SYSTEM OPERATIONS

CONNECTION TO A MONITOR
Use either HDMI or VGA output to connect to a monitor and select the correct input
channel on the monitor.
CONNECTION TO A ROUTER
If remote reviewing is required from a smart-phone or PC, please connect the DVR to
the router using a network cable. During power up the DVR will obtain the necessary
network details.
POWER ON
Plug one lead from the 5-way power supply into the 12VDC power supply input
marked on the DVR. Turn on the DVR at the mains power point. The Power supply
indicator light will illuminate on the DVR's front panel followed by several
short bleeps.
POWER OFF
Select Logout from the Shortcut menu and turn off the DVR at the mains
power source.
N.B Auto resume after power failure. If the DVR is shut down abnormally, the DVR
will automatically backup video and resume previous working status after the
power is restored.
MOUSE CONTROLLER
In order to prevent un-authorised tampering majority of DVR functions of are
controlled via the mouse controller.
5
