VARI LITE® - VL2000™ S
Error Display
TILT
NO
SENS
TILT
SENS
ACTV
WAIT
WRNG
SW
PROG
82
L U '
POT UMINAIRE SER S
Table A-2: Troubleshooting Guide (Continued)
Description
Tilt Sensor Not Found
Tilt Sensor Always Active
Retrieving Current Status
Wrong Software Program
02-May-03
M
ANUAL
Possible Cause and Remedy
EOT flag attached to large pulley is not engaging the
EOT sensor
- Ensure flag is attached to the large pulley
- Ensure that flag passes through the sensor at a
depth sufficient to engage the sensor beam
Tilt belt disconnected, extremely loose or not installed
properly
- Properly install belt between tilt motor and large
pulley
Main board pan/tilt connector (J9) disconnected
- Connect main board pan/tilt connector (J9)
End-of-travel sensor connector (J2) disconnected
- Connect end-of-travel sensor connector (J2)
System displays wait while getting status.
Software installed does not match luminaire type
- Download the correct software for the luminaire
02 .9 673 .00 01 D
