USB to 4-Port RS-232 Converter
Warranty
All products manufactured by ICP DAS are warranted against
defective materials for a period of one year from the date of delivery
to the original purchaser.
Warning
ICP DAS assumes no liability for damages consequent to the
use of this product. ICP DAS reserves the right to change this
manual at any time without notice. The information furnished by ICP
DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, or for any
infringements of patents or other rights of third parties resulting from
its use.
Copyright
Copyright 2012 by ICP DAS Co., LTD. All rights reserved
worldwide.
Trademark
The names used for identification only may be registered
trademarks of their respective companies.
USB-2514
User Manual
1
USB-2514 Series User Manual
Publication Jun, 2013 Ver. 1.01
Advertisement
Table of Contents
Related Manuals for ICP DAS USA USB-2514 Series
Summary of Contents for ICP DAS USA USB-2514 Series
- Page 1 USB-2514 Series User Manual USB to 4-Port RS-232 Converter USB-2514 User Manual Warranty All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for damages consequent to the use of this product.
- Page 2 USB-2514 Series User Manual Introduction USB-2514 is USB to 4-Port RS-232 converter that provides a simple way add up to four RS-232 ports on your PC. The USB-2514 is support USB 1.1, USB 2.0 standards and easy setting RS-232 transmission speed from 300 bps to 921600 bps.
-
Page 3: Dimensions (Unit: Mm)
USB-2514 Series User Manual Dimensions (Unit: mm): Specifications: Interface Compatibility: USB 1.1 and 2.0 standards RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND Speed 300 bps ~ 921600 bps RS-232 DB9 male x 4 Connector B Type Software... -
Page 4: Usb Driver Installation
USB-2514 Series User Manual USB driver installation Microsoft Windows XP Download driver files from Package CD, \NAPDOS\USB-2514\ Vx.xx.xx ftp://ftp.icpdas.com/pub/cd/usbconverter/napdos/ Manually install USB driver Step1. Please execute “USB-2514_tM-7561_Driver.exe“ (the driver file name for v2.08.24 or newer) file first to install necessary driver files of USB-2514 to system. - Page 5 USB-2514 Series User Manual Step4. Select “Install the software automatically (Recommended)”. → Select “Next”. Step5. If it is pop-up a new windows that “Hardware Installation”, please select “Continue Anyway”. Publication Jun, 2013 Ver. 1.01...
- Page 6 USB-2514 Series User Manual Step6. Select “Finish” to finish. Repeat Step3 to Step6 for each other ports. (Must be repeated four loops). Step7. Select “No, not this time”. → Select “Next”. Publication Jun, 2013 Ver. 1.01...
- Page 7 USB-2514 Series User Manual Step8. Select “Install the software automatically (Recommended)”. → Select “Next”. Step9. If it is pop-up a new windows that “Hardware Installation”, please select “Continue Anyway”. Publication Jun, 2013 Ver. 1.01...
- Page 8 USB-2514 Series User Manual Step10. Select “Finish” to finish. Repeat Step7 to Step10 for each other ports. (Must be repeated four loops). Step11. Please open “Device Manager”. → check com. Publication Jun, 2013 Ver. 1.01...
