- Page 1 © LAI GAMES www.laigames.com ► READ THIS MANUAL BEFORE OPERATING THE MACHINE. ► KEEP THIS MANUAL FOR YOUR REFERENCE.
- Page 2 LAI GAMES Correspondence regarding this machine should be addressed to your closest LAI GAMES office, or LAI GAMES Distributor. For contact details, refer to the back page of this manual. DISCLAIMER Please be aware that this software may not be legal to operate in some states and countries.
- Page 3 LAI GAMES NOTES Dear Customer, Keep up-to-date with any new Software release or Service Bulletins for this Game. Check our Website at www.laigames.com and click on Product Support, here you will find links to all the Bulletins and Software Updates to keep your game in top working order.
-
Page 4: Table Of Contents
Operator's Manual – FireFighter © LAI GAMES TABLE OF CONTENTS SAFETY PRECAUTIONS ..................1 INTRODUCTION ..................... 2 SPECIFICATIONS ....................3 MACHINE INSTALLATION INSPECTION ........... 4 ASSEMBLY INSTRUCTIONS ................. 5 WATER SYSTEM ..................... 6 WATER SYSTEM DIAGRAM ................. 7 HOW TO PLAY ......................8 OPERATION ....................... - Page 5 BASIC OPERATION .................... 39 SPECIFICATIONS ....................41 TD-963CR SCHEMATIC DIAGRAM ..............42 DISPENSER PARTS DIAGRAM................43 3 D EXPLODE PARTS .................... 44 FIREFIGHTER MAIN WIRING DIAGRAM ............49 FIREFIGHTER BASE WIRING DIAGRAM ............50 FIREFIGHTER POWER WIRING DIAGRAM ............51...
-
Page 6: Safety Precautions
Operator's Manual – FireFighter © LAI GAMES SAFETY PRECAUTIONS The following safety precautions and advisories are used throughout this manual and are defined as follows. * WARNING! * Disregarding this text could result in serious injury. * CAUTION! * Disregarding this text could result in damage to the machine. -
Page 7: Introduction
INTRODUCTION CONGRATULATIONS! You have just bought the “Fire Fighter”, another sensational product from LAI GAMES. This game, based around the popular kids water game style, has many new features. “Fire Fighter” features two player or single player game play, an impressive main display, backlit targets, and robust and reliable water Cannon guns. -
Page 8: Specifications
Operator's Manual – FireFighter © LAI GAMES SPECIFICATIONS DIMENSIONS Weight: 240 kg (530lb) [Empty of water] Height: 2049mm (80-6/8”) Width: 1082mm (42-1/2”) Length: 1615mm (63-1/2”) Power: 660 W – (220V @ 3.0 A)(120V @ 5.5 A) Maximum 380 W –... -
Page 9: Machine Installation And Inspection
Boards. If any integrated circuit (IC) logic PC Boards should need servicing. Please contact the nearest LAI GAMES distributor. (Refer to the back page of this manual) * CAUTION! * Water needs to be added to the game BEFORE running the pumps. -
Page 10: Assembly Instructions
Operator's Manual – FireFighter © LAI GAMES ASSEMBLY INSTRUCTIONS The “Fire Fighter” is shipped in two main sections, the Upper Cabinet, containing most of the controlling electronics and the Lower Cabinet, containing the water system and player controls. The game should not be shipped fully assembled as this could cause damage to the Both Cabinets. -
Page 11: Water System
Operator's Manual – FireFighter © LAI GAMES WATER SYSTEM The “Fire Fighter” is a water style game and requires regular maintenance and cleaning to keep the water in good condition. The game needs 20 liters (5 Gallons) of water to operate effectively. The machine should be emptied of any water before moving or shipping to prevent spillage. -
Page 12: Water System Diagram
Operator's Manual – FireFighter © LAI GAMES WATER SYSTEM DIAGRAM As viewed from front Yellow Player Blue Player Targets Targets Blue Player Yellow Player Water Canon Water Canon Wash-Down Stop Valve Drain Stop Valve Blue Player Stop Valve Yellow Player... -
Page 13: How To Play
Operator's Manual – FireFighter © LAI GAMES HOW TO PLAY THE PLAYER’S AIM IS TO REACH THE 99 POINTS FIRST BY AIMING THE WATER STREAM AT THE LIT TARGETS INSIDE THE PLAYERS FIRE HYDRANT Insert coin/s. (The exact amount of coins per play is dependant on Program settings P1 through to P4. -
Page 14: Operation
Operator's Manual – FireFighter © LAI GAMES OPERATION The “Fire Fighter” game has six operational modes: Attract mode, Play mode, Test Mode, Programmable Adjustments Mode, Audits Mode and Game History Mode. OPERATIONAL DIAGRAM POWER UP ATTRACT MODE PLAY MODE PRESS TEST... -
Page 15: Test Mode
Operator's Manual – FireFighter © LAI GAMES TEST MODE The Fire Fighter Test mode has Three Test Configurations allowing you to test the function of the Sound, all Game Lamps, Displays, the Game Switches, Pump Motors and the Water Cannon action. (Refer to the Test Mode Diagram below). -
Page 16: Sound, Lamps & Display Test
Operator's Manual – FireFighter © LAI GAMES SOUND, LAMPS & DISPLAY TEST ENTER The Sound, Lamp & Display test is entered from Attract mode by pressing the test button once. * NOTE! * If there is an active error displayed, press the red test button once to try and clear the error. - Page 17 Operator's Manual – FireFighter © LAI GAMES TICKET DISPENSER NOTCH The Ticket Notch Switch (C1 & C2) can be activated or deactivated from the Ticket Feed Button on the Ticket Dispenser PCB or by manually pushing the tickets from the ticket holder through the dispenser after pulling the ticket release...
-
Page 18: Run Test
Operator's Manual – FireFighter © LAI GAMES RUN TEST ENTER The Run Test mode is entered from switch test by pressing the Test button once or from Attract mode by pressing the Test button three times. This will prompt the code on the 3-digit display indicating the program mode. -
Page 19: Programmable Adjustments Mode
Operator's Manual – FireFighter © LAI GAMES PROGRAMMABLE ADJUSTMENTS MODE The Fire Fighter has thirteen programmable adjustments that can be changed in this mode. They are P01 to P13 and their codes and values are displayed alternatively during the adjustment procedure. -
Page 20: Programmable Adjustments Quick Reference Table
Operator's Manual – FireFighter © LAI GAMES PROGRAMMABLE ADJUSTMENTS QUICK REFERENCE TABLE PROGRAMMABLE OPTIONAL DEFAULT CODE FEATURES ADJUSTMENTS VALUES SETTINGS 1 – 10 1, 2, 3…10 Coin Slot 1 – Coins / Credit 1 – 10 1, 2, 3…10 Coin Slot 1 – Games / Credit 1 –... -
Page 21: Programmable Adjustments Detailed
Operator's Manual – FireFighter © LAI GAMES PROGRAMMABLE ADJUSTMENTS DETAILED P01=COIN MECH 1: NUMBER OF COINS PER CREDIT (Default 01) (Adjustable 1 – 10) This variable sets the number of coins that need to be inserted into coin mechanism 1, for each credit. It can be set to either of 1, 2, 3… to 10 coins for one credit. - Page 22 Operator's Manual – FireFighter © LAI GAMES P08= NUMBER OF TICKETS SINGLE PLAYER GAME LOSER (Default 6) (Adjustable from 0 to 100) This setting is the number of tickets the game dispenses when a player who has played a single player game loses the game because the computer controlled player by puts out all the fires (reaching 99 points) before the player does.
-
Page 23: Audits Mode
Operator's Manual – FireFighter © LAI GAMES AUDITS MODE The Audits Mode allows the operator to view statistics in all areas of the Game Play. This enables the operator to make calculated adjustments and “Fine Tune” the machine to maximize earning potential. The Audits mode stores bookkeeping of the games processed since the last game audits reset. -
Page 24: Audit Procedure
Operator's Manual – FireFighter © LAI GAMES AUDIT PROCEDURE ENTER The Audits mode is entered from Programmable Adjustments mode by pressing the Test button once or from Attract mode by pressing the A A A Test button five times. -
Page 25: Audits Quick Reference Table
Operator's Manual – FireFighter © LAI GAMES AUDITS QUICK REFERENCE TABLE CODE DISPLAY AUDIT FUNCTION Total Number of Games Played A 0 1 Total Number of Single Player Games A 0 2 Total Number of Multi Player Games A 0 3... -
Page 26: Audits Detailed
Operator's Manual – FireFighter © LAI GAMES AUDITS DETAILED A01 = TOTAL NUMBER OF GAMES PLAYED This Audit displays the total number of games played on this machine since the audits were last cleared (including service games). A02 = TOTAL NUMBER OF SINGLE PLAYER GAMES This Audit displays the Total Number of Single Player Games started since the audits were last cleared. - Page 27 Operator's Manual – FireFighter © LAI GAMES A09 = TOTAL NUMBER OF TIMES A SINGLE PLAYER ON BLUE LOST This Audit displays the total number times a player on blue has lost in the single player mode since the audits were last cleared. Single Player mode is selected by pressing Only the Yellow or Blue Start buttons on the control panel at the start of a game.
- Page 28 This Audit displays the total number of service credits that were given since the audits were last cleared. * NOTE! * LAI Games Customer Support may request from the operator the values of these Manufacturers audits, to help with any service issues. Page 23...
-
Page 29: Game History Mode
Operator's Manual – FireFighter © LAI GAMES GAME HISTORY MODE By using the Game History Mode the operator can view the results of the last 5 games played. This enables the operator to verify tickets paid for a win / lose. -
Page 30: Game History Procedure
Operator's Manual – FireFighter © LAI GAMES GAME HISTORY PROCEDURE ENTER The Game History mode is entered from Audits mode by pressing the Test button once or from Attract mode by pressing the Test button six H H H times. -
Page 31: Errors And Troubleshooting
Operator's Manual – FireFighter © LAI GAMES ERRORS AND TROUBLESHOOTING If the Game microprocessor detects any problems with the operation of the game, an Error will be displayed on the 3-digit display and the machine will play a voice message. “Please Call the Attendant”. Some error Messages will only be displayed E r r X when test mode is entered. - Page 32 EEPROM, If still Error massage, this could be a problems with the game audits and program. If this error occurs, send your main MCU PCB to the nearest authorized LAI games dealer for repair. Err4 – TARGET SENSOR JAM This error occurs if one or more of the target sensors are continuously active.
-
Page 33: Fuse Information
Operator's Manual – FireFighter © LAI GAMES FUSE INFORMATION * WARNING! * Always turn OFF Mains power and unplugged the game, before replacing any fuses. MAIN AC SUPPLY FUSE (1 x 6 AMP FAST BLOW, M205 TYPE) This fuse is for the main AC supply and is situated in the IEC mains input socket. -
Page 34: Section A: Service Instructions
Operator's Manual – FireFighter © LAI GAMES SECTION A: SERVICE INSTRUCTIONS BE SURE TO READ THE FOLLOWING Carefully before servicing this machine Page 29... -
Page 35: Locating And Accessing Parts
Operator's Manual – FireFighter © LAI GAMES LOCATING AND ACCESSING PARTS PARTS LOCATION DIAGRAM As viewed from front Acrylic Header Three Digit (Mylar) Time Display Yellow Player Blue Player Level Display Level Display Yellow Player Blue Player Hose Lamps Hose Lamps... -
Page 36: Locating And Accessing Parts
Operator's Manual – FireFighter © LAI GAMES LOCATING AND ACCESSING PARTS PARTS LOCATION DIAGRAM B As viewed from rear Fluorescent Fluorescent Lamps Ballasts Fluorescent 3-Digit Starters Display PCB Game MPU 8 Channel AC Driver PCB Game Sound 24VAC Level Lamps... -
Page 37: Parts Description
Operator's Manual – FireFighter © LAI GAMES PARTS DESCRIPTION COIN MECHANISMS The coin mechanisms can be accessed inside the front center door in the center of the machine cabinet. CASH BOX The cash box is located inside the coin door on the front of the machine cabinet. - Page 38 Operator's Manual – FireFighter © LAI GAMES POWER CORD The power cord is a standard IEC power cord (as used on computers) that is plugged in to the power inlet socket at the rear of the machine. The power cord can be removed for transport.
-
Page 39: Lamps
Operator's Manual – FireFighter © LAI GAMES LAMPS * WARNING! * Always turn OFF Mains power and unplugged the game, before replacing any lamps. Always allow time for cooling as Lamps that have been active for a time may still be too hot to touch. -
Page 40: Maintenance
Operator's Manual – FireFighter © LAI GAMES MAINTENANCE CLEANING AND CHECK UP EXTERIOR Regularly dust and clean the external cabinet areas as required, using a soft water-damp cloth and mild soap. Check for blown bulbs and replace as required. -
Page 41: Section B: Technical Details
Operator's Manual – FireFighter © LAI GAMES SECTION B: TECHNICAL DETAILS It is advised that anybody using SECTION B for repairing or modifying any of the components of the game should be a qualified technician, having at least a basic knowledge of digital components, integrated circuits and electricity. -
Page 42: Mains Voltage Adjustment
Operator's Manual – FireFighter © LAI GAMES MAINS VOLTAGE ADJUSTMENT POWER SUPPLY The Switch Mode Power Supply has a switch to set the mains voltage range. It is located at the rear of the game cabinet, and is accessed via the back door. Use a... - Page 43 Operator's Manual – FireFighter © LAI GAMES FLORESCENT TUBE BALLASTS AND STARTERS Locate the florescent tube ballasts and starters in the back of the cabinet. If unsure of the location of any ballasts or starters, refer to Parts location diagram on page 30.
-
Page 44: Ticket Dispenser Reference Guide
Operator's Manual – FireFighter © LAI GAMES TICKET DISPENSER REFERENCE GUIDE The ENTD-2000 Ticket Dispenser has been designed with features that virtually eliminate ticket jams. It requires very little maintenance, making it the most reliable and compatible ticket dispenser on the market today. This guide is designed to explain the basic functions and specifications of the ticket dispenser. - Page 45 Operator's Manual – FireFighter © LAI GAMES CLEARING TICKET JAMS 1. Gently pull any tickets that are between the rollers and front plate out the front of the unit. 2. Lift the upper rollers by pulling the latch bar back into the unlock position.
-
Page 46: Specifications
Operator's Manual – FireFighter © LAI GAMES SPECIFICATIONS LED FUNCTION GREEN LED: Notch output indicator. YELLOW LED: Motor Enable. STANDARD TICKET UNIT: TD-963CR The TD-963CR is designed to fit more applications. The game‟s software turns the dispenser on with a logic high signal and monitors a return notch signal from dispenser to turn it off. -
Page 47: Td-963Cr Schematic Diagram
Operator's Manual – FireFighter © LAI GAMES TD-963CR SCHEMATIC DIAGRAM Page 42... -
Page 48: Dispenser Parts Diagram
Operator's Manual – FireFighter © LAI GAMES DISPENSER PARTS DIAGRAM Page 43... -
Page 49: 3 D Explode Parts
Operator's Manual – FireFighter © LAI GAMES 3 D EXPLODE PARTS Page 44... - Page 50 Operator's Manual – FireFighter © LAI GAMES Page 45...
- Page 51 Operator's Manual – FireFighter © LAI GAMES Page 46...
- Page 52 Operator's Manual – FireFighter © LAI GAMES Page 47...
- Page 53 Operator's Manual – FireFighter © LAI GAMES Page 48...
-
Page 54: Firefighter Main Wiring Diagram
Operator's Manual – FireFighter © LAI GAMES FIREFIGHTER MAIN WIRING DIAGRAM Page 49... -
Page 55: Firefighter Base Wiring Diagram
Operator's Manual – FireFighter © LAI GAMES FIREFIGHTER BASE WIRING DIAGRAM Page 50... -
Page 56: Firefighter Power Wiring Diagram
Operator's Manual – FireFighter © LAI GAMES FIREFIGHTER POWER WIRING DIAGRAM Page 51... - Page 57 LAI GAMES warrants its manufactured products for a period of 3 months inclusive of parts and labor from the date of sale. LAI GAMES exclusive obligation is to repair any item with any defects as a result of faulty workmanship or materials, providing the defective item or items of equipment are returned to the LAI GAMES distributor from which the machine was purchased.
- Page 58 INTERNATIONAL SALES & SERVICE Sales/Enquiries: sales@laigames.com Product Support: support@mleisure.co.id Website: www.laigames.com For your nearest LAI GAMES Distributor visit our web site at http://www.laigames.com...
