- Page 1 Startup Guide Keysight U5303A PCIe High-Speed Digitizer 2 channels, 12-bit, up to 3.2 GS/s, DC up to 2 GHz bandwidth, with custom firmware support...
- Page 2 Copyright Notice HEREIN. SHOULD KEYSIGHT AND THE public to use, modify, reproduce, © Keysight Technologies 2013 - 2016 USER HAVE A SEPARATE WRITTEN release, perform, display, or disclose No part of this manual may be...
- Page 3 temperature range is not maintained, safety precautions required to avoid intended to be used with impedance- module surface temperatures may possible injury. Read and follow all limited sources. NEVER connect exceed safe handling conditions which installation, operation, and switching cards directly to AC mains. can cause discomfort or burns if maintenance information carefully When connecting sources to switching...
- Page 4 For continued To prevent electrical shock, disconnect To return unwanted products, contact protection against fire hazard, replace the Keysight Technologies instrument your local Keysight office, or for more fuse with same type and rating. from mains before cleaning. Use a dry...
-
Page 5: Table Of Contents
Fitting the module with the optional card retainer into your PC U5303A Front Panel Features Front Panel Connectors Front Panel LEDs Step 5: Verify Operation of the U5303A Module Keysight Connection Expert Driver Graphical Interface: MD2 Soft Front Panel Perform a Verification of the U5303A (optional) -
Page 6: Documentation Map
Documentation Map Documentation Map Keysight U5303A Startup Guide... -
Page 7: U5303A Pcie High-Speed Digitizer Introduction
U5303A PCIe High-Speed Digitizer Introduction The scope of this Startup Guide is to detail the processes of receiving and installing the Keysight U5303A PCIe High-Speed Digitizer, installing the required software, and verifying basic module operation. If you have any questions after reviewing this information, please contact your local Keysight representative or contact us through our website at www.keysight.com/find/contactus. - Page 8 This Start-Up Guide is intended to lead the user through the four steps of product installation as summarized in the diagram below. An optional fifth step shows how to perform an operational verification of the U5303A PCIe High-Speed Digitizer. Step 1: Unpack and Inspect...
-
Page 9: Step 1: Unpack And Inspect The Module
(see warranty information at beginning of this document). To avoid damage when handling a module, do not touch any exposed components or connector pins. http://www.keysight.com/find/tips for information on preventing damage to your Keysight equipment. Keysight U5303A Startup Guide... -
Page 10: Return A Module For Service
Name and address of owner. A P.O. box is not acceptable as a return address. Product model number (for example, U5303A). Product serial number. The serial number label is located on the top cover of the module. The serial number can also be read from the Soft Front Panel interface, but only after the hardware is installed. -
Page 11: Step 2: Verify U5303A Shipment Contents
Step 2: Verify U5303A Shipment Contents Step 2: Verify U5303A Shipment Contents The following items are also included with your U5303A PCIe High-Speed Digitizer order: Part Number Quantity Description U5303A PCIe High-Speed Digitizer. U1092-80001 Coaxial cable, MMCX (male) to BNC (male), 1 m. -
Page 12: Step 3: Install The Software
Recommended models are: HP Z420, HP Z440, or Dell T5810. Install the Software If the Keysight MD2 software is installed on your computer, first uninstall the Keysight MD2 software from the Control Panel > Programs and Features before installing the Keysight MD2 High-Speed Digitizer Software. Keysight U5303A Startup Guide... -
Page 13: Keysight Io Libraries Suite (Iols)
2. From the High-Speed Digitizers Applications DVD launch the installer. 3. Follow the installer prompts and select the applications your want to install. For complete list of application options supported by your digitizer, please refer to product’s datasheet. Keysight U5303A Startup Guide... -
Page 14: Step 4: Install The Module
Follow ESD precautions when handling and installing the U5303A. 2. The U5303A features a x8 PCIe bus interface, and should be installed in either a x8 or x16 PCIe slot. 3. When installing the U5303A, ensure that it has optimum cooling. Do not install it in a position where the integrated cooling fans may be obstructed. -
Page 15: Fitting The Module With The Optional Card Retainer Into Your Pc
When disconnecting the auxiliary power cable, it is important to push it away from the PCB side of the U5303A in order to disengage the friction lock. Failure to do this could cause the module side of the connector to be withdrawn at the same time thus damaging it. - Page 16 Step 4: Install the Module Diagram showing U5303A fan/support assembly fixings . Removing the card retainer 1. Remove the screw (A in the figure). 2. Withdraw the card retainer. Installing the card retainer (if not previously fitted) 1. Slide the card retainer onto the fan module and fit screw (A) to the top of the retainer.
-
Page 17: U5303A Front Panel Features
Step 4: Install the Module U5303A Front Panel Features Front Panel Connectors Connector Type Description MMCX External trigger input, 50 Ω DC terminated, ±5 V range. TRG IN female Analog signal inputs, DC-coupled and 50 Ω terminated. female The input Full Scale Ranges are selectable:... -
Page 18: Front Panel Leds
If warning or error status is observed, please try the following steps: Power-cycle the PC (If using a PCIe expansion chassis, observe the power sequence requirements) If the error persists please contact Keysight technical support http://www.key- sight.com/find/assist. Keysight U5303A Startup Guide... -
Page 19: Step 5: Verify Operation Of The U5303A Module
Step 5: Verify Operation of the U5303A Module Step 5: Verify Operation of the U5303A Module Keysight Connection Expert The intention of this step is to verify correct operation of the newly installed module. Run Keysight Connection Expert by clicking the task bar icon , and select Connection Expert. -
Page 20: Driver Graphical Interface: Md2 Soft Front Panel
Step 5: Verify Operation of the U5303A Module Driver Graphical Interface: MD2 Soft Front Panel The Keysight MD2 SFP (Soft Front Pannel) is a graphical interface for High-Speed Digitizer Instrument Drivers that enables the control of any supported digitizers. The MD2 SFP can be launched from Keysight Connection Expert, directly from the Windows Start Menu >... -
Page 21: Perform A Verification Of The U5303A (Optional)
Perform a Verification of the U5303A (optional) Requirements for Verification The correct operation of the U5303A may be verified by the use of a simple application which carries out several performance checks on a signal acquired from an external Function Generator. - Page 22 Step 5: Verify Operation of the U5303A Module AgMD2Verify checks the version of the Control FPGA firmware. If the version is not up-to-date, the tool will automatically propose to update the firmware using the "Firmware Update Utility". Once the Control FPGA firmware has been updated successfully, please power off your computer and restart it again for the update to take effect.
