Specification
Model
LIRDCVH
Pick up Element
1/3" Omnivision 1.3MP CMOS Sensor
Effective Picture
1280 X960
Elements (H×V)
Resolution
1200TV Line
0.01 Lux/F1.2
Minimum Illumination
S/N Ratio
More than 50dB
Synchronous System
Internal, Negative sync.
IR Distance
30 Meters (with Ф5X36PCS Infrared LED)
IR Power On
Photodiode AUTO Control
Video Output
CVBS / TVI
Functions
DNR
Power/Current
DC12V(+/-10%)/700mA
Lens
2.8-12mm Manual Zoom Lens
IP Rating
Dimension (mm)
Φ131 x 93(H)
Weight (g)
800
Operating Tempera-
-10~+50℃ RH95% MAX
ture
Accessories list
Name
Camera
User Guide
/
Notes:
Number
Do not attempt to disassemble the camera. If the camera
1
can not work, please contact local franchiser or our company.
1
LIRDCVH CCTV Camera
Vandalproof IR Dome Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real Colour. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.
