Summary of Contents for NXP Semiconductors KEA128LEDLIGHTRD

  • Page 1 KEA128LEDLIGHTRD Quick Start Guide Lighting Control Module Reference Design using Kinetis KEA128...
  • Page 2 Quick Start Guide Get to Know the KEA128LEDLIGHTRD Board MC33901 CAN MC33662 LIN Transceiver Connector Connector Transceiver Potentiometers User Buttons Reset Button 6 Pin SWD Light Output Connector 12 V Power Supply Kinetis EA MC10XS3425 User LEDs Driver Figure 1: Front side of KEA128LEDLIGHRD...
  • Page 3 KEA128LEDLIGHTRD Features Hardware • SKEAZ128 32-bit ARM Cortex -MO+ ® ® MCU (64-pin LQFP) • MC33662 LIN transceiver • MC33901 CAN transceiver • MC10XS3425EK multi-chip high-side switch • 4 LEDs • 4 Potentiometers • 4 User buttons • SWD connector interface for debugging...
  • Page 4: Installation Instructions

    CodeWarrior Development Studio for Download and install the reference design Microcontrollers installation file is included application software available at in the supplied media for your freescale.com/KEA128LEDLIGHTRD. convenience. Connect a The most recent version of CodeWarrior Lamp for MCUs (Eclipse IDE) can be downloaded from www.freescale.com/CodeWarrior.
  • Page 5 Step-by-Step Installation Instructions (cont.) Connect the 5. Navigate to the extracted application directory: KEA128LEDLIGHTRD/ Debugger KEA128_LIGHTING_RD and click OK. Connect a P&E USB Multilink Universal 6. Click Finish. debugger to the 6 pin SWD connector 7. Click Run>Debug to download the of the board.
  • Page 6 Quick Start Guide Application Control in FreeMASTER The FreeMASTER run-time debugging tool is used to control the application and monitor application variables during run-time. An explanation on how to use the FreeMASTER user interface is given below. 1. Click the Output Control button in the Output Channel section or press switch SW2, SW3, SW4, SW5 to control each output state.
  • Page 7: Jumper Options

    freescale.com Jumper Options The following is a list of all jumper options. The default installed jumper settings are shown in white text within gray boxes. Jumper Option Setting Description Inputs Allows independent control of each high side switch output 10-11 Wake up Allows wake up function of MC10XS3425 FSI selection:...
  • Page 8 Visit freescale.com/warranty for complete warranty information. For more information, visit freescale.com/KEA128LEDLIGHTRD Freescale, the Freescale logo, CodeWarrior and Kinetis are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. ARM and Cortex are registered trademarks of ARM Limited (or its subsidiaries) in the EU and/or elsewhere.
