signal Type HDMI 2.0 and HDCP 2.2 800 x 600, 1024 x 768, 1280 x 720, 1280 x 768, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768, Input Resolution Support 1440 x 900, 1600 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160P, 4096 x 2160P... - Page 5 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1 (CONTINUED). SPECIFICATIONS SPECIFICATION DESCRIPTION General ESD Protection Human-Body Model: ±8 kV (air-gap discharge)/±4 kV (contact discharge) Surge Protection Voltage: ±1 kV Data communication cord: 1 kV Electrical Fast Transient/Burst Power cord: 2 kV Approvals...
-
Page 6: Overview
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.1 INTRODUCTION The HDMI 2.0 Extender over Fiber is an HDMI Extender with HDCP 2.2 compatibility. It distributes compressed UHD video, audio, RS-232 or IR together up to 1000 feet (300 meters) over fiber optic cable. The extender features bi-directional RS-232 or IR ports to control AV devices, easy to choose by the slide switch on the rear panels. -
Page 7: What's Included
TECHNICAL SUPPORT 1.877.877.2269 2.3 WHAT’S INCLUDED Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com AVX-HDMI2-FO-HDB-KIT includes: Š (1) Transmitter (AVX-HDMI2-FO-HDB-TX) with 10 Gbit/s MM SFP+ module Š... -
Page 8: Hardware Description
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.5 HARDWARE DESCRIPTION The HDMI 2.0 Extender over Fiber consists of a Transmitter unit and a Receiver unit. 2.5.1 TRANSMITTER Figures 2-1 and 2-2 show the front and back panels of the transmitter. Table 2-1 describes its components. POWER STATUS HDCP LINK... - Page 9 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 TABLE 2-1. TRANSMITTER COMPONENTS NUMBER IN COMPONENT DESCRIPTION FIGURE 2-1 ON: The transmitter is powered on. Power LED OFF: The transmitter is powered off. Flashing: The transmitter is working properly. Status LED OFF: The transmitter is not working properly.
-
Page 10: Receiver
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.5.2 RECEIVER Figures 2-3 and 2-4 show the front and back panels of the receiver. Table 2-2 describes its components. POWER STATUS HDCP LINK FIGURE 2-3. RECEIVER FRONT PANEL TX RX G RS232 DC 12V... - Page 11 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 TABLE 2-2. RECEIVER COMPONENTS NUMBER IN COMPONENT DESCRIPTION FIGURE 2-3 ON: The receiver is powered on. Power LED OFF: The receiver is powered off. Flashing: The receiver is working properly. Status LED OFF: The receiver is not working properly.
-
Page 12: Connections And Installation
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: CONNECTIONS AND INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 3.1 INSTALLATION STEPS 1. Using quality HDMI cables, connect an HDMI source (such as Blu-ray, games console, satellite/cable TV, media server etc.) to the HDMI IN port of the transmitter. 2. -
Page 13: Rs-232 Passthrough
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: CONNECTIONS AND INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 3.3 RS-232 PASSTHROUGH The bi-directional RS-232 passthrough function enables you to use two devices that support RS-232 (such as a laptop and a projector) for serial communication. -
Page 14: Appendix A. Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY COMPLIANCE TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC STATEMENT This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment. -
Page 15: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY COMPLIANCE TECHNICAL SUPPORT 1.877.877.2269 A.2 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 16: Appendix B. Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 17 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 18 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ _________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ ________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 19 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 20 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2018 BLACK BOX CORPORATION. ALL RIGHTS RESERVED. AVX-HDMI2-FO-HDB-KIT_USER_REV1.PDF...
