- Page 1 Stacker Vendor GAMES © www.laigames.com ► READ THIS MANUAL BEFORE OPERATING THE MACHINE. ► KEEP THIS MANUAL FOR YOUR REFERENCE.
- Page 2 LAI GAMES Correspondence regarding this machine should be addressed to your closest LAI GAMES office, or LAI GAMES Distributor. For contact details, refer to the back page of this manual. © LAI GAMES Copyright Notice: Authorization is hereby provided to you to copy this...
- Page 3 LAI GAMES NOTES Dear Customer, Keep up-to-date with any new Software release or Service Bulletins for this Game. Check our Website at www.laigames.com click on Product Support, here you’ll find links to all the Bulletins and Software Updates to keep your game in top working Order.
-
Page 4: Table Of Contents
Operator's Manual – Stacker Vendor LAI GAMES © TABLE OF CONTENTS SAFETY PRECAUTIONS ..................1 MACHINE INSTALLATION INSPECTION ........... 2 INTRODUCTION ......................3 SPECIFICATIONS ....................4 HOW TO PLAY ......................5 FITTING PRIZES TO THE PRIZE ARM ..............6 PRIZE SELECTION AND PAYOUT ADJUSTMENT ..........8 OPERATION ....................... - Page 5 Operator's Manual – Stacker Vendor LAI GAMES © FUSE LOCATION DIAGRAM ................34 SECTION A: SERVICE INSTRUCTIONS ............35 LOCATING AND ACCESSING PARTS ............... 36 PARTS LOCATION DIAGRAM ................36 PARTS DESCRIPTION ..................38 LAMPS ........................40 MAINTENANCE ....................41 INSTRUCTIONS TO FIT 90 T-HANDLE LOCK ..........
-
Page 6: Safety Precautions
Operator's Manual – Stacker Vendor LAI GAMES © SAFETY PRECAUTIONS The following safety precautions and advisories are used throughout this manual and are defined as follows. * WARNING! * Disregarding this text could result in serious injury. * CAUTION! * Disregarding this text could result in damage to the machine. -
Page 7: Machine Installation And Inspection
© MACHINE INSTALLATION and INSPECTION When installing and inspecting “Stacker Vendor”, be very careful of the following points and pay attention to ensure that the players can enjoy the game safely. Be sure to turn the power OFF before working on the machine. -
Page 8: Introduction
DESCRIPTION The “Stacker Vendor” is a quick stop skill game that is simple and fast to play and learn. The player must press the start/stop button to stack the moving blocks on top of each other. Each time the player successfully builds another layer onto the pile of blocks, the next level is progressively harder. -
Page 9: Specifications
Operator's Manual – Stacker Vendor LAI GAMES © SPECIFICATIONS DIMENSIONS Weight: 163 kg (360lb) Height: 2000mm (78-1/2”) Width: 730mm (28-3/4”) Length: 770mm (30-1/2”) Power: Maximum 300 W – (220V @ 1.4 A)(120V @ 2.5 A) Average 150 W – (220V @ 0.7 A)(120V @ 1.5 A) -
Page 10: How To Play
Operator's Manual – Stacker Vendor LAI GAMES © HOW TO PLAY PLAYERS AIM TO BUILD A VERTICAL STACK OF BLOCKS TO WIN PRIZES Insert coin/s. (The exact amount of coins per play is dependant on Program settings P1 through to P6. See program settings, page 14 for details). -
Page 11: Fitting Prizes To The Prize Arm
Operator's Manual – Stacker Vendor LAI GAMES © FITTING PRIZES TO THE PRIZE ARM STEP ONE: Removal of Prize Locking Pin. 1. Unscrew the Prize Locking pin (left-hand thread), by turning it in a clockwise direction. 2. Remove the pin by pulling it all the way out. - Page 12 Operator's Manual – Stacker Vendor LAI GAMES © STEP FOUR: Correct positioning of prizes. Position the Hanging Ties on the START prize arm as shown. Space the prizes FINISH apart on the arms so they well presented, looking from the front.
-
Page 13: Prize Selection And Payout Adjustment
PRIZE SELECTION AND PAYOUT ADJUSTMENT Please read the following guide as a good starting point for setting up of your new “Stacker Vendor” game. By testing different merchandise and fine-tuning the settings you can maximize your game earnings. * NOTE! * All the following recommendations are based on an approximate payout of 30%. -
Page 14: Operation
(Refer to programmable adjustment P07, see page 14 of this manual). PLAY MODE The Stacker Vendor has two play modes. The Standard Coin Play mode, where a coin, or coins are inserted. Or Free Play where no coins are necessary. -
Page 15: Test Mode
© TEST MODE The Stacker Vendor Test mode has Three Test Configurations allowing you to test the function of the Sound, all Game Lamps, Displays, the Game Switches and the Prize Arm Motors. (Refer to the Test Mode Diagram below). -
Page 16: Sound, Lamps & Display Test
Operator's Manual – Stacker Vendor LAI GAMES © SOUND, LAMPS & DISPLAY TEST ENTER The Sound, Lamp & Display test is entered from Attract mode by pressing the test button once. * NOTE! * If there is an active error displayed, press the red test button once to try and clear the error. - Page 17 Operator's Manual – Stacker Vendor LAI GAMES © TICKET DISPENSER NOTCH (If optional Ticket or Capsule dispenser is fitted) The Ticket Notch Switch (C1) can be activated or deactivated from the Ticket Feed Button on the Ticket Dispenser PCB or by manually...
-
Page 18: Run Test
Operator's Manual – Stacker Vendor LAI GAMES © RUN TEST ENTER The Run Test can be entered by pressing the Test button once while in the Switch Test or by pressing the Test button three times while in Attract mode, will be displayed on the 4-digit display. -
Page 19: Programmable Adjustments Mode
LAI GAMES © PROGRAMMABLE ADJUSTMENTS MODE The Stacker Vendor has twenty three programmable adjustments that can be changed in this mode. They are P01 to P23 and their codes and values are displayed alternatively during the adjustment procedure. Example: Code P01 (Number of Coins Mech 1) is displayed as... -
Page 20: Programmable Adjustments Quick Reference Table
Operator's Manual – Stacker Vendor LAI GAMES © PROGRAMMABLE ADJUSTMENTS QUICK REFERENCE TABLE PROGRAMMABLE OPTIONAL DEFAULT CODE FEATURES ADJUSTMENTS VALUES SETTINGS 1 – 10 1, 2, 3…10 Coin Slot 1 – Coins / Credit 1 – 10 1, 2, 3…10 Coin Slot 1 –... -
Page 21: Programmable Adjustments Detailed
Operator's Manual – Stacker Vendor LAI GAMES © ON or OFF ON or OFF Major prize Arm No.10 Status 1 – 6 1, 2,3 …6 Number of prize arm re-tries SOFt or HArd SOFt or Hard SOFt Error type for Minor Prize – Err7... - Page 22 Operator's Manual – Stacker Vendor LAI GAMES © P03 -2 = COIN MECH 1: NUMBER of BONUS CREDIT per COIN on LEVEL 1 (Default OFF) (Adjustable OFF – 99) This variable sets the number of bonus credit that will be given on every coin inserted in coin mechanism 1 on level 1 multiple bonus for bonus credit.
- Page 23 Operator's Manual – Stacker Vendor LAI GAMES © P04 = COIN MECH 2: NUMBER OF COINS PER CREDIT (Default 01) (Adjustable 1 – 10) This variable sets the number of coins that need to be inserted into coin mechanism 2 for each credit. It can be set to 1, 2, and 3… to 10 coins for one credit.
- Page 24 Operator's Manual – Stacker Vendor LAI GAMES © P06 - 4 = COIN MECH 2: NUMBER of BONUS CREDIT per COIN on LEVEL 2 (Default OFF) (Adjustable OFF – 99) This variable sets the number of bonus credit that will be given on every coin inserted in coin mechanism 2 on level 1 multiple bonus for bonus credit.
- Page 25 Operator's Manual – Stacker Vendor LAI GAMES © P08 = CUBE SPEED (Default 3) (Adjustable 1 - 6) This option is for setting the Cube Speed. This affects the speed of the cube block movement as the player increases in levels. A setting of [1] is the easiest up to [6], the hardest.
- Page 26 Operator's Manual – Stacker Vendor LAI GAMES © P12 = NUMBER of MERCY TICKETS / CAPSULES ADJUSTMENT (default 0) (Adjustable 0 – 20) This option adjusts the number of mercy tickets or capsules paid out if the optional ticket or capsule dispenser is fitted. See P18 for setting Mercy System Mode payout options.
- Page 27 Operator's Manual – Stacker Vendor LAI GAMES © P24 = NUMBER OF PRIZE ARM RE-TRIES (Default 02) (Adjustable 1 – 6) This option controls the number of retries a user will get when a prize arm times out during the prize selection stage.
- Page 28 Operator's Manual – Stacker Vendor LAI GAMES © P28 = Minor Prize Option (Default Cap) (Adjustable Prz, Tic, Cap) This adjustment sets the way minor prize activated. If this option sets to Cap if player reach minor prize it will be dispense capsule, other option can be set for Ticket (Tic) or Prize (Prz).
-
Page 29: Audits Mode
Operator's Manual – Stacker Vendor LAI GAMES © AUDITS MODE The Audits Mode allows the operator to view statistics in all areas of the Game Play. This enables the operator to make calculated adjustments and “Fine Tune” the machine to maximize earning potential. The Audits mode stores bookkeeping of the games processed since the last game audits reset. -
Page 30: Audit Procedure
Operator's Manual – Stacker Vendor LAI GAMES © AUDIT PROCEDURE ENTER The Audits mode is entered from Programmable Adjustments mode by pressing the Test button once or from Attract mode by pressing the Test button five times. A A A A will be displayed on the 4-digit display. -
Page 31: Audits Quick Reference Table
Operator's Manual – Stacker Vendor LAI GAMES © AUDITS QUICK REFERENCE TABLE CODE DISPLAY AUDIT FUNCTION Total Coins In Mechanism 1 Total Coins In Mechanism 2 Total Number of Service Credits Total Number of Major Prize Wins Total Number of Minor Prize Wins... -
Page 32: Audits Detailed
Operator's Manual – Stacker Vendor LAI GAMES © Manufactures Audit only Manufactures Audit only Check Sum AUDITS DETAILED A01 = TOTAL COINS IN MECHANISM 1 This Audit displays the total number of coins inserted into coin mechanism 1 since the audits were last cleared. - Page 33 Operator's Manual – Stacker Vendor LAI GAMES © A08 to A22 TOTAL NUMBER OF GAMES ENDING on LEVELS 1 to 15 These Audits display the total number of games ending on level number 1 through to 15 on this machine since the audits were last cleared. Each level is a row of squares on the LED Playfield Display;...
-
Page 34: Game History Mode
Operator's Manual – Stacker Vendor LAI GAMES © GAME HISTORY MODE By using the Game History Mode the operator can view the results of the last 10 games played. This enables the operator to verify players game results and verify the win / lose pattern on the LED Playfield Display. -
Page 35: Game History Procedure
Operator's Manual – Stacker Vendor LAI GAMES © GAME HISTORY PROCEDURE ENTER The Game History mode is entered from Audits mode by pressing the Test button once or from Attract mode by pressing the Test button six times. H H H H will be displayed on the 4-digit display. -
Page 36: Errors And Troubleshooting
Operator's Manual – Stacker Vendor LAI GAMES © ERRORS AND TROUBLESHOOTING If the microprocessor detects any problems with the operation of the game, an Error will be displayed on the 4-digit display and the machine will play a voice message. -
Page 37: Troubleshooting Game Errors
EEPROM (The 23C16 IC on the main MCU PCB). This could cause problems with the game audits and program settings. If this error occurs, take your game to the nearest authorized LAI games dealer for repair. Err4 – MAJOR PRIZE DEPLOYMENT ERROR... - Page 38 If you cannot find anything blocking the sensor, there could be faulty infrared sensors or receivers on the prize sensor. The sensor PCB’s should be returned to your nearest LAI Games distributor for repair. The Prize Sensor is designed around 12 pairs of infrared detectors and LEDs.
-
Page 39: Fuse Information
Operator's Manual – Stacker Vendor LAI GAMES © FUSE INFORMATION * WARNING! * Always turn OFF Mains power and unplugged the game, before replacing any fuses. MAIN AC SUPPLY FUSE (1 x 6 AMP FAST BLOW, M205 TYPE) This fuse is for the main AC supply and is situated in the IEC mains input socket. -
Page 40: Section A: Service Instructions
Operator's Manual – Stacker Vendor LAI GAMES © SECTION A: SERVICE INSTRUCTIONS BE SURE TO READ THE FOLLOWING Carefully before servicing this machine Page 35... -
Page 41: Locating And Accessing Parts
Operator's Manual – Stacker Vendor LAI GAMES © LOCATING AND ACCESSING PARTS PARTS LOCATION DIAGRAM As viewed from front Florescent FL15 Header Lamp Acrylic Diachronic Prize Display Down Lamps Door Major Prize LED Playfield Arms (Long) Display Major Prize Arm... - Page 42 Operator's Manual – Stacker Vendor LAI GAMES © PARTS LOCATION DIAGRAM Cont. As viewed from rear PARTS Location Diagram Florescent Lamp Upper Deflector Vent Major Prize Florescent FL15 Arms Motors Lamps LED Playfield Minor Prize Display PCBs Arms Motors PRIZE SHUTE...
-
Page 43: Parts Description
Operator's Manual – Stacker Vendor LAI GAMES © PARTS DESCRIPTION COIN MECHANISMS The coin mechanisms can be accessed inside the Coin door to the right on the front of the machine cabinet. CASH BOX The cash box is located inside the coin door on the front of the machine cabinet. - Page 44 Operator's Manual – Stacker Vendor LAI GAMES © POWER CORD The power cord is a standard IEC power cord (as used on computers) that is plugged in to the power inlet socket at the rear of the machine. The power cord can be removed for transport.
-
Page 45: Lamps
Operator's Manual – Stacker Vendor LAI GAMES © LAMPS * WARNING! * Always turn OFF Mains power and unplugged the game, before replacing any lamps. Always allow time for cooling as Lamps that have been active for a time may still be too hot to touch. -
Page 46: Maintenance
Operator's Manual – Stacker Vendor LAI GAMES © MAINTENANCE CLEANING AND CHECK UP EXTERIOR Regularly dust and clean the external cabinet areas as required, using a soft water-damp cloth and mild soap. Check for blown bulbs and replace as required. -
Page 47: Instructions To Fit 90 T-Handle Lock
TO NEW TYPE COIN DOORS This document is to instruct in the fitting of a 90º T-Handle Lock to the new type coin doors for Lighthouse and Stacker Vendor. How to Identify the New type Coin Doors The new type coin doors can be identified by additions both to the door and to the door frame. - Page 48 Operator's Manual – Stacker Vendor LAI GAMES © What is a T-Handle Lock and where to Purchase it The “Pop-out” T-Handle Locks are commonly found on drink and snack vending machines. They provide a heavy duty tamper proof locking system with replaceable inner cylinders using a variety of key types.
- Page 49 Operator's Manual – Stacker Vendor LAI GAMES © Removing Original Lock & Cam Open the Coin Door and remove the cam from the rear of the barrel lock. Then remove the barrel lock from the front and rear cover plates.
-
Page 50: Section B: Technical Details
Operator's Manual – Stacker Vendor LAI GAMES © SECTION B: TECHNICAL DETAILS It is advised that anybody using SECTION B for repairing or modifying any of the components of the game should be a qualified technician, having at least a basic knowledge of digital components, integrated circuits and electricity. -
Page 51: Mains Voltage Adjustment
Operator's Manual – Stacker Vendor LAI GAMES © MAINS VOLTAGE ADJUSTMENT POWER SUPPLY The Switch Mode Power Supply has a switch to set the mains voltage range. It is located at the rear of the game cabinet, and is accessed via the back door. Use a... -
Page 52: 3D Parts Explode
Operator's Manual – Stacker Vendor LAI GAMES © 3D PARTS EXPLODE Page 47... - Page 53 Operator's Manual – Stacker Vendor LAI GAMES © Page 48...
- Page 54 Operator's Manual – Stacker Vendor LAI GAMES © Page 49...
- Page 55 Operator's Manual – Stacker Vendor LAI GAMES © Page 50...
- Page 56 Operator's Manual – Stacker Vendor LAI GAMES © Page 51...
- Page 57 Operator's Manual – Stacker Vendor LAI GAMES © Page 52...
-
Page 58: Stacker Vendor Main Wiring Diagram
Operator's Manual – Stacker Vendor LAI GAMES © Stacker Vendor MAIN WIRING DIAGRAM Page 53... -
Page 59: Stacker Vendor Power Wiring Diagram
Operator's Manual – Stacker Vendor LAI GAMES © Stacker Vendor POWER WIRING DIAGRAM Page 54... -
Page 60: Stacker Vendor Optional Wiring Diagram
Operator's Manual – Stacker Vendor LAI GAMES © Stacker Vendor OPTIONAL WIRING DIAGRAM Page 55... - Page 61 WARRANTY LAI GAMES warrants its manufactured products for a period of 3 months inclusive of parts and labor from the date of sale. LAI GAMES exclusive obligation is to repair any item with any defects as a result of faulty workmanship or materials, providing the defective item or items of equipment...
- Page 62 * NOTE! INTERNATIONAL SALES & SERVICE Sales/Enquires sales@laigames.com. Product Support support@mleisure.co.id Web site www.laigames.com LAI GAMES For your nearest Distributor visit our web site at http://www.laigames.com...
