Performing LCR Measurements

Auto Identification (Ai)
Press the
select an appropriate primary measurement
function (L, C, or R), secondary measurement
function (D, Q, or
(parallel or series) for the device-under-test.
The LCR meter powers up in the Ai mode by default.
NOTE
the Ai mode is enabled.
–
–
LCR measurement steps
8
button to automatically identify and
θ
is shown on the left of the display screen when
flashes when the LCR meter is identifying
a measurement function and mode.
Press again while
Ai mode.
Keysight U1731C/U1732C/U1733C Quick Start Guide
), and measurement mode
is shown to exit the
