  • Page 1 82-13285 High Speed PTZ Camera...
  • Page 3 Thank You for Choosing our PTZ Camera! When you open the box:  Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if any parts are either missing or damaged.  Make sure if the contents are all included as per the packing list. ...

  • Page 4: Table Of Contents

    Table of Contents Safety Notes --- Important!!! ..........................1 About The Product ............................. 2 2.1. Features..............................2 2.2. Functions ..............................2 Installation................................3 3.1. DIP Switch Setting ............................ 3 3.2. Installation............................... 10 3.2.1. In-ceiling Mount Installatoin ......................10 Operation Guide..............................12 4.1.

  • Page 5: Safety Notes

    SAFETY NOTES --- IMPORTANT!!! The following important notes must be followed carefully to run the PTZ camera and respective accessories in total safety. The camera and relative accessories are called video system in this section. Use the instructions correctly and fully Read all safety rules and instructions carefully before starting to run the video system.

  • Page 6: About The Product

    ABOUT THE PRODUCT This integrated PTZ Dome series, with built-in DSP of high performance, can combine integreated camera and decoders. It adopts pan-digital controlling, ensuring a flexible program. Reaching all-round and complete clearance monitoring in the true sense, due to high-accuracy rotating system, freely and fast position and successive track scanning.

  • Page 7: Installation

     Target is behind the glass with water drop or dust.  Target moves too fast.  Large area target such as wall.  Target is too dark or vague. IRIS control System defaults Auto IRIS. Camera can adjust immediately according to the alteration of back ground illumination so that a lightness steady image can be achieved.
  • Page 8 Pic. 1 Switch Position The camera can be controlled via various communication protocols by setting SW1 switches(1, and 2) and operate at 1200bps, 2400bps, 4800bps, 9600bps and 19200bps baud rate by setting SW1 switches(3, and 4). Refer to Table 2: SWITCH1 SETTING for communication protocol and baud rate settings, do not set the switches to reserved position.
  • Page 9 Table 3: SWITCH2 SETTING Address 5 / 19...
  • Page 10 6 / 19...
  • Page 11 7 / 19...
  • Page 12 8 / 19...
  • Page 13 9 / 19...

  • Page 14: Installation

    Table 3: SWITCH2 SETTING  Always use the “ PELCO P”or “ PELCO D”protocols.  It is advisable to select PELCO-D protocol at 9600 bps baud rate to ensure the correct operation of the camera with the compatible products in the catalogue. ...
  • Page 15 Step 8 Step 9 Step 10 Step 11 11 / 19...

  • Page 16: Operation Guide

    OPERATION GUIDE 4.1. OPERATION AT POWER UP The camera employs the default settings the first time it is switched on. Changes to the settings will be permanently stored and will be made available the next time the camera is switched on. You can return to the default settings by means of the appropriate menu option at any time.

  • Page 17: Function Program Menu

    Control panel command Function Accesses main menu PRESET ENTER Stores preset position (Preset) xxx. PRESET ENTER Recalls preset position (Preset) xxx. CALL ENTER Starts the cruise function CALL ENTER Delete all Presets CALL ENTER Start pattern 1 CALL ENTER Start pattern 2 CALL ENTER Start pattern 3...

  • Page 18: System Information

    CAMERA Camera parameter programming submenu CRUISE SETTING Cruise programming submenu(refer to Section 4.2.5. ). DISPLAY SETUP used to enable the labels to be displayed for the various camera functions. This performs a total reset and loads the default settings. The operations may RESTORE FACTORY DEFAULT take a few seconds (approximately 20 seconds): the message “...
  • Page 19 MOTION <SET FRAME SCAN> POWER UP PATTERN 4 PARK TIME PARK ACTION PATTERN 4 FRAME SCAN SPEED BACK EXIT Screen 4: MOTION Option Value Explanation NONE No action is performed at the end of power up. The camera performs an auto scan at the end of power up: the AUTO SCAN camera performs a 360 horizontal scan operation.

  • Page 20: Pattern

    Point the cursor to the label to be moved by moving the joystick vertically. Press OPEN chose the Value using the joystick. Press OPEN. 4.2.3.1. SET FRAME SCAN Point the cursor to the label” SET FRAME SCAN” by moving the joystick vertically. Press OPEN TO NEXT STEP: FRAME SCAN SET SCAN POSITION CLEAR FRAME SCAN...

  • Page 21: Cruise

    PATTERNS PATTERN NUMBER <PROGRAM PATTERN> CLEAR CURRENT PATTERN CLEAR ALL PATTERN BACK EXIT Screen 8: PATTERNS A pattern is a sequence of movements and functions which may be stored and repeated manually or automatically. Option Value Explanation PATTERN NUMBER 1 ~ 4 This option is used to select a pattern.

  • Page 22: Trouble Shooting

    DWELL TIME <SECS> 5 ~ 250 Duration (in seconds) of the dwelling time on each presetting. Value 1 selects the first group of Presets from 1 to 10, value 2 selects the second group from 11 to 20, value 3 selects the third group from 21 to 30.
  • Page 23 9. Do not install the camera near the air conditioner outlet. In the following cases, the lens because of water vapor condensation born fog. from the air conditioner off when you open when the high and low temperatures caused by the rapid change.
