1.1 General Introduction

The ARRAY 3600 Series Power Supply is a compact programmable DC power supply. It is equipped with
backlight LCD display, numerical keypad and rotary knob which make it much easier to use. It offers constant
voltage mode and constant current mode. Programming features include over-current protection, maximum output
voltage and output power limitation, and 10 parameters storage. It is an essential instrument for scientific research,
education, service and so on institutions.

1.2 Specifications

Mode
Number
DC
Output
Line
Regulation
Load
Regulation
Ripple
and noise
Programming
accuracy at
o o
25 C+/-5 C
Readback
accuracy at
o o
25 C+/-5 C
Program
resolution
Readback
resolution
Protection
AC Input
Operation environment
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03

Chapter 1 General Introduction

3644A
1
Voltage 0~18V
Current 0~5A
Power(max) 90W
0~3.999V: 0.01% + 3mV
Voltage
4~18V: 0.02% + 10mV
Current 0.02% + 8mA
Voltage 0.02% + 20mV
Current 0.02% + 15mA
Voltage < 1mVrms
Current < 5mArms
Voltage 0.1% + 20mV
Current 0.2% + 20mA
0.2% + 20mV
Voltage
0.2% + 20mA
Current
0-3.999V: 1mV
Voltage
4-18V: 10mV
Current 1mA
Voltage 10mV
Current 10mA
Over voltage/Over current/Over power
110/220V AC switch able (60/50HZ)
o
0-50 C, 80% RH*
3600 SERIES USER MANUAL
3645A
1
0~36V
0~3A
108W
0~3.999V: 0.01% + 3mV
4~36V: 0.02% + 10mV
0.02% + 8mA
0.02% + 10mV
0.02% + 10mA
< 1mVrms
< 4mArms
0.1% + 20mV
0.2% + 20mA
0-19.999V: 0.2% + 20mV
20-36V: 0.2% + 100mV
0.2% + 20mA
0-3.999V: 1mV
4-36V: 10mV
1mA
0-19.999V: 10mV
20-36V: 100mV
10mA
3646A
1
0~72V
0~1.5A
108W
0~3.999V: 0.01% + 3mV
4~72V: 0.02% + 10mV
0.02% + 8mA
0.02% + 10mV
0.02% + 8mA
< 1mVrms
< 3mArms
0.1% + 20mV
0.2% + 20mA
0-19.999V: 0.2% + 20mV
20-72V: 0.2% + 100mV
0.2% + 20mA
0-3.999V: 1mV
4-72V: 10mV
1mA
0-19.999V: 10mV
20-72V: 100mV
10mA
1
