Port Connections

The diagram below shows the port connections located in the back of a
KVM 32:
Power
cord

Rack Mounting the KVM

To rack-mount the KVM, perform the following steps:
1. Install the brackets onto the front corners of the box using a screw driver
2. Mount the KVM unit in a secure position.
AlterPath KVM Manual
Power
switch
32 CAT5 KVM ports
and the screws and bolts provided with the mounting kit.
Refer to the Safety Considerations When Rack Mounting section of
this chapter to ensure safety.
2:
AlterPath KVM Installation
brackets
Auxiliary
User2
Mouse
Keyboard
[-User1-]
Ethernet
Console
2-3
