- Page 1 Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series User Manual V1.0 LMX-0802 Series 8-Port Industrial Managed Ethernet Switches with 6*10/100Tx + 2*100Fx SC or ST Ports Version 1.2 Hardware Manual...
-
Page 2: Trademark Information
Trademark Information Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA are the registered trademarks of Wi-Fi Alliance. -
Page 3: Fcc Warning
This manual supports the following models: LMX-0802-M LMX-0802-M-T LMX-0802-S3 LMX-0802-S3-T LMX-0802-ST-M LMX-0802-ST-M-T LMX-0802-ST-S3 LMX-0802-ST-S3-T This document is the current official release manual. Please check our website (www.antaira.com) for any updated manual or contact us by e-mail (support@antaira.com). -
Page 4: Table Of Contents
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 Table of Contents 1. Introduction ..............1 1.1 Product Overview 1.2 Product Software Features 1.3 Product Hardware Features 1.4 Package Contents 1.5 Safety Precaution 2. Hardware Description ..........4 2.1 Physical Dimensions... -
Page 5: Introduction
(SNMP). 1.1 Product Overview Antaira Technologies’ LMX-0802 series is an 8-port industrial managed Ethernet switch that is embedded with 6*10/100 Ethernet ports and 2*100Fx SC or ST type Fiber connectors to support either multi-mode (2Km) or single-mode (30Km). It is a fully manageable Layer 2 Ethernet switch that is pre-loaded with a user-friendly web management console design. -
Page 6: Product Hardware Features
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 IGMP snooping v1/v2, IGMP filtering / throttling, IGMP query up to 256 group Supports IPv4/IPv6, RMON, MIB II, port mirroring, event syslog, DNS, NTP/SNTP, HTTPS, SSH/SSL, TFTP ... -
Page 7: Package Contents
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 1.4 Package Contents 1– LMX-0802 series: 8-port industrial managed Ethernet switch, with 6*10/100Tx RJ45 Ethernet ports and 2*100Fx (SC/ST) Fiber Ports (Multi-mode 2Km, or Single-mode 30Km) ... -
Page 8: Hardware Description
2. Hardware Description 2.1 Physical Dimensions Figure 2.1, below, shows the physical dimensions of Antaira’s LMX-0802 series: 8-port industrial managed Ethernet switches with 6*10/100Tx ports and 2*100Fx fiber ports. (W x D x H) is 54mm x 99mm x 142mm Figure 2.1... -
Page 9: Front Panel
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 2.2 Front Panel The front panel of the LMX-0802 series industrial managed Ethernet switch is shown below in Figure 2.2. 6-Pin Removal Terminal Block (Power Input) Grounding Screw LED for PWR1, PWR2, and Fault LAN Port #7~8 –... -
Page 10: Led Indicators
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 2.4 LED Indicators There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific meaning, see below in Table 2.1. -
Page 11: Ethernet Ports
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 Seconds Function Save running configuration to USB Reboot the switch 7 or more Restore factory default Table 2.2 – Reset Button Functions 2.6 Ethernet Ports RJ-45 Ports RJ-45 Ports (Auto MDI/MDIX): The RJ-45 ports are auto-sensing for 10Base-T or 100Base- TX connections. -
Page 12: Fiber Port
Crossover Cable Schematic 2.7 Fiber Port Antaira’s LMX-0802 series provides different models to support two major fiber optical ports and optional models for SC or ST type fiber connectors. The multi-mode up to 2 km, 1310 nm in 50/125 µm, 62.5/125 µm The single-mode in 30km, 1310 nm in 9/125 µm... -
Page 13: Cabling
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 2.8 Cabling Use the four twisted-pair, category 5e, or the above cabling for the RJ-45 port connections. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) in length. -
Page 14: Grounding Note
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 The wire gauge for the terminal block should range between 12 ~ 24AWG If only using one power source, jumper Pin 1 to Pin 5 and Pin 2 to Pin 6 to ... -
Page 15: Mounting Installation
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 3. Mounting Installation 3.1 DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-... -
Page 16: Wall Mounting
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 3.2 Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown below in Figure 3.4. Caution: “Wall” means industrial control panel wall 1. -
Page 17: Hardware Installation
4. Hardware Installation 4.1 Installation Steps This section will explain how to install Antaira’s LMX-0802 series: 8-port industrial managed Ethernet switches with 6*10/100Tx ports and 2*100Fx SC or ST fiber ports. Caution: This device is intended for use indoor and at altitudes up to 2000 meters. - Page 18 Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 Voltage/Power lines should be properly insulated as well as other cables. Be careful when handling them so as to not trip over. Do not under any circumstance insert foreign objects of any kind into the heat dissipation holes located in the different faces of the device.
-
Page 19: Technical Specifications
Antaira Technologies - Industrial Ethernet Switches LMX-0802 Series Hardware Manual V1.2 5. Technical Specifications Table 5.1 has the technical specifications for Antaira’s LMX-0802 series: 8-port industrial managed Ethernet switches with 6*10/100Tx ports and 2*100Fx SC or ST fiber ports. IEEE 802.3 10Base-T 10Mbit/s Ethernet IEEE 802.3u... -
Page 20: Technical Specifications
Antaira Customer Service and Support (Antaira US Headquarter) + 844-268-2472 (Antaira Europe Office) + 48-22-862-88-81 (Antaira Asia Office) + 886-2-2218-9733 Please report any problems to Antaira: www.antaira.com support@antaira.com www.antaira.eu info@antaira.eu www.antaira.com.tw info@antaira.com.tw Any changes to this material will be announced on the Antaira website.
