PVG 16 and 32 Service Assembly/Disassembly Guide
Testing

PVG 16 and 32 function testing

© Danfoss | November 2017
For relief valve version and location please see the figure
C-C C-C
360º~120 bar 360º~100 bar
360º~1740 psi 360º~1450 psi
T
T
Function testing insures the correct dynamic manual and electrical operation of the PVG 16 and PVG 32
valve assembly. This test should be performed after completing the pressure adjustments. Each section of
the assembly must be tested:
1. With the pump connected, remove the plugs from the section to be tested as described in the
Pressure setting after assembly
the cylinder and the "B" port to the base end of the cylinder (see the figure below).
Inlet Pressure Measurement
30 to 350 bar
[435 to 5075 psi]
PC Pump 14 l/min
[3.4 US gal/min]
2. Shift the control lever of the tested section towards the valve and observe cylinder retraction. Shift
the same control lever away from the valve and observe cylinder extension. Repeat several times. On
valve groups with PVM's on the "B" side, the cylinder movement will be opposite when shifting the
handle in the same direction.
3. Check the spool travel smoothness in both directions.
LS
C C
LS B
C LS A C
C
C
on page 22 section. Connect the "A" port of the valve to the rod end of
Workport PVLP Pressure Measurement
32 to 350 bar [464 to 5075 psi]
P A B A
PVP
T LS PVB PVB
B A B
LX
PVB PVS/I
V310340.A
