1.3.3 Electronics

1.3.3a Electronics Enclosure Material
Epoxy-coated aluminum
Stainless steel A351, Gr 316/316L (optional)
1.3.3b Weight
29 lb (13.2 kg) aluminum
58 lb (24.3 kg) stainless
1.3.3c Dimensions
Size (l x h x d): 13" x 11" x 9"
1.3.3d Ingress Protection
Type 4X / IP66
1.3.3e Power Supply
•
100 - 240 VAC
•
12 - 32 VDC
1.3.3f Power Consumption
7 Watts
1.3.3g Display
High contrast 128 x 64 pixel graphical display with LED illumination.
1.3.3h Outputs
•
Two frequency/pulse outputs
•
Two alarm relays
•
One 4/20 mA output with HART (version 6)
1.3.3i Inputs
Two 4/20 mA and one 100 Ohm RTD input for density, pressure and temperature input (optional), or
Three 4/20 mA inputs for density, pressure and temperature input (optional).
