1.4.4 Flowrates

Table 7 below includes OIML approved minimum and maximum flowrates for which the system has been shown to
maintain OIML accuracies and repeatabilities.
Nominal Vessel
Diameter (in.)
In general, ultrasonic flowmeters are capable of measuring fluid flow rates from as low as 0.5 ft/s (0.15m/s) to over
30 ft/s (9.1 m/s).
IMPORTANT: Please consult GE for an application assessment if higher or lower flow rates are required for a
particular application.

1.4.5 Allowable Fluids

Allowable fluids include: liquid petroleum and related products, liquid food and chemical products (including water) in
liquid state. With regards to the Pressure Equipment directive, the product is approved for Group 1 liquids.
This product uses Viton
than any non-fluorinated elastomer, providing the best proven fluid resistance of any commercial rubber. They provide
excellent resistance to oils, fuels, lubricants, and most mineral acids.
WARNING! If application fluids have a known incompatibility with Viton
Sentinel™ LCT4 User's Manual
Table 7: OIML Approved Flowrates
OIML Maximum/Minimum Flow Rates
English [GPM]
Q
min
3 18
4 44
6 71
8 89
10 106
12 212
14 467
16 608
18 766
20 947
24 1233
®
O-rings which provide resistance to degradation by a greater variety of fluids and chemicals
Metric [m
Q Q
max min
1409 4
1828 10
2576 16
6604 20
9026 24
11227 48
15410 106
20033 138
25316 174
31260 215
43588 280
Chapter 1. Features and Capabilities
3
/hr]
Q
max
320
415
585
1500
2050
2550
3500
4550
5750
7100
9900
®
, please consult GE.
