- Page 1 Liebert® PSI™ 750/1000/1500/1920/3000VA, 60Hz, 120VAC User Manual...
- Page 2 Technical Support Site If you encounter any installation or operational issues with your product, check the pertinent section of this manual to see if the issue can be resolved by following outlined procedures. Visit https://www.VertivCo.com/en-us/support/ for additional assistance.
-
Page 3: Table Of Contents
6.2.2 Battery Mode Shutdown Via Pins 4 & 5 6.3 Network Surge Protection Connectors 6.4 UPS Communication 6.5 UPS Inverter/Transfer Voltage Configurations 7 Battery Maintenance 7.1 Battery Charging, Storage 7.2 Internal Battery Replacement Procedure Vertiv | Liebert® PSI™ User Manual |... - Page 4 8 Specifications Vertiv | Liebert® PSI™ User Manual |...
-
Page 5: Important Safety Instructions
Never block or insert any objects into the ventilation holes or other openings of the UPS. Keep all vents free of dust accumulation that could restrict air flow. Do not place UPS power cord anywhere it might be damaged. Vertiv | Liebert® PSI™ User Manual |... - Page 6 “critical” devices. Maximum load must not exceed that shown on the UPS rating label. If uncertain, consult your local dealer, local Vertiv representative or Channel Support Applications. When installing the UPS or making input and output connections, comply with all relevant safety codes and standards (e.g., UL 1778).
- Page 7 NOTICE Do not connect equipment that could overload the UPS or demand half-wave rectification from the UPS, such as electric drills, vacuum cleaners, laserjet printers and hair dryers. Vertiv | Liebert® PSI™ User Manual |...
- Page 8 This page intentionally left blank. Vertiv | Liebert® PSI™ User Manual |...
-
Page 9: Glossary Of Symbols
Risk of electrical shock Indicates caution followed by important instructions Indicates the unit contains a valve-regulated, lead-acid battery Recycle DC voltage Equipment grounding conductor Bonded to ground AC voltage ON/Alarm Silence/Manual Self-Diagnostic Test Status Change Button Vertiv | Liebert® PSI™ User Manual |... - Page 10 This page intentionally left blank. Vertiv | Liebert® PSI™ User Manual |...
-
Page 11: Introduction
Liebert MultiLink™ shutdown software. Figure 1.1 Front view of UPS, rack mount Figure 1.2 1000 and 1500VA—rear view Vertiv | Liebert® PSI™ User Manual |... - Page 12 Figure 1.3 1920VA—rear view Figure 1.4 3000VA—rear view Vertiv | Liebert® PSI™ User Manual |...
-
Page 13: What's Included
Liebert MultiLink Shutdown Software and User Manual on CD • Contact Closure (ML9P9S) Cable • USB Cable • Tower Stand • Rack-Mount Handles • Battery-UPS Tab • Mounting Hardware • Fixed Mounting Rails • EPO Connector Figure 2.1 Accessories Vertiv | Liebert® PSI™ User Manual |... - Page 14 This page intentionally left blank. Vertiv | Liebert® PSI™ User Manual |...
-
Page 15: Installation
32°F to 104°F (0°C to 40°C). Figure 3.1 Placing the Liebert PSI 3.2 Tower UPS Installation See Figure 3.2 on the next page when using the Liebert PSI in a tower configuration. Vertiv | Liebert® PSI™ User Manual |... -
Page 16: Rack-Mount Ups Conversion And Installation
Figure 3.2 Tower configuration—attach Tower Stand 3.3 Rack-Mount UPS Conversion and Installation See Figure 3.3 on the facing page when installing the Liebert PSI in a rack. Vertiv | Liebert® PSI™ User Manual |... -
Page 17: Orient Display For Installation
The Liebert PSI features a rotating display that may be oriented for either tower or rack installations. To set the display for your installation, pull out on the display and rotate it until it is oriented correctly, then press it into the UPS until it is seated. Vertiv | Liebert® PSI™ User Manual |... -
Page 18: Charge Batteries And Perform Battery Startup
Figure 3.4 Adjusting the UPS display 3.5 Charge Batteries and Perform Battery Startup Before connecting input power or connecting the load, Vertiv recommends these steps: • Charge the battery for at least 8 hours. • start the UPS on battery to ensure the battery is fully functional and charged. -
Page 19: Connect Network Surge Protection
Connect a 10 base-T/100 network cable to the RJ-45 network surge protection IN jack on the rear of the UPS. Connect from the OUT jack with network cabling to network equipment (see Figure 3.6 below). Figure 3.6 Connect network surge protection Vertiv | Liebert® PSI™ User Manual |... -
Page 20: Connect Computer Interface Port
USB port on the computer. See the Liebert MultiLink user manual for operating instructions. NOTE: Vertiv recommends connecting the USB cable directly to the computer WITHOUT using a USB hub. Vertiv | Liebert® PSI™ User Manual |... -
Page 21: Epo Switch
EPO circuit to allow disconnecting the UPS input feeder breaker to interrupt all sources of power to the UPS and connected equipment to comply with national and local wiring codes and regulations. Figure 3.8 EPO connection for normally open operation Vertiv | Liebert® PSI™ User Manual |... - Page 22 This page intentionally left blank. Vertiv | Liebert® PSI™ User Manual |...
-
Page 23: Controls And Indicators
UPS Operation in Battery Mode LED 11 UPS Fault UPS Fault 4.1 Control Buttons 4.1.1 On/Alarm Silence/Manual Self-Diagnostic Test This button controls output power to connected load(s). It has three functions: • • Alarm Silence Vertiv | Liebert® PSI™ User Manual |... -
Page 24: Off Button
If LED still indicate battery weak after the battery has been retested, contact your local dealer, Vertiv representative or Liebert Applications. • If LED indicates a Battery Fault: Contact your local dealer, Vertiv representative or Liebert Applications. • If LED indicates UPS Fault: Remove the load, retest the self diagnostic test, if LED indicated UPS Fault, Contact your local dealer, Vertiv representative or Liebert Applications. -
Page 25: Battery Level Indicator
LED 10 LED 11 Green Normal Mode Steady Green Green AVR Boost Flashes Steady Green Green AVR Buck Flashes Steady Battery Mode Yellow (dark start) Steady Yellow Weak Battery Flashes Yellow Site-Wiring Fault Flashes Vertiv | Liebert® PSI™ User Manual |... - Page 26 LED 2 LED 3 LED 4 LED 5 LED 9 LED 10 LED 11 Overload Flashes Battery Fault Yellow Shutdown Steady Steady Overload Shutdown Steady Steady UPS Output Yellow Abnormal Steady Steady Shutdown Vertiv | Liebert® PSI™ User Manual |...
-
Page 27: Operational Modes
Refer to Table 8.1 on page 29 for approximate battery run times. 5.4 Battery Recharge Operation Once utility power is restored, the UPS resumes normal operation and the Battery Charger begins recharging the batteries. Vertiv | Liebert® PSI™ User Manual |... - Page 28 This page intentionally left blank. Vertiv | Liebert® PSI™ User Manual |...
-
Page 29: Communication
6.2.2 Battery Mode Shutdown Via Pins 4 & 5 While the UPS is operating on battery, a 5-12VDC signal for 2 seconds or longer is required to signal a shutdown. Signals for less than 2 seconds are ignored. Vertiv | Liebert® PSI™ User Manual |... -
Page 30: Network Surge Protection Connectors
It also changes the UPS’ output voltage when the UPS is operating in battery mode. The factory default setting is 120 VAC. Figure 6.1 DIP switch settings for 120V system Table 6.2 Voltage configurations Setting Input Voltage Range Output Voltage (Battery Mode) 83~138 110VAC 90~150 120VAC 96~159 127VAC Vertiv | Liebert® PSI™ User Manual |... -
Page 31: Battery Maintenance
7. Unpack the new battery assembly, taking care not to destroy the packing. 8. Compare the new and old battery assemblies to make sure they are the same. If so, proceed with replacement. If they are different, STOP and contact your local dealer, Vertiv representative or Liebert Applications. - Page 32 Figure 7.1 Battery replacement Vertiv | Liebert® PSI™ User Manual |...
- Page 33 Shutdown after 10 Minutes >120% Shutdown UPS Immediately >100% - 119% Continuous Overload Alarm Till End of Battery Discharge Battery Mode >120% - 130% Shutdown After 10 Seconds >130% Shutdown UPS Immediately Battery Parameters Vertiv | Liebert® PSI™ User Manual |...
- Page 34 *NEC limits the input current rating of the PS2200RT3-120XR and PS2200RT3120XRW models to 80% of the input plug's rating. Up to 2200VA/1980W is available by contacting a certified electrician to change the input plug to 30A plug. Vertiv assumes no liability for damage caused by miswiring or misapplication of the input plug.
- Page 36 VertivCo.com | Vertiv Headquarters, 1050 Dearborn Drive, Columbus, OH, 43085, USA © 2017 Vertiv Co. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co.
