6.2 Hardware Maintenance and Inspection

WARNING! Before opening the vessel, it must not contain any pressure! This warning pertains to all
three interfaces described below (flange interface, transmitter connection and sensor ports). The
appropriate procedure should be followed to properly relieve any pressure build up in the system
prior to servicing the equipment.
WARNING! All equipment must be de-energized prior to servicing.
Only trained and qualified personnel should service the pressure vessel. The system has three serviceable interfaces:
•
Flanges
•
Sensor ports
•
Transmitter connection
Sentinel™ LCT4 User's Manual
Transmitter Connection
Flanges
Sensor Ports
Figure 55: Serviceable Interfaces
(Hidden)
Chapter 6. Maintenance
111
