N9040B UXA Signal Analyzer
Option RTS, Streaming
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement business
has become Keysight Technologies. For more information,
go to
www.keysight.com
.
Installation Note
Advertisement
Related Manuals for Keysight Technologies N9040B UXA
Summary of Contents for Keysight Technologies N9040B UXA
- Page 1 Keysight Technologies N9040B UXA Signal Analyzer Option RTS, Streaming Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement business has become Keysight Technologies. For more information, go to www.keysight.com Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Option RTS, Streaming Option RTS, Streaming Products Affected UXA N9040B Serial Numbers: To Be Performed By: (X) Keysight Service Center ( ) Personnel Qualified by Keysight ( ) Customer Estimated Installation Time: 2.0 Hours Estimated Adjustment and Verification Time: 0.0 Hours Additional Tasks: 0.0 Hours Introduction...
- Page 4 Option RTS, Streaming Contents Quantity Description Keysight Part Number Installation Note This note Option Upgrade Entitlement Certificate 5964-5178 WBDIF Extension Board assembly N9020-60272 Bracket, WBDIF Extension N9040-00033 Screw, M3 x 0.5 8 mm long 0515-0372 Flex Cable Assembly for Option B5X N9040-60048 Flex Cable Assembly for Option B2X and B5X N9040-60047...
-
Page 5: Initial Instrument Functionality Check
Option RTS, Streaming Initial Instrument Functionality Check Power on the instrument and allow the instrument to boot up, run the alignments and display the measurement screen. The instrument will probably display a spectrum analyzer screen and you will see the instrument sweeping. There should be no alignment failures. - Page 6 Option RTS, Streaming Assemble the WBDIF Extension board, Bracket, and Flex Circuit 1. Locate the WBDIF Extension board and the bracket in the kit. Attach the WBDIF Extension board to the bracket with four screws from the kit. See Figure 1.
- Page 7 Option RTS, Streaming 5. The flex cable(s) will need to be routed as shown in Figure 2 Figure Figure 2 Flex Circuit Routing - 1 Figure 3 Flex Circuit Routing - 2 Installation Note N9040-90014...
- Page 8 Option RTS, Streaming Figure 3 shows the WBDIF Extension assembly installed in the instrument that has Option B5X. Notice the gray flexible cables are routed along the instrument chassis. 7. Remove the gray label that covers the rear panel Wideband Digital Bus connectors. 8.
-
Page 9: License Installation Procedure Over Usb
Option RTS, Streaming License Installation Procedure over USB 1. Locate the Option Upgrade Entitlement Certificate (5964-5178) from the kit. 2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the Certificate. 3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an attached License File. - Page 10 Performance Testing Required Verification Test Name None For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL, or if in the United States, call the following telephone number: http://www.keysight.com/find/assist...
