Instruction Manual
D102748X012
Figure A‐6. Digital Level Controller Analog Output Signal
24
22
20
18
16
14
12
10
8
Output Saturated
(3.8 mA)
6
4
2
-20%
E0379
Note
The upper alarm value is compliant with NAMUR NE 43, but the lower alarm value is not.
If using in a system with NAMUR NE 43 compatibility, the high alarm value may be an appropriate choice.
Other circuits in the digital level controller provide reverse polarity protection, transient power surge protection, and
electromagnetic interference (EMI) protection.
Output during Alarm with
Alarm Jumper in Hi Position
(22.5 mA)
Normal Operation
0% 20% 40%
Output during Alarm with
Alarm Jumper in Lo
Position
(3.7 mA)
60% 80%
PV Range
DLC3010 Digital Level Controller
Principle of Operation
Output Saturated
(20.5 mA)
100% 120%
May 2018
103
