  • Page 1 Liebert® PSI XR™ 1000/1500/2200/3000, 120VAC User Manual...
  • Page 2 Technical Support Site If you encounter any installation or operational issues with your product, check the pertinent section of this manual to see if the issue can be resolved by following outlined procedures. Visit https://www.VertivCo.com/en-us/support/ for additional assistance.

  • Page 3: Table Of Contents

    6.2.1 Any Mode Shutdown Via Pins 5 & 6 6.2.2 Battery Mode Shutdown Via Pins 4 & 5 6.3 Network Surge Protection Connectors 6.4 UPS Communications 6.5 UPS Inverter/Transfer Voltage Configurations 7 Battery Maintenance 7.1 Battery Charging, Storage Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 4 7.2 Internal Battery Replacement Procedure 8 Specifications 9 Troubleshooting Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 5: Important Safety Instructions

    Never block or insert any objects into the ventilation holes or other openings of the UPS. Keep all vents free of dust accumulation that could restrict air flow. Do not place UPS power cord anywhere it might be damaged. Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 6 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 7: Glossary Of Symbols

    Indicates caution followed by important instructions Indicates the unit contains a valve-regulated, lead-acid battery Recycle DC voltage Equipment grounding conductor Bonded to ground AC voltage ON/Alarm Silence/Manual Self-Diagnostic Test Status Change Button Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 8 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 9: Introduction

    Liebert shutdown software. Figure 1.1 Front view of UPS Figure 1.2 1000 and 1500VA—rear view Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 10 Figure 1.3 2200 and 3000VA—rear view Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 11: What's Included

    Input Power Cord, 2200/3000 only: 2 • IEC Output Cable, 1000/1500 only: 2 • IEC Output Cable, 2200/3000 only: 3 • Tower Stand • Rack-Mount Handles • Battery-UPS Tab Figure 2.1 Accessories Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 12 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 13: Installation

    3 INSTALLATION 3.1 Preparation Inspect the UPS for freight damage. Report any damage to the carrier and your local dealer or Vertiv representative. CAUTION: Risk of injury from heavy unit. May cause equipment damage or personal injury. The UPS and battery cabinets are heavy (see Table 8.1 on page 27 and Table 8.2 on page 28).

  • Page 14: Rack-Mount Ups Conversion And Installation

    3.3 Rack-Mount UPS Conversion and Installation See Figure 3.3 on the facing page when installing the Liebert PSI XR in a rack. External battery cabinets are installed in racks in the same manner. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 15: Orient Display For Installation

    The Liebert PSI XR features a rotating display that may be oriented for either tower or rack installations. To set the display for your installation, pull out on the display and rotate it until it is oriented correctly, then press it into the UPS until it is seated. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 16: Charge Batteries And Perform Battery Startup

    Figure 3.4 Orienting the UPS display 3.5 Charge Batteries and Perform Battery Startup Before connecting input power or connecting the load, Vertiv recommends these steps: • Charge the battery for at least 8 hours. • Start the UPS on battery to ensure the battery is fully functional and charged.

  • Page 17: Connect Network Surge Protection

    Connect a 10 base-T/100 network cable to the RJ-45 network surge protection IN jack on the rear of the UPS. Connect from the OUT jack with network cabling to network equipment (see Figure 3.6 below). Figure 3.6 Connect network surge protection Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 18: Connect Computer Interface Port

    USB port on the computer. See the Liebert MultiLink user manual for operating instructions. Vertiv recommends connecting the USB cable directly to the computer WITHOUT using a USB hub. 3.10 EPO Switch The Liebert PSI XR is equipped with an Emergency Power Off (EPO) switch. The user must supply a...

  • Page 19: External Battery Cabinet Installation

    External battery cabinet connectors are color-coded as noted in Table 3.1 on the next page. Do not try to install external battery cabinets with connectors that are a different color from the battery connector on the UPS. Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 20 Nominal System Voltage (connector color) External Battery Cabinet Model PS1000RT3-230XR 24VDC (Red) PSRT3-24VBXR PS1500RT3-230XR PS2200RT3-230XR 48VDC (Gray) PSRT3-48VBXR PS3000RT3-230XR Figure 3.10 Connect battery cabinets to UPS See Table 8.3 on page 29 for approximate battery run times. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 21: Controls And Indicators

    UPS Operation in Battery Mode LED 11 UPS Fault UPS Fault 4.1 Control Buttons 4.1.1 On/Alarm Silence/Manual Self-Diagnostic Test This button controls output power to connected load(s). It has three functions: • • Alarm Silence Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 22: Off Button

    If LED still indicates that the battery is weak after the battery has been retested, contact your local dealer, local Vertiv representative or Liebert Applications. • If LED indicates a Battery Fault: Contact your local dealer, Vertiv representative or Liebert Applications. •...

  • Page 23: Battery Level Indicator

    LED 11 Green Normal Mode Steady Green Green AVR Boost Flashes Steady Green Green AVR Buck Flashes Steady Battery Mode Yellow (dark start) Steady Yellow Weak Battery Flashes Yellow Site-Wiring Fault Flashes Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 24 LED 2 LED 3 LED 4 LED 5 LED 9 LED 10 LED 11 Overload Flashes Battery Fault Yellow Shutdown Steady Steady Overload Shutdown Steady Steady UPS Output Yellow Abnormal Steady Steady Shutdown Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 25: Operational Modes

    For approximate battery run times, refer to Table 8.3 on page 29. 5.4 Battery Recharge Operation Once mains power is restored, the UPS resumes normal operation, and the Battery Charger begins recharging the batteries. Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 26 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 27: Communication

    When Pin 6 is shorted to Pin 5, the UPS output is shut Off no matter what mode the UPS is operating. The UPS cannot be started as long as the pins are shorted. When the short is removed, the UPS output can be enabled by pressing the ON/Alarm Silence/Manual Self-Diagnostic Test button. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 28: Battery Mode Shutdown Via Pins 4

    The factory default setting is 230 VAC. Figure 6.1 DIP switch settings for 230V system Table 6.2 Voltage configurations Setting Input Voltage Range Output Voltage (Battery Mode) 165~275 220VAC 173~288 230VAC 180~300 240VAC Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 29: Battery Maintenance

    7. Unpack the new battery assembly, taking care not to destroy the packing. 8. Compare the new and old battery assemblies to make sure they are the same. If so, proceed with replacement. If they are different, STOP and contact your local dealer, Vertiv representative or Liebert Applications.
  • Page 30 Figure 7.1 Battery replacement Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 31: Specifications

    5 hours to 90% of rated capacity, after full discharge into resistive load Battery Backup Time Full Load 5 min. Half Load 10 min. Environmental Operating Temperature, °C (°F) 0 to 40 (32 to 104) Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 32 Relative Humidity 0% to 90%, non-condensing Maximum Operating Altitude 3000m (10,000 ft.) at 35°C (95°F) without derating Agency Safety IEC/EN/AS 62040-1-1 Emissions IEC/EN/AS 62040-2 2nd Ed Class A Transportation ISTA Procedure 1A Certification Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 33 Internal Battery + 5 External Battery Cabinets 1140 Internal Battery + 6 External Battery Cabinets Run times are in minutes, assume fully charged batteries and are typical at 77°F (25°C) with resistive loads. Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 34 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...

  • Page 35: Troubleshooting

    Consult the Liebert shutdown software user manual or contact your LAN Liebert shutdown software administrator. Batteries weak Recharge batteries. Battery Weak LED (LED 3) flashing Batteries need to be replaced Replace batteries. NOTES Vertiv | Liebert® PSI XR™ User Manual |...
  • Page 36 This page intentionally left blank. Vertiv | Liebert® PSI XR™ User Manual |...
