RabbitCore RCM4500W User Manual page 91

All signals from the RCM4510W module are available on header J2 of the Prototyping Board.
The remaining ports on the Rabbit 4000 microprocessor are used for RS-232 serial communica-
tion. Table B-2 lists the signals on header J2 and, where applicable, explains how they are config-
ured by the
brdInit()
Table B-2. Use of RCM4510W Signals on the Prototyping Board
Pin
1
2
3
4
5
6
7
8–15
16
17
18
19
20
21
22–23
24–25
26–27
28–29
30–31
32–39
40–47
48
49
50
There is a 1.3" × 2" through-hole prototyping space available on the Prototyping Board. The holes
in the prototyping area are spaced at 0.1" (2.5 mm). +3.3 V, +5 V, and GND traces run along the
top edge of the prototyping area for easy access. Small to medium circuits can be prototyped using
point-to-point wiring with 20 to 30 AWG wire between the prototyping area, the +3.3 V, +5 V, and
GND traces, and the surrounding area where surface-mount components may be installed. Small
holes are provided around the surface-mounted components that may be installed around the pro-
totyping area.
User's Manual
function call for use on the Prototyping Board.
Pin Name
+3.3 V +3.3 V power supply
GND
/RST_OUT Reset output from reset generator
/IORD External read strobe
/IOWR External write strobe
/RESET_IN Input to reset generator
VBAT_EXT External backup battery connection
PA0–PA7 Output, high
PB0 Output, high
PB1 Programming port CLKA
PB2 LED DS2 (normally high/off)
PB3 LED DS3 (normally high/off)
PB4 Switch S2 (normally open/pulled up)
PB5 Switch S3 (normally open/pulled up)
PB6–PB7 Output, high
PC0–PC1 Serial Port D (RS-232, header J4) (high)
PC2–PC3 Serial Port C (RS-232, header J4) (high)
PC4–PC5 Serial Port B (used by XBee RF module)
PC6–PC7 Serial Port A (programming port) (high)
PE0–PE7 Output, high
PD0–PD7 Output, high
CONVERT Not available
VREF Not available
GND
Prototyping Board Use
