INSTALLATION AND MAINTENANCE INSTRUCTIONS
8100A FAAST
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Remote Reset Time
Power Reset
Average Operating Current
Alarm
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
IP Rating
Coverage Area
Air Movement
Hazardous Environments
Exterior Dimensions
Height
Width
Depth
Cable Access
Wire Gauge
Pipe Network Size
Shipping Weight
TABLE OF CONTENTS
INTRODUCTION
SCOPE OF THIS MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DESCRIPTION
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ITEMS INCLUDED WITH UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION
PIPE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Securing the Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting the Detector to the Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connecting the Air Sampling Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Exhaust Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
WIRING
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Conduit Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CABLING REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SYSTEM POWERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
USER INTERFACE
USER INTERFACE CARD INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PARTICULATE LEVEL DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ALARM LEVEL DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
AIR FLOW/FAULT DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
USER INTERFACE BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MODES OF OPERATION
INITIALIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
STARTUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SS-400-012
18 – 30 VDC
External monitor must be pulled low for a minimum of 100 msec.
1 sec.
500 mA @ 24 VDC
650 mA – All relays active, all alarm levels displayed. Voltage @ 24 VDC
3.0 A @ 30 VDC, 0.5A @ 125 VAC
32°F (0°C) to 100°F (38°C)
-4°F (-20°C) to 140°F (60°C)
10 to 95% (non-condensing)
IP30
8,000 sq. ft. (743.2 sq. m.)
100 – 4,000 ft./min. (30.5-1,219.2 m/min.)
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D, or non-hazardous locations only
13.25 in. (33.66 cm)
13.0 in. (33 cm)
5.0 in. (12.7 cm)
4 – 1 in. (2.54 cm) cable entry holes on top and bottom of unit.
12 AWG (2.0523 mm) max. to 24 AWG (0.5105 mm) min.
Up to 8000 sq. ft. (approx 743 sq. m)
Maximum single pipe length 262 ft. (80 m)
Network outside pipe diameter 1.050 in., IPS (25 mm)
Internal pipe diameter .591 to .827 in. (15-21 mm)
11.6 lbs. (5.26 kg), includes packing material
6581 Kitimat Rd. Unit 6 Mississauga, Ontario L5N 3T5
®
Failure of Configuration Validation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power or Network Loss during Configuration . . . . . . . . . . . . . . . . . . . . . . 6
NORMAL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TEST MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RESET MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ACCLIMATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting Acclimate mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DAY, NIGHT AND WEEKEND MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ISOLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USER BUTTON ALTERNATE FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Passcode Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Address Blink Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
IP Address Blink Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
FAULTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
REAL–TIME CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
LOGS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Data Trend Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Message Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
EXTERNAL MONITOR/RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ETHERNET CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PIPE NETWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WEB SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
E-MAIL NOTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CANNED SMOKE TESTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GLOSSARY
KEY TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1
1-800-SENSOR2, Fax: 905-812-0771
www.systemsensor.ca
I56-3749-006
Advertisement
Table of Contents
Related Manuals for System Sensor 8100A FAAST
Summary of Contents for System Sensor 8100A FAAST
- Page 1 INSTALLATION AND MAINTENANCE INSTRUCTIONS 8100A FAAST 6581 Kitimat Rd. Unit 6 Mississauga, Ontario L5N 3T5 Fire Alarm Aspiration Sensing Technology ® 1-800-SENSOR2, Fax: 905-812-0771 www.systemsensor.ca SPECIFICATIONS Electrical Characteristics External Supply Voltage 18 – 30 VDC Remote Reset Time External monitor must be pulled low for a minimum of 100 msec.
-
Page 2: Installation
DESCRIPTION mounted to the wall using the enclosed mounting plate. Figure 1 shows the The 8100A FAAST aspirating smoke detection system is an advanced particu- wall mounting plate. For easier access to the FAAST unit, it is preferred to late detection system for use in early warning and very early warning applica- position the mounting plate in an easily accessible location. -
Page 3: Mounting The Detector To The Bracket
Mounting the Detector to the Bracket Exhaust Pipe Once the mounting plate is attached, the unit is ready to be mounted onto the The device should always be exhausted into the space that it is monitoring. plate. Perform the following procedure to mount the unit. There are some circumstances when it may be necessary to connect a pipe to the exhaust port to divert the exhaust away from the location of the unit. -
Page 4: User Interface
CABLING REQUIREMENTS TABLE 2. FACP WIRING DIAGRAM The FAAST system provides a series of Euro style pluggable terminals, located Fire Panel (FACP) typical connection FAAST 8100A behind the left side door of the unit. for monitoring of device Fire Alarm Aspiration Sensing Technology® Refer to Table 1 for the proper electrical connections to the unit. -
Page 5: Green Leds
FIGURE 4. USER INTERFACE DISPLAY modified using the PipeIQ software tool. Each of these alarm levels controls a set of form C relay contacts. When an alarm level threshold is crossed, the cor- responding level LED illuminates and the relay activates a signal.. These alarm levels and associated relay outputs can be programmed for either latching or non- latching operation, in addition to a programmable delay for each level from 0 to Alarm Level... -
Page 6: Modes Of Operation
NOTE: Installation must be accomplished in accordance with all local codes and regulations. Product is ULC certified to CAN/ULC S529. The 8100A FAAST is ULC approved from 0.00046 %/ft obs. to 3.15%/ft obs. Evacuation via FACP (fire alarm control panel) must not be set higher than 0.735 %/ft obs. Product is approved for air velocity range from 100 to 4000 FPM. -
Page 7: Day, Night And Weekend Mode
DAY, NIGHT AND WEEKEND MODE FIGURE 10. ADDRESS BLINK MODE If Acclimate mode is not desired, the FAAST system can operate in a simple day, night and weekend mode. This allows the device to have separate thresh- old levels for each state. Times can be configured, if desired, for entering and leaving day and night time operation. -
Page 8: Real-Time Clock
TABLE 5. FAULT DESCRIPTION NUMBER NAME DESCRIPTION ACTIVATED RELAY Low Flow Fault Device has decreased airflow of 20%. Minor Fault Device has decreased airflow of 50%. Urgent Fault Configuration Configuration of device with configuration software has failed. Minor Fault Device was interrupted with a power loss during configuration. A Reset will clear Minor Fault this fault and device will revert back to it's last good configuration. -
Page 9: Web Server
WEB SERVER TABLE 6. CANNED SMOKE TESTING The FAAST system contains an integrated Web server which is used to ob- ULC LISTED COMPANY AEROSOL serve detector configuration and may be used to remotely monitor the unit. Home Safeguard The Web server features include: •... - Page 10 FAAST System Validation Form Customer Name: Project Name: Site Address: Installer Name/Contact information: Date: Commissioning Agent/Contact information: Date: Client Representative/Contact information: Date: Witness/Contact information: Date: Wiring Checked: Date: Yes / No Detector Settings Checked: Date: Yes / No Test Relays: Date: Yes / No REQUIRED DOCUMENTS...
- Page 11 FAAST System Validation Form (CONT.) Air Handling Yes / No Duct Sampling Yes / No Number of Sample points: Number of Cabinets: Temperature: Humidity: Conditions: Other: As-Built Installation Is the system installed in Yes / No Yes / No Drawings Available? accordance with the design? Is the power supply Is the pipe network installed...
- Page 12 United States. WARRANTY System Sensor warrants its enclosed smoke detector to be free from defects in materials RA #__________, 6581 Kitimat Road, Unit 6 Mississauga, Ontario L5N-3T5. Please include and workmanship under normal use and service for a period of three years from date of a note describing the malfunction and suspected cause of failure.
