Samsung ST55W3PCX/XAX Service Manual page 77

Electrical Parts List
Loc. No. Code No. Description ; Specification
ASSY P/MATERIAL
1 A/PMATERIAL AA92-04017A ASSY P/MATERIAL;SP55W3HFX/ELE
2 BOX 0203-000367 TAPE-CELLULOSE;#430,-,W19,L25,CLR
2 T/BOX 0203-001096 TAPE-CELLULOSE;#301,T0.06,W75,L400,WHT
2 H/BOX AA61-00049B HOLDER-BOX;DP,-,PP,V0,NTR,AA61-20285A
2 SHEET AA63-00533A SHEET;,LDPE 1.0+HDPE 0.015,1000,WHT
2 BAND AA63-10007C BAND PP;W18,CLEAR,1G
2 C/SET BP69-00039A CUSHION-SET;55W3(NEW-2),EPS C=0.02,SIDE
2 PE-BAG AA69-30036A BAG-PE;HDPE,T0.02,2000,1800,-,-,555J,
2 TAPE/BOX 0203-001269 TAPE-OPP MASKING;#301,T0.06,W75,L50000,N
2 STAPLE AA60-40006A PIN-STAPLE;-,-,-,H18,33X17.8X2
ASSY BOX
1 A/BOX AA92-04032W ASSY BOX;ST55W3PCX/XAX,P55A
2 L/BNOM AA68-01793A LABEL;BOX & NOM,WTH,PAPER,MEX & TIJ
2 PCK-BOT BP69-00008A PACKING-COVER,BOT;55W3,(NEW)H-3 AB,C-1,1
2 PCK-OUT BP69-00022M PACKING CASE-OUT;55W3(SAMEX),H-3 AB,C3,,
ASSY PRT
1 A/PRT BP91-00491A ASSY PRT;HCM5525WX/XAA,P55A
2 A/CPTB BP91-00505A ASSY CPT-B;HCM5525WX/XAA,P55A,B
3 SILGRY 0201-001030 ADHESIVE-SIL;SE9178,GRY,NON-FLOW,UL94V0
3 TAPE/AC 0203-001303 TAPE-ACETATE;#1554,T0.25,W19,L30000,WHT
3 GLYCOL 0204-001148 ETHYLENE GLYCOL;MS-S02,CH20HCH20H,80,20
3 CRTB AA03-00328A CRT COLOR;P16LFM00BMB(TU),FREE,0.78MH,7.
3 DY AA27-00249A DEFLECTION YOKE;-,DPD-5292AA,S/S,7,29.1
3 CY AA33-00018A MAGNET CONVERGENCE;JH 92LT - 36F,-,29.1M
3 L/CONN AA39-00018A LEAD CONNECTOR-ASSY;-,YFH800-01,YRH187RH
3 H/DY BP61-00079A HOLDER-DY;,PJTV,T0.5,NYLON66 V2
3 SCRT AA60-00125B SPACER-CRT;PROJ,SILICONE,D/GRAY
3 SPACER-C AA60-00126B SPACER-CAP;PROJ,EPDM,BLK
3 C-LENS AA60-00127B SPACER-LENS;PROJ,SILICONE,D/GRAY
3 BC+AL AA60-10011A SCREW-TAPTITE;HH,+,PC,M4,L12,ZPC(BLK),SW
3 BKT-LENS AA61-00056B BRACKET-LENS;-,PROJECTION,SECC,T1.6,-,-,
3 HCRT AA61-00809B HOLDER-CRT;PROJ,PC/ABS GF 20%,BLK
3 H/CAP AA61-00810B HOLDER-CAP;PROJ,PC,CLR
3 C/COUPLER AA61-00847A CASE-COUPLER,B;DP,PROJ,AA61-00808B
3 SPACER-L AA63-00076A SPACER-LENS;FELT ,T1.0,BROWN,7CRT,PROJE
3 LENS-ASSY AA67-00146A LENS-ASSY;,DELTA 260,CLEAR A/B
3 LENS-DELTA AA67-00156A LENS;,DELTA 240,CLEAR,C-ELEMENT
3 A/BCRT AA91-00722A ASSY-BRKT,CRT;,SECC T1.6,PROJ
3 FBT AA26-30006F TRANS-FLYBACK;-,FWZ-50A001C,55',30KV
2 A/CPTG BP91-00507A ASSY CPT-G;HCM5525WX/XAA,P55A,G
3 SILGRY 0201-001030 ADHESIVE-SIL;SE9178,GRY,NON-FLOW,UL94V0
3 TAPE/AC 0203-001303 TAPE-ACETATE;#1554,T0.25,W19,L30000,WHT
3 GLYCOL 0204-001148 ETHYLENE GLYCOL;MS-S02,CH20HCH20H,80,20
3 CRTG AA03-00327A CRT COLOR;P16LFM00HHA(TU),FREE,0.78MH,7.
3 DY AA27-00249A DEFLECTION YOKE;-,DPD-5292AA,S/S,7,29.1
3 L/CONN AA39-00018A LEAD CONNECTOR-ASSY;-,YFH800-01,YRH187RH
3 H/DY BP61-00079A HOLDER-DY;,PJTV,T0.5,NYLON66 V2
3 SCRT AA60-00125B SPACER-CRT;PROJ,SILICONE,D/GRAY
3 SPACER-C AA60-00126B SPACER-CAP;PROJ,EPDM,BLK
3 C-LENS AA60-00127B SPACER-LENS;PROJ,SILICONE,D/GRAY
3 BC+AL AA60-10011A SCREW-TAPTITE;HH,+,PC,M4,L12,ZPC(BLK),SW
3 BKT/LENS AA61-00056B BRACKET-LENS;-,PROJECTION,SECC,T1.6,-,-,
3 HCRT AA61-00809B HOLDER-CRT;PROJ,PC/ABS GF 20%,BLK
3 H/CAP AA61-00810B HOLDER-CAP;PROJ,PC,CLR
3 C/COUPLER AA61-00846A CASE-COUPLER,G;DP,PROJ,AA61-00807B
3 SPACER-L AA63-00076A SPACER-LENS;FELT ,T1.0,BROWN,7CRT,PROJE
3 LENS-ASSY AA67-00146A LENS-ASSY;,DELTA 260,CLEAR A/B
3 LENS-DELTA AA67-00158A LENS;,DELTA 240,GREEN,C-ELEMENT
3 A/BCRT AA91-00722A ASSY-BRKT,CRT;,SECC T1.6,PROJ
3 FBT AA26-30006F TRANS-FLYBACK;-,FWZ-50A001C,55',30KV
2 A/CPTR BP91-00509A ASSY CPT-R;HCM5525WX/XAA,P55A,R
3 SILGRY 0201-001030 ADHESIVE-SIL;SE9178,GRY,NON-FLOW,UL94V0
3 TAPE/AC 0203-001303 TAPE-ACETATE;#1554,T0.25,W19,L30000,WHT
3 GLYCOL 0204-001148 ETHYLENE GLYCOL;MS-S02,CH20HCH20H,80,20
7-20
Remark Loc. No. Code No.
3 CRTR
3 DY
3 CY
3 L/CONN
3 H/DY
3 SCRT
3 SPACER-C
3 C-LENS
3 BC+AL
3 BKT-LENS
3 HCRT
3 H/CAP
3 C/COUPL
3 SPACER-L
3 LENS/ASSY AA67-00146A LENS-ASSY;,DELTA 260,CLEAR A/B
3 LENS-DELTA AA67-00157A LENS;,DELTA 240,RED,C-ELEMENT
3 A/BCRT
3 FBT
1 A/ACCS
2 BATT
2 C/RCA
2 RMT
2 H/LEG
2 C/WARR
2 C/REG
2 M/SERV
2 BAG(ACCS)
2 BAG(LEG)
2 I/B(SPA)
Description ; Specification
AA03-00326A CRT COLOR;P16LFM00RFA(TU),FREE,0.78MH,7.
AA27-00249A DEFLECTION YOKE;-,DPD-5292AA,S/S,7,29.1
AA33-00016A MAGNET CONVERGENCE;JH 92LT - 29F,-,29.1M
AA39-00018A LEAD CONNECTOR-ASSY;-,YFH800-01,YRH187RH
BP61-00079A HOLDER-DY;,PJTV,T0.5,NYLON66 V2
AA60-00125B SPACER-CRT;PROJ,SILICONE,D/GRAY
AA60-00126B SPACER-CAP;PROJ,EPDM,BLK
AA60-00127B SPACER-LENS;PROJ,SILICONE,D/GRAY
AA60-10011A SCREW-TAPTITE;HH,+,PC,M4,L12,ZPC(BLK),SW
AA61-00056B BRACKET-LENS;-,PROJECTION,SECC,T1.6,-,-,
AA61-00809B HOLDER-CRT;PROJ,PC/ABS GF 20%,BLK
AA61-00810B HOLDER-CAP;PROJ,PC,CLR
AA61-00845A CASE-COUPLER,R;DP,PROJ,AA61-00806B
AA63-00076A SPACER-LENS;FELT ,T1.0,BROWN,7CRT,PROJE
AA91-00722A ASSY-BRKT,CRT;,SECC T1.6,PROJ
AA26-30006F TRANS-FLYBACK;-,FWZ-50A001C,55',30KV
ASSY ACCESSORY
BP92-00533R ASSY ACCESSORY;ST47W3PCX/XAX,P55A
4301-000121 BATTERY-MN;1.5V,-,AAA,10.5X44.
AA39-00006A CABLE-RCA;-,RCA,3000MM,0.12/10,RED/WHT/Y
AA59-00262A REMOCON;,TM63,COMMONDO,48,G6671B,EX,S/S
AA61-20126A HOLDER-LEG;-,-,ABS,HB,BLK,-
AA68-00559C CARD WARRANTY;-,-,W/P150(G),-,138X212,-,
AA68-02967A MARK RECYCLE-CARD REGISTRATION;,8.5X11,
AA68-02879A MANUAL SERVICE;WHT,ALL MEX&TIJ
AA69-01196A BAG PE;CR20805X,LDPE, 93/4X151/2,(ACC
AA69-30009C BAG-SHEET;LDPE,T0.08,W150,L120,-,-,-
BP68-00057B MANUAL USERS;ST47W3PC,SPA,W/P 100G,P55A,
Remark
Samsung Electronics
