ETC Net3 Conductor Setup Manual

ETC Setup Guide
®
Net3 Conductor Network Services Gateway
Overview
Net3 Conductor Network Services Gateway provides powerful and flexible control for integrated
lighting systems. This setup guide will guide you through the setup of the Net3 Conductor
including hardware, electrical and data connections, unit power up, and connection to the built-
in web interface.
Features
Net3 Conductor provides the following features:
• A central repository for all system configurations
• Multiple network services for simple network lighting system integration.
• Logging of real-time errors.
• Reporting tools providing access to historical errors using user defined filters.
• Real-time logging and notification of system errors using e-mail or SMS messaging.
• Conductor is configured using the built-in web interface or its companion software, Net3
Concert.
• On board LCD displaying information including the firmware version number, current date,
time and time zone, IP address and system uptime. Additional displays include indication of
firmware update processing.
Help from ETC Technical Services
If you experience difficulty during setup or installation of the Net3 Conductor, additional
information is available from
nearest office to you; contact information is listed below.
Setup and Connect
General Use
Note:
Net3 Conductor ships standard with non-slip padded feet for use on a table top. Alternatively, the
unit can be installed into a standard 19" rack enclosure when used with the included 1U Half
Width Rack Mount Kit (4260K1001).
Corporate Headquarters
London, UK Tel +44 (0)20 8896 1000

Rome, IT Tel +39 (06) 32 111 683

Holzkirchen, DE
Hong Kong Tel +852 2799 1220

Web: www.etcconnect.com
4266M2200 Rev C

Net3 Conductor Setup Guide
www.etcconnect.com
The Net3 Conductor unit must be mounted in a rack in a horizontal flat
orientation, or flat on a table top.
Middleton, WI, USA Tel +608 831 4116
 
Service: (UK)

Service: (UK) service@etceurope.com

Tel +49 (80 24) 47 00-0 Service: (DE)
 
Service: (Asia) service@etcasia.com

© 2015 ETC. All Rights Reserved.

Released 2015-03 ETC intends this document to be provided in its entirety.
 
or by contacting ETC Technical Services at the
Service: (Americas)

service@etceurope.com
techserv-hoki@etcconnect.com
Product information and specifications subject to change.

Page 1 of 4
service@etcconnect.com
Electronic Theatre Controls, Inc.
