Parts Breakdown
Model MS-IT-0370-H
Item No. Description
16900 Sharpening Assembly for H37S
Ring EL.Benzing 6 Stainless Steel for
36536
H37S
16902 Ring EL.Benzing 8 for H37S
17281 Ring EL.Seeger Ext.25 for H37S
Ring EL.Seeger Est.25 Ser.Heavy for
77585
H37S
19484 Ring 52 for H37S
19612 Ring 33 for H37S
17283 Oil Seal 25x52x10 for H37S
77601 Oil Seal OR 2010 for H37S
17287 O-Ring 123 17.86x2.62 for H37S
77602 O-Ring OR 4500 for H37S
77547 Pin Stop Ring for H37S
77502 Shaft Sealing Ring Ø98x42 for H37S
36546 Carriage Rod for H37S
77548 Tray Rod for H37S
77533 Quandra Bar for H37S
36548 Shock Absorber Bar 12x170 for H37S
77549 Plate Rod for H37S
19508 Carriage Rod for H37S
79260 Body for H37S
16904 Bushing Sharpener for H37S
64357 Bushing DU 16x18x15 for H37S
17304 Bushing for H37S
17305 Bushing DU 18x20x15 for H37S
19514 Bushing Guard A310 for H37S
16906 Bush Sharpening for H37S
16907 Bush Sharpening for H37S
17307 Bushing Sharp for H37S
19630 Bushing Fastener for H37S
78265 Bushing Funnel for H37S
77550 Bushing DU 10x12x10 for H37S
Bushing Fastener Guard Knife A310A
77588
for H37S
17312 Bushing 22x25x20 for H37S
36563 Carriage Bushing for H37S
Bushing for Carriage Support lg.23mm
36564
for H37S
Bushing to Hold Carriage Springs for
36566
H37S
36567 Bushing DU 12x14x25 for H37S
77551 Bushing for Plate Ø16x19 for H37S
38915
Position Item No. Description
A1026 36569 Fixing Lever Bushing for H37S
A5404X 17313 Bushing DU 14x15x16 for H37S
A5406 23646 Sharpener Pivot Ferrule for H37S
A5453 77552 Bushing for Plate for H37S
A5454 77503 Bushing DU 12x14x30 INOX for H37S
A5485 77553 Pusher Arm for H37S
A5495 77554 Pusher Arm Assembly for H37S
A5809 77518 Sharpener Cover for H37S
A5848 36591 Carriage Support for H37S
A5852 65141 Flat Cart for H37S
A5857 77534 Cart Assembly for H37S
Wiring Assembly 6 Poles LG.400 for
A5921 77605
H37S
A5946 79263 Contact Pin for H37S
B1024 36601 Rivet 1.9x5 for H37S
B1038 36607 Blade Cover Bolt Keeper 14x14 for H37S
B1081 36609 Capacitor 20µF 250V for H37S
B1251 65148 Condenser 20mf 250V for H37S
B1258 74403 Connector Faston 2 Poles Male for H37S
B1376 77611 P.C.B. Cover Box for H37S
B1808 36614 Cover Anter.Motor H (Diam.135) for H37S
B6048 36615 Back Motor Cover for H37S
B6053 65149 Cover Fan Mot.ESTR.Diam 135 for H37S
B6056 19534 Housing Sharpener H for H37S
B6057 19536 Rack for H37S
B6061 65156 Bearing 2Z-6205 25x52x15 for H37S
B6075 16925 Bearing 2RS-6204 20x47x14 for H37S
B6076 36630 Bearing 5x16x6.5 for H37S
B6083 36631 Bearing 2RS-6205 25x52x15 for H37S
B6104B 16926 Bearing 2RS-6000 (10x26x8) for H37S
B6110 60423 Touch Pad Gasket for H37S
B6111 19637 Nut M3 for H37S
B6140 77504 Stainless Steel Nut U5587 M4 for H37S
B6211 77612 Self-Locking Nut M3 UNI7473 for H37S
B6213 77535 Special Nut M10 for H37S
B6214 16928 Nut U5589 M6 for H37S
B6221 65158 Low Nut U5589 M8 6S for H37S
B6222 36638 Nut U5589 M10 Stainless Steel for H37S
B6231 77505 Stainless Steel Nut U5588 M12 for H37S
Position Item No.
B6239 19646
B6244 77555
B6256 19642
B6332 36643
B6336 36646
B7825 36647
B7919 64365
C1616 36649
C185404 36651
C1885 79264
C1904 77506
C3236 19648
C3352 77556
C4640 36656
C5007 17341
C5814 36661
C5815 36665
C6010 77519
C644680 77557
C6464 65168
C6466 36677
C6573 77590
C6807 77558
C7244 19564
C8011 36680
C8024 77614
C8035 36682
C8056 77591
C8067 65172
C8242 17351
D0101 36689
D0102X 36691
D0110 65173
D0116 36695
D0133 77559
D0135 36697
D0137X 77507
D014215 19580
20
Description Position
Nut U5588 M16 Stainless Steel for H37S D0144X
Domed Nut DIN 917 M8 Stainless Steel
D014515
for H37S
Nut M8 for H37S D0155X
Nut U5588 M5 for H37S D0160
Nut U5588 M6 Stainless Steel for H37S D0163X
Nut U5588 M8 for H37S D0165
Nut U5588 M8 for H37S D0165X
Nut U5588 M10 Stainless Steel for H37S D0167X
Sharpener Support Nut for H37S D0183
Blade Support Screw for H37S D5454
Spacer Ø22x22 for H37S D5465
Knife Spacer for H37S D5602
Right Spacer INT90 for H37S D5624
Motor Spacer for H37S D5640
Spacer D.10.5x14 H.9 for H37S D5643
Carriage Shock Absorber Spacer for
D5762
H37S
Locknut Spacer for H37S D577018
Spacer Eccentrico for H37S D577141
Spacer Supp.Bar Post. for H37S D5834
Eccentric Cusc. Cart lg.43 for H37S E145801
Cam Pin for H37S E1460
Cam for Sharpener for H37S E1461
Eccentric for H37S E1471
Cam 25mm for H37S E1474
Carriage Felt for H37S F1606
Nylon Cable Tie (Diam.45x200) for H37S F2815
Unhook Friction Clasp 12x22x8 for H37S F3015
Support Blade Flange for H37S F6039
Flange for Impugn. Graduated for H37S F609076
Locknut for H37S G5018
Stainless Steel Locknut M8 for H37S G5027
Ring for Bushing for H37S G5053
Ring for Eccentric for H37S G5054
Ring Support Cap for H37S G5055
Plate Bar Supp. Ring 250/273 for H37S G5056
Logging Locknut for H37S G5064
Locknut M22 P.1 for H37S G5106
Handle TS8 for H37S I1907
