4: KVM Web Configuration
4. Click on the OK button when done.
5. Click on the Apply Changes located at the bottom of the ACS
To Add a Rule
The forms and dialog boxes for adding a rule is similar to the ones used for
editing a rule. Refer to IP Filtering: To Edit a Rule procedure section for a
definition of the user input fields.
1. From the IP Filtering form, select the chain to which you wish to add a
2.
3. From the Edit Rule for Chain dialog box, click on the Add button.
4. Complete the Add Rule dialog box. (Refer to IP Filtering: To Edit a Rule
5. Click on the Apply Changes button located at the bottom of the ACS
4-54
Field Name
icmp-host-unreachable
icmp-port-unreachable
icmp-proto-unreachable
icmp-net-prohibited
icmp-host-prohibited
echo-reply
tcp-reset
configuration window to save your configuration.
rule (or if you are adding a new chain, select the Add button and follow
the procedure for adding a chain.)
Click on the Edit Rule button.
The system brings up the Edit Rule for Chain dialog box.
The system brings up the Add Rule dialog box.
section for a definition of the input fields, as needed.)
configuration window to complete the procedure.
Definition
ICMP host unreachable alias.
ICMP port unreachable alias.
ICMP protocol unreachable alias.
ICMP network prohibited alias.
ICMP host prohibited alias.
Echo reply alias.
TCP RST packet alias.
