Extended Range DVI-D Extender with Audio and RS-232
Extends your PC DVI transmission distance up to
330 feet (100 m).
Includes two compact units: transmitter and receiver.
Customer
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Support
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Information
a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
AVX-DVI-TP-100M
BLACK BOX
®
Advertisement
Table of Contents
Related Manuals for Black Box AVX-DVI-TP-100M
Summary of Contents for Black Box AVX-DVI-TP-100M
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. Support call 724-746-5500) • FREE technical support 24 hours a day, 7 days Information a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com... -
Page 2: Trademarks Used In This Manual
Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. UL is a registered trademark of Underwriters Laboratories. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. -
Page 3: Instrucciones De Seguridad
FCC and IC RFI Statements/NOM Statement FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference... - Page 4 NOM Statement 5. El aparato eléctrico no deberá ser usado cerca del agua — por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc. 6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
- Page 5 NOM Statement 18. Servicio por personal calificado deberá ser provisto cuando: A: El cable de poder o el contacto ha sido dañado; u B: Objectos han caído o líquido ha sido derramado dentro del aparato; o C: El aparato ha sido expuesto a la lluvia; o D: El aparato parece no operar normalmente o muestra un cambio en su desempeño;...
-
Page 6: Safety Instructions
Safety Instructions Safety Instructions The Extended Range DVI-D Extender has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment, the extender should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 7: Table Of Contents
Introduction ..................10 Features ....................10 What’s Included ................10 Hardware Description ............... 11 2.4.1 Transmitter ................11 2.4.2 Receiver .................13 3. Hardware Installation .................15 4. Cable ....................16 Appendix. Troubeshooting ................17 Contacting Black Box................17 Shipping and Packaging ..............17 724-746-5500 | blackbox.com Page 7... -
Page 8: Specifications
Chapter 1: Specifications 1. Specifications Audio Support — Stereo 2-channel analog audio Approvals — Converter Unit: FCC, CE, RoHS, WEEE Power Supply: UL , FCC ® Compliance — HDMI, DVI 1.1, HDCP Computer Interface — DVI-D ESD Protection — Human body model: ±19 kV (air-gap discharge) and ±12 kV (contact discharge);... - Page 9 Chapter 1: Specifications Power — Source: Desktop power supply; Power supply cord length: 4 ft. (12.8 m); For both the transmitter and receiver: AC input: 100–240 VAC, 50–60 Hz, 0.8 A, Consumption: 20 W; Output: 5 VDC, 4 A Size — Each unit: 1.3"H x 4.1"W x 3"D (3.2 x 10.5 x 7.6 cm) Weight —...
-
Page 10: Overview
• Direct plug-in at TX and wall-mounting with screws at RX. 2.3 What’s Included Your package should contain the following items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. • (1) DVI Transmitter with built-in wallmount brackets •... -
Page 11: Hardware Description
Chapter 2: Overview 2.4 Hardware Description 2.4.1 Transmitter Figures 2-1 and 2-2 show the front and back panels of the Transmitter. Table 2-1 describes its components. Figure 2-1. Transmitter’s front panel. Figure 2-2. Transmitter’s back panel. 724-746-5500 | blackbox.com Page 11... - Page 12 Chapter 2: Overview Table 2-1. Transmitter’s components. Number Component Description Barrel connector Links to 5-VDC power supply. Power LED Lights when the unit is receiving power. Connect to a DVI source with a DVI DVI-D input female-to-male cable. Audio input Connect to audio input.
-
Page 13: Receiver
Chapter 2: Overview 2.4.2 Receiver FIgures 2-3 and 2-4 show the front and back panels of the receiver unit. Table 2-2 describes its components. Figure 2-3. Receiver’s front panel. Figure 2-4. Receiver’s back panel. 724-746-5500 | blackbox.com Page 13... - Page 14 Chapter 2: Overview Table 2-2. Receiver’s components. Number Component Description Barrel connector Links to 5-VDC power supply. Power LED Lights when the unit is receiving power. Connect to a DVI display with a DVI DVI-D output male-to-male cable. Audio output Connect to audio output.
-
Page 15: Hardware Installation
5. Make sure your CAT5/5e/6 cable is tightly connected and not loose. 6. High quality PC video displays on the screen. Audio Audio cable cable XR Extender XR Extender Transmitter Receiver (AVX-DVI-TP-100M) (AVX-DVI-TP-100M) Speakers DVI cable Flat panel display DVI cable CAT5/5e/6 cable Figure 3-1. Connection diagram. -
Page 16: Cable
Chapter 4: Cable 4. Cable 1. The transmission length is largely affected by the type of LAN cables, the type of HDMI sources, and the type of HDMI display. The testing result shows solid LAN cables (usually bulk cable (100 ft. [300 m]) can transmit a lot longer sig- nals than stranded LAN cables (usually in patch cord form). -
Page 17: Appendix. Troubeshooting
• Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number. - Page 18 NOTES 724-746-5500 | blackbox.com Page 18...
- Page 19 NOTES 724-746-5500 | blackbox.com Page 19...
- Page 20 Great tech support is just 30 seconds away at 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
