Keysight Technologies N9344C Configuration Manual page 4

04 | Keysight | N9342-44C Handheld Spectrum Analyzer (HSA) - Configuration Guide
Configure your Keysight N934xC Handheld Spectrum Analyzer (HSA)
(continued)
Description
Step 7. Add an accessory (continued)
Bandpass filter
Bandpass filter
Bandpass filter
Bandpass filter
Adapter
Adapter
Adapter
Adapter
Adapter
Adapter
Adapter
Adapter
Cable
Cable
Cable
Cable
Cable
Cable
Attenuator
Attenuator
Attenuator
Step 8. Add calibration service
Select Keysight calibration plan
Commercial calibration certificate with test data
3-year calibration assurance plan
(return to Keysight)
5-year calibration assurance plan
(return to Keysight)
Option number Additional information
N9311x-551 – 3 dB passband 880 to 915 MHz
– Rejection ≥ 35 dBc at 826 MHz, ≥ 36 dBc at 932 MHz
– Insertion loss ≤ 1 dB
– VSWR ≤ 1.5
N9311x-552 – 3 dB passband 1707.5 to 1787.5 MHz
– Rejection ≥ 35 dBc at 1550 MHz, ≥ 35 dBc at 1925 MHz
– Insertion loss ≤ 0.4 dB
– VSWR ≤ 1.5
N9311x-553 – 3 dB passband 1845 to 1915 MHz
– Rejection ≥ 35 dBc at 1770 MHz, ≥ 35 dBc at 1986 MHz
– Insertion loss ≤ 0.6 dB
– VSWR ≤ 1.5
N9311x-554 – 3 dB passband 1910 to 1990 MHz
– Rejection ≥ 35 dBc at 1825 MHz, ≥ 35 dBc at 2070 MHz,
– Insertion loss ≤ 0.6 dB
– VSWR ≤ 1.5
N9311x-540 Type-N(m) to BNC(f), DC to 2 GHz
N9311x-541 Type-N(m) to SMA(f), DC to 12.4 GHz
N9311x-542 Type-N(f) to 7/16 DIN(f), DC to 7.5 GHz
N9311x-543 Type-N(f) to BNC(m), DC to 4 GHz
N9311x-544 Type-N(f) to 7/16 DIN(m), DC to 7.5 GHz
N9311x-545 Type-N(f) to SMA(m), DC to 12.4 GHz
N9311x-546 Type-N(f) to Type-N(f), DC to 18 GHz
N9311x-547 Type-N(m) to DIN(f), DC to 7.5 GHz
N9311x-580 Phase stable, 1.5 m, N(m) to N(m)
N9311x-581 Phase stable, 3 m, N(m) to N(m)
N9311x-582 1.5 m, SMA(m) to SMA(m)
N9311x-583 1.5 m, BNC(m) to BNC(m)
N9311x-585 Phase stable, 1.5 m, N(m) to DIN(f)
N9311x-586 Phase stable, 1.5 m, N(m) to N(f)
N9311x-560 40 dB, N(m) to N(f), 10 watts average
N9311x-561 40 dB, N(m) to N(f), 50 watts average
N9311x-562 40 dB, N(m) to N(f), 100 watts average
N934xC-UK6 Keysight provides a commercial calibration certification; only available at time of
purchase; provides measurement results.
R-50C-011-3 Priority calibration service covering all calibration costs for
3 years; 15% cheaper than buying stand-alone calibrations.
R-50C-011-5 Priority calibration service covering all calibration costs for
5 years; 20% cheaper than buying stand-alone calibrations.
