- Page 1 Preparing Your Room for the Polycom® Open Telepresence Experience ™ (OTX ™ ) 300 Installation OTX 300 Hardware Version A Software Version 2.7 3725-09853-001/A September 2010...
- Page 2 As between the parties, Polycom, Inc., retains title to and ownership of all proprietary rights with respect to the software contained within its products. The software is protected by United States copyright laws and international treaty provision.
-
Page 3: Table Of Contents
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation Table of Contents About This Document ......................... 4 Will the OTX 300 Fit in My Selected Room? ................5 Physical Room Requirements ....................6 Ceiling Requirements ......................6 Height .......................... -
Page 4: About This Document
The Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation document is intended for Polycom customers who have purchased an OTX 300 and are in the process of preparing their room for the OTX installation. This document defines the room characteristics (such as the room size, wall color, and power outlets), delivery requirements, and network requirements needed to successfully deploy the Polycom OTX 300 telepresence solution. -
Page 5: Will The Otx 300 Fit In My Selected Room
Will the OTX 300 Fit in My Selected Room? The first step in preparing for an OTX 300 installation is to make sure that the OTX will properly fit into the room you selected. The following table can help you make that determination. -
Page 6: Physical Room Requirements
• If your ceiling is higher than 10 ft (3.04 m) and lower than 14 ft (4.26 m), you must order three optional 6-foot (1.82 m) drop cables (part number 2457-26765-072) from your Polycom sales representative. Be sure to order one drop cable for each Ceiling Microphone Array. - Page 7 For more information about the OTX Complete Experience kit lighting requirements: • See the lighting plans on pages 28 and 29 and the OTX 300 side view on page 31. • See the specification sheet for the lights: For Zumtobel Lighting VAETROS™...
- Page 8 OTX lighting. (Note that this pertains to rooms with and without the OTX Complete Experience Kit, although Polycom does recommend that all rooms that are deeper than 15 ft 6 in (4.72 m) front-to- back should include a Complete Experience Kit.) To reduce the probability of interference from other lights in the room: •...
-
Page 9: Front Wall Requirements
Your room may have lights in the area outside of the “keep-out” area; however these lights must have the same temperature as the OTX lighting. Additionally, to minimize stray light, Polycom recommends that these lights be downward-facing, such as recessed can lights. -
Page 10: Lan Jacks
If you choose to install tabletop microphones rather than the standard Ceiling Microphone Arrays, you must purchase two HDX tabletop microphone array kits (Polycom part number 2215-23327-001). Each kit contains one microphone array and one 25-foot (7.6 m) cable. (Note that the microphone cabling is limited to this length.) -
Page 11: Camera Bracket
Camera Bracket During the installation of the OTX 300, the installers must attach the camera bracket to the front wall of the room. To prepare for the installation of this bracket, you must drill mounting holes in the front wall in accordance with the placement plan on page 30. -
Page 12: Side Wall Requirements
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation Side Wall Requirements Color • Recommended Option: Paint the side walls, including the baseboards, Behr Ultra Pure White interior satin enamel 7050. • Second Option: Paint the side walls, including the baseboards, Behr Pewter Mug interior satin enamel 770E-3. -
Page 13: Obstructions
• To obtain the best acoustics, use a room in which the floor is carpeted or have carpeting installed in the room. • Polycom recommends that you install a black carpet made of tiles similar to the following: InterfaceFLOR™ Tectonics/Binary (Style Number 14137/Color Number 100060). Install the floor with the lines aligned and as closely matched as possible;... -
Page 14: Floor Support
23 and 24. Polycom highly recommends that you do not locate the door on the front wall or the rear wall of the room because the width of the room would have to be greatly expanded to accommodate access around the OTX video wall or the rear wall of the OTX Complete Experience Kit. -
Page 15: Chairs
Herman Miller® Eames® Aluminum Group Executive chair (see http://www.hermanmiller.com/Products/Eames-Aluminum-Group-Chairs). This chair complements the décor of the OTX 300 in both style and size. If you do not purchase these chairs, Polycom highly recommends that you purchase chairs that are the same size, color, and shape to maintain the integrity of the room. -
Page 16: Power And Cooling
Note that this table includes only the OTX components and not the participants, laptops, and lighting. Thermostat Polycom recommends installing an independently controlled thermostat on a side wall in the room. The operating temperature for the OTX equipment should be within 41° to 86° F (5° to 30° C). -
Page 17: Delivery Requirements
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation Delivery Requirements You must ensure that the following delivery requirements are met: • Access is available to a loading bay or designated area that is protected from inclement weather and from excessive heat and cold. -
Page 18: Network Requirements
• Review your Wide Area Network (WAN) connectivity. You must have sufficient bandwidth to support HD video as well as capacity for your existing data traffic. • Review your Quality of Service (QoS) settings. If you are using Diffserv, you can use Polycom’s Diffserv markings to fit into your current QoS schema. -
Page 19: Summary Checklist Of Room Requirements
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation Summary Checklist of Room Requirements Review the following checklist prior to the OTX installation. In order to achieve the optimal OTX telepresence experience, you should answer yes to most of the questions listed. - Page 20 Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation India Power Outlets Italy (continued) Australia, New Zealand Are mounting holes drilled according to wall and placement plan on Camera Bracket page 30? Obstructions Are all devices, such as thermostats, removed from front wall?
- Page 21 Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation Thermostat Is independently controlled thermostat installed? Obstructions Is room clear of any obstructing architectural elements? Delivery Requirements Check if Yes Is access to loading bay available and protected from inclement weather? Can loading bay accommodate a 53 ft (16.1 m) trailer truck?
-
Page 22: Appendix: Otx 300 Placement Plans
• OTX 300 Front Wall Network Switches: See page 26 • OTX 300 Optional EMEA and APAC Power Configurations: See page 27 • OTX 300 Complete Experience Kit Lighting and Ceiling Microphone Array Placement Plan: See page 28 • OTX 300 Complete Experience Kit Lighting Gripple Plan: See page 29 •... -
Page 23: Otx 300 Placement Plan (With Complete Experience Kit)
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Placement Plan (with Complete Experience Kit) Page 23 of 32... -
Page 24: Otx 300 Placement Plan (Without Complete Experience Kit)
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Placement Plan (without Complete Experience Kit) Note that the dashed lines show the minimum room size. Page 24 of 32... -
Page 25: Otx 300 Front Wall Electrical Plan
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Front Wall Electrical Plan Page 25 of 32... -
Page 26: Otx 300 Front Wall Network Switches
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Front Wall Network Switches See the following page for the optional EMEA and APAC power placement. Page 26 of 32... -
Page 27: Otx 300 Optional Emea And Apac Power Configurations
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Optional EMEA and APAC Power Configurations Page 27 of 32... -
Page 28: Otx 300 Complete Experience Kit Lighting And Ceiling Microphone Array Placement Plan
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Complete Experience Kit Lighting and Ceiling Microphone Array Placement Plan Page 28 of 32... -
Page 29: Otx 300 Complete Experience Kit Lighting Gripple Plan
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Complete Experience Kit Lighting Gripple Plan Page 29 of 32... -
Page 30: Otx 300 Camera Mount Location
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Camera Mount Location Page 30 of 32... -
Page 31: Otx 300 Side View
Preparing Your Room for the Polycom Open Telepresence Experience (OTX) 300 Installation OTX 300 Side View Page 31 of 32... - Page 32 Polycom Worldwide Headquarters 4750 Willow Road, Pleasanton, CA 94588 1.800.POLYCOM or +1.925.924.6000 www.polycom.com...
