Figure 8 shows the use of the Rabbit 4000 microprocessor ports in the RCM4510W modules.
PC0, PC2
PC1, PC3
PB1, PC6, STATUS
PC7, /RES,
SMODE0, SMODE1
PC4, RxD+
PC5, TxD–
The ports on the Rabbit 4000 microprocessor used in the RCM4510W are configurable, and so
the factory defaults can be reconfigured. Table 2 lists the Rabbit 4000 factory defaults and the
alternate configurations.
User's Manual
PB0
PA0–PA7
PB2–PB7
ABBIT ®
R
4000
Figure 8. Use of Rabbit 4000 Ports
PD0–PD7
PE0–PE7
/RES _ IN
/RESET_OUT,
/IORD
/IOWR
