4: KVM Web Configuration
4-52
Field Name
Inverted
Destination IP
Mask
Inverted
Protocol
Inverted
Input Interface
Inverted
Output Interface
Inverted
Fragments
ICMP Type
Definition
Select this box to invert the target action (i.e.,
the action assigned to the target will be per-
formed to all source IPs/Masks except to the one
just defined).
Destination IP address.
Destination network mask.
Select this box to invert the target action (i.e.,
the action assigned to the target will be per-
formed to all Destination/Mask IPs except to the
one just defined).
The transport protocol to check. If the numeric
value is available, select Numeric and type the
value in the adjacent text input field; otherwise,
select one of the other options.
Select box to invert the target action (i.e., the
action assigned to the target will be performed
to all protocols except to the one just defined).
The interface where the IP packet should pass.
The Input Interface option will appear only for
the chains INPUT and FORWARD.
Select box to invert the target action (i.e., the
action assigned to the target will be performed
to all interfaces except to the one just defined).
The interface where the IP packet should pass.
The Output interface option will appear for the
chains FORWARD and OUTPUT.
Select box to invert the target action (i.e., the
action assigned to the target will be performed
to all interfaces except to the one just defined).
Indicates the fragments or unfragmented pack-
ets to be checked. The IP Tables can check for:
- All Packets.
- 2nd, 3rd... fragmented packets.
- Non-fragmented and 1st fragmented packets.
This dropdown list box contains all the ICMP
types that may be applied to the current rule.
