7.7A DISCHARGE SYSTEM AND PARTS - ALL MODELS EXCEPT JOHN DEERE 160H
key
number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
(I) For complete breakdown of this sub-assembly, refer to Section 7.8A.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
description
insert, nylon tubing 1/4"od
tube, nyl .25 od x 040w wht
tube, nyl .25 od x .040w blk
adapter,receiver oil fill 185dpq
tube, 5/16 od x .040 wall
glass, sight oil level 1-1/2" pltd
conn, female pipe 1/8-27 npt
insert, nyl tubing 3/8"od
elbow, 90 3/8"tube x 1/8"npt m
elbow, 90 3/8"tube x 1/4"npt m
connector, tube oil return 1/4 x 1/4
orifice, .040" x .25m x .25m nptf
valve, inline check 1" npt ball
tube, oil siphon 1/4"od 110-185
orifice, min pressure nylon 9mm
switch, temp n.c. 250$sf, single pole
panel, frame frt 185dpq 60hp
baffle, cooler l.h. 185dpq ca 60hp
hose, hydraulic parkrimp 1-1/4 x 18
hose, hydraulic parkrimp 1" x 72lg
tbg, nylon-11 3/8"od red
tbg, nylon-11 3/8"od yellow
tbg ,nylon-11 3/8"od green
tbg, nylon-11 3/8"od blue
tbg, nylon-11 3/8"od orange
frame assembly, 185q 60hp
bumper, baffle 185q 60hp
valve, check 1/8 female - male
valve, drain 1-1/16-12unf o-ring
tank, receiver air/oil 185q pe
sub assembly, manf regulator-blowdown 185 (I)
plug, o-ring boss sae 1 1/4
ILLUSTRATIONS AND PARTS
number
02250052-841
02250054-860
02250054-861
02250064-595
02250081-220
02250081-779
- 02250097-138
02250099-052
02250099-622
02250099-626
02250108-700
02250109-215
02250109-661
02250114-091
02250121-007
02250133-513
02250134-143
02250139-756
02250139-774
02250139-778
02250139-950
02250139-951
02250139-952
02250139-953
02250139-954
02250140-184
02250140-185
02250142-248
02250142-844
02250142-979
02250148-203
040029
Continued on page 69
Section 7
part
quantity
4
2 ft.
5 ft.
1
1
1
1
5
1
1
1
1
1
1
1
1
1
1
1
1
4
2
2
5
4
1
1
1
1
1
1
1
67
