CPD-E210
Note:
D
The components identified by shading and mark
are critical for safety. Replace only with part number
specified.
REF.NO. PART NO.
DESCRIPTION
R600
1-205-998-11
CEMENTED
R602
1-219-513-11
CARBON
R603
1-249-403-11
CARBON
R604
1-220-827-91
REGISTER
R605
1-211-761-71
RES, FUSE
R606
1-218-768-11
METAL CHIP
R607
1-240-997-91
METAL CHIP
R608
1-215-473-00
METAL
R609
1-216-665-11
METAL CHIP
R610
1-216-651-11
METAL CHIP
R611
1-240-961-91
METAL CHIP
R612
1-247-791-91
CARBON
R613
1-219-513-11
CARBON
R614
1-216-345-11
METAL OXIDE
R615
1-242-778-91
METAL CHIP
R616
1-242-780-91
METAL CHIP
R617
1-240-969-91
METAL CHIP
R618
1-216-635-11
METAL CHIP
R619
1-215-893-11
METAL OXIDE
R620
1-216-687-11
METAL CHIP
R621
1-216-098-00
RES,CHIP
R622
1-247-791-91
CARBON
R623
1-216-615-91
METAL CHIP
R624
1-216-611-11
METAL CHIP
R625
1-260-332-51
CARBON
R626
1-240-985-91
METAL CHIP
R627
1-249-377-11
CARBON
R628
1-216-674-11
METAL CHIP
R629
1-249-441-11
CARBON
R630
1-211-874-71
RES, FUSE
R631
1-211-874-71
RES, FUSE
R633
1-249-429-11
CARBON
R634
1-211-874-71
RES, FUSE
R635
1-215-925-11
METAL OXIDE
R636
1-260-119-11
CARBON
R637
1-215-902-11
METAL OXIDE
R638
1-211-874-71
RES, FUSE
R639
1-211-874-71
RES, FUSE
R640
1-249-381-11
CARBON
R642
1-216-641-11
METAL CHIP
R643
1-215-467-00
METAL
R645
1-216-675-91
METAL CHIP
R646
1-242-763-91
METAL CHIP
R647
1-240-993-91
METAL CHIP
R648
1-216-669-11
METAL CHIP
R649
1-216-663-11
METAL CHIP
R650
1-215-471-00
METAL
R654
1-216-344-00
METAL OXIDE
R655
1-247-807-31
CARBON
REMARK
1
5%
10W
4.7M
5%
1/2W
68
5%
1/4W
560K
5%
1/2W
0.1
10%
1/2W
470K
0.50% 1/10W
22K
5%
1/10W
150K
1%
1/4W
3.9K
0.50% 1/10W
1K
0.50% 1/10W
22
5%
1/10W
22
5%
1/4W
4.7M
5%
1/2W
0.47
5%
1W
F
680K
5%
1/10W
1M
5%
1/10W
100
5%
1/10W
220
0.50% 1/10W
1.5K
5%
2W
F
33K
0.50% 1/10W
110K
5%
1/10W
22
5%
1/4W
33
0.50% 1/10W
22
0.50% 1/10W
2.2K
5%
1/2W
2.2K
5%
1/10W
0.47
5%
1/4W
F
9.1K
0.50% 1/10W
100K
5%
1/4W
0.12
10%
1/2W
0.12
10%
1/2W
10K
5%
1/4W
0.12
10%
1/2W
22K
5%
3W
F
47K
5%
1/2W
47K
5%
2W
F
0.12
10%
1/2W
0.12
10%
1/2W
1
5%
1/4W
F
390
0.50% 1/10W
82K
1%
1/4W
10K
0.50% 1/10W
39K
5%
1/10W
10K
5%
1/10W
5.6K
0.50% 1/10W
3.3K
0.50% 1/10W
120K
1%
1/4W
0.39
5%
1W
F
100
5%
1/4W
— 44 —
Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
REF.NO. PART NO.
DESCRIPTION
R656
1-215-893-11
METAL OXIDE
R660
1-260-119-11
CARBON
R661
1-215-902-11
METAL OXIDE
R663
1-216-663-11
METAL CHIP
R665
1-216-663-11
METAL CHIP
R703
1-249-410-11
CARBON
R704
1-216-673-11
METAL CHIP
R705
1-216-667-11
METAL CHIP
R706
1-216-667-11
METAL CHIP
R707
1-216-659-11
METAL CHIP
R708
1-216-659-11
METAL CHIP
R709
1-216-659-11
METAL CHIP
R710
1-216-659-11
METAL CHIP
R711
1-216-346-00
METAL OXIDE
R712
1-215-860-11
METAL OXIDE
R713
1-216-347-11
METAL OXIDE
R716
1-215-860-11
METAL OXIDE
R717
1-216-353-00
METAL OXIDE
R718
1-215-863-11
METAL OXIDE
R719
1-216-679-11
METAL CHIP
R724
1-216-422-11
METAL OXIDE
R727
1-216-679-11
METAL CHIP
R728
1-215-863-11
METAL OXIDE
R729
1-216-353-00
METAL OXIDE
R730
1-216-421-11
METAL OXIDE
R731
1-216-295-91
SHORT
R733
1-216-295-91
SHORT
R735
1-216-659-11
METAL CHIP
R737
1-216-659-11
METAL CHIP
R739
1-240-993-91
METAL CHIP
R741
1-249-377-11
CARBON
R743
1-249-377-11
CARBON
R745
1-240-949-91
METAL CHIP
R747
1-240-949-91
METAL CHIP
R753
1-216-679-11
METAL CHIP
R755
1-216-667-11
METAL CHIP
R903
1-240-981-91
METAL CHIP
R904
1-240-981-91
METAL CHIP
R905
1-216-295-91
SHORT
R906
1-240-993-91
METAL CHIP
R907
1-260-087-81
CARBON
R908
1-240-985-91
METAL CHIP
R909
1-240-985-91
METAL CHIP
R912
1-240-981-91
METAL CHIP
R913
1-240-969-91
METAL CHIP
R914
1-240-969-91
METAL CHIP
R915
1-240-989-91
METAL CHIP
R916
1-240-995-91
METAL CHIP
R917
1-240-995-91
METAL CHIP
REMARK
1.5K
5%
2W
F
47K
5%
1/2W
47K
5%
2W
F
3.3K
0.50% 1/10W
3.3K
0.50% 1/10W
270
5%
1/4W
8.2K
0.50% 1/10W
4.7K
0.50% 1/10W
4.7K
0.50% 1/10W
2.2K
0.50% 1/10W
2.2K
0.50% 1/10W
2.2K
0.50% 1/10W
2.2K
0.50% 1/10W
0.56
5%
1W
F
33
5%
1W
F
0.68
5%
1W
F
33
5%
1W
F
2.2
5%
1W
F
100
5%
1W
F
15K
0.50% 1/10W
18
5%
1W
F
15K
0.50% 1/10W
100
5%
1W
F
2.2
5%
1W
F
12
5%
1W
F
2.2K
0.50% 1/10W
2.2K
0.50% 1/10W
10K
5%
1/10W
0.47
5%
1/4W
F
0.47
5%
1/4W
F
2.2
5%
1/10W
2.2
5%
1/10W
15K
0.50% 1/10W
4.7K
0.50% 1/10W
1K
5%
1/10W
1K
5%
1/10W
0
10K
5%
1/10W
100
5%
1/2W
2.2K
5%
1/10W
2.2K
5%
1/10W
1K
5%
1/10W
100
5%
1/10W
100
5%
1/10W
4.7K
5%
1/10W
15K
5%
1/10W
15K
5%
1/10W
