Auto Power OFF
The meter will automatically power OFF if the reading stays 0% for 3 minutes. If the meter detects
readings, other than 0%, it will not automatically power OFF.
Display (Hold) Lock
Short press the Display Lock button
the display when Display Lock is active. Press
Beeper ON/OFF
The beeper defaults to ON. To switch the beeper OFF, long press the Display Lock/Audible Beeper
button . When the beeper is active, the audio display icon
Pinless Moisture Measurements
1. Short press the Material Select button (
modes of operation. The displayed icon indicates the selected mode.
2. To take a measurement, hold the meter and position the sensor so that it is directly touching
the surface under test (at any angle). The meter can sense moisture to a depth of 10.2cm (4").
NOTE: The position of your hand can affect the reading. Do not move or reposition the hand
that holds the meter while taking measurements or when powering the unit.
3. Observe the displayed relative readings, view the displayed moisture droplet icon(s)
drops indicate higher moisture levels), and listen for the audible beeping (faster beeping
indicates higher moisture; there are eight intensity levels). As discussed in the Measurement
Considerations section, the displayed reading is an average of the moisture measured over the
tested surface area to the maximum penetration depth.
4. Long press the power button to power OFF the meter.
Relative Moisture Reading Reference Table
WOOD (%)
TOTAL RANGE > 0.1~99.9
0.1~9.9
LOW
10.0~16.9
17.0~23.9
MEDIUM
24.0~29.9
30.0~39.9
40.0~59.9
HIGH
60.0~69.9
70.0~99.9
Maintenance
Battery Replacement
When the battery status icon appears empty or flashing, replace the battery.
1. Remove the battery cover by pushing the compartment latch (bottom, back of meter).
2. Replace the 9V battery observing correct polarity.
3. Replace the battery cover securely.
4. Dispose of battery responsibly and within applicable legal regulations.
to freeze the displayed reading. The icon is visible on
again to return to the normal operating mode.
will be visible.
) to toggle the Wood and Building Material
BUILDING MATERIAL (%)
0.1~99.9
0.1~9.9
10.0~16.9
17.0~23.9
24.0~29.9
30.0~39.9
40.0~59.9
60.0~69.9
70.0~99.9
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate
collection sites, the retail store where the batteries were purchased, or wherever
batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is obligated to take
end-of-life devices to a designated collection point for the disposal of electrical and electronic
equipment.
Care and Cleaning
•
Store the meter in an environmentally stable, dust-free environment, out of direct sunlight.
• Remove the battery from the instrument if the meter is to be stored for long periods or if
the battery power symbol appears empty (or flashing) on the display.
• To clean the meter case, wipe with a damp cloth, do not use solvents or abrasives.

Specifications

Display
Sensor Type
Measurement Type
(more
Measurement Indication Digital, Moisture Droplet icons (1, 2, or 3 droplets) and audible tone with
Measurement Ranges:
Wood: Low: 0.1% to 16.9%; Medium: 17.0% to 39.9%; High: 40.0 to 99.9%
Building Materials: Low: 0.1% to 16.9%; Medium: 17.0% to 39.9%; High: 40.0 to 99.9%
Measurement depth
Resolution
Accuracy
Auto Power OFF
Power supply
Low Battery indication
Low Battery APO
Operating conditions
Storage conditions
Dimensions
Weight
All rights reserved including the right of reproduction in whole or in part in any form
2
LCD with multi-function indicators
Pinless spherical sensor
Non-destructive, electro-magnetic sensing
eight levels of intensity indicating low to high moisture readings
Sensor detects to a depth of 10.2cm (4")
0.1%
Relative readings only
After approx. three (3) minutes with 0% display reading.
One (1) 9V Battery; Consumption: < 40mA
< 7.5VDC, approximately
< 5.5VDC; APO will occur in 20 seconds, approximately
o o
5 ~ 45 C (41 ~ 113 F); 80%RH max.
o o
0 ~ 50 C (32 ~ 122 F); 85%RH max.
210 x 70 x 33mm (8.3 x 2.8 x 1.3")
155g (5.5 oz.) without battery
Copyright © 2017 FLIR Systems, Inc.
www.extech.com
MO57-en-GB_V1.0 7/17
