Samsung ST55W3PCX/XAX Service Manual page 68

Loc. No. Code No. Description ; Specification
5 C852 2401-003076
5 C856 2401-003076
5 CORE 3301-001201
5 FP801S 3601-000300
5 CN803 3711-003043
5 T432 AA26-00053A TRANS;-,-,-,1.2mH,-,-,-,-,-,-,31.5KHZ,-,
5 T481 AA26-00091A TRANS-HV-STORAGE;4mH,-,14P,830uH,180V,10
5 T444S AA26-00100A TRANS FBT;FFA97513L,CT29A7DR,0.3mH,-,-,-
5 T431 AA26-50001U TRANS-HORIZ.DRIVE;-,-,-,28mH,-,-,105uH,-
5 T461 AA26-50001V TRANS-HORIZ.DRIVE;-,-,-,6.0mH,-,-,113uH,
5 L432 AA27-00056A COIL HORIZ. WIDTH;-,600uH,YL9N 15x27.5 C
5 L862 AA27-10001C COIL CHOKE;-,100uH,K,-,5.0A,ST,700UH-K(R
5 L863 AA27-10001C COIL CHOKE;-,100uH,K,-,5.0A,ST,700UH-K(R
5 L864 AA27-10002L COIL-CHOKE;-,24UH,K,-,2A,-,24U
5 LR401S AA27-30003M COIL LINEARITY;-,5uH,OWA14x15,USRC0.1x60
5 LX801S AA29-30002L FILTER LINE NOISE;-,10mHMIN,5A,AC90~260V
5 LX802S AA29-30002M FILTER LINE NOISE;-,1mHMIN,5A,AC90~260V,
5 LX803S AA29-30002M FILTER LINE NOISE;-,1mHMIN,5A,AC90~260V,
5 LX804S AA29-30002M FILTER LINE NOISE;-,1mHMIN,5A,AC90~260V,
5 CN801 AA39-00180A LEAD CONNECTOR-ASSY;,14P,YBNH250-14,3515
5 GT01 AA60-40012D PIN-GT,ASSY;4P,T1.6,6-12.5-14MM,NYLON66
5 D855 AA96-00243E ASSY H/S;-,SOUND,AA62-00045A,FMG-G26S
5 D856 AA96-00243E ASSY H/S;-,SOUND,AA62-00045A,FMG-G26S
6 0205-000129
6 0402-000231
6 6003-000335
6 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-,
5 Q433 AA96-00243H ASSY H/S;-,POWER,AA62-00045A,KSD73Y,C17A
6 0205-000129
6 0502-000298
6 6003-000335
6 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-,
5 IC831S AA96-00275Q ASSY H/S;,-,AA62-00051A,STR-X6459,K55A
6 0205-001027
6 6003-000333
6 6003-000334
6 AA62-00051A HEAT SINK-PS;-,-,-,SILVER,HOLE 31mm,ALL,
6 AA62-30177A HEAT SINK-PN;-,CUS-1,T1.0,-,KCV12D,-,-,1
6 BP13-00004A IC HYBRID;STR-X6459A,COMMANDO,7,-20 TO +
5 D811S AA96-00276A ASSY H/S;-,BRIDGE,AA62-00052A,RBV606,WA
6 0205-000129
6 0402-000549
6 6003-000335
6 AA60-30003A WASHER;-,-,-,-,T1.5,-,SBHG-1
6 AA62-00052A HEAT SINK-PS;-,-,-,SILVER,HOLE 18.5mm, 2
5 IC421 AA96-00475B ASSY H/S;SILICON-OIL,FMLG-12S(4),AA62-00
6 0205-000129
6 0402-000233
6 1203-000165
6 6003-000334
6 AA62-00066B HEAT SINK;D2,D3,AL ,T1.0,89,70,-,AA62-00
5 IC301 AA96-00623A ASSY H/S;-,POWER,AA62-00056A,LA7845
6 0205-000129
6 1204-000517
6 6003-000334
6 AA62-00056A HEAT SINK-PS;-,-,T1.0,-,41*35*70,D2,-,-,
5 Q431 BH99-00033H ASSY HEAT/SINK;BH62-00038A,SPRING,2SC544
6 0205-001027
6 0402-001296
6 0502-001230
6 BH61-70003A SPRING-PS;SUS304,W1/2H,T0.5,W3.8
6 BH62-00038B HEAT SINK-FBT;COMMANDO,A1050S,T2.0,85*80
6 BH73-00028A SILICON/RUBBER-HS;CDT ALL,SILICON,26*33*
5 TS801S BP26-00001A TRANS-POWER S/W (DPMS);19B012,P55A,HCM42
5 T801S BP26-00006A TRANS SWITCHING;EER5345,P55A,HCM4215W,80
5 CN802 BP39-00014A LEAD CONNECTOR-ASSY;P55A/HCM4215W,UL1007
5 BP39-00091A LEAD CONNECTOR;HCN553W,UL1617#22,UL/CSA,
5 Q473 BP96-00006B ASSY HEAT SINK P;HS,SCREW,IRF640B,2SC412
6 CIS 0205-001027
6 CIS 0502-001100
6 CIS 0505-001722
6 CIS 6003-000333
6 CIS AA60-30001A WASHER-PLATE;-,M3,ID3.5,15X8.5,T1.0,-,SB
6 CIS BP62-00001A HEAT SINK;COMMANDO,A1050P,T2.0,W62.0,H50
5 A/AUTO BP97-00511M ASSY AUTO;0
6 D301 0401-000005
6 D385 0401-000005
Samsung Electronics
C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
CORE-FERRITE;AE,230.5x10.25x36mm,1500,28
FUSE-CARTRIDGE;250V,6.3A,SLOW-BLOW,GLASS
CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH
GREASE-SILICON;SC102,JAPAN
DIODE-RECTIFIER;FMG-G26S,600V,
SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
GREASE-SILICON;SC102,JAPAN
TR-POWER;KSD73,NPN,100V,60V,5A
SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
OIL-SILICON;G746
SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
SCREW-TAPTITE;RH,+,2S,M3,L6,ZP
GREASE-SILICON;SC102,JAPAN
DIODE;RBV-606
SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
GREASE-SILICON;SC102,JAPAN
DIODE-RECTIFIER;FML-G12S,200V,
IC-POSI.ADJUSTREG.;78R12,TO-22
SCREW-TAPTITE;RH,+,2S,M3,L6,ZP
GREASE-SILICON;SC102,JAPAN
IC-LINEAR;LA7845SIPVERTICALAMP
SCREW-TAPTITE;RH,+,2S,M3,L6,ZP
OIL-SILICON;G746
DIODE-RECTIFIER;FMP-3FU,1500V,5A,T0-3PF
TR-POWER;FJL6920YDTU,N,200000MW,TO-264 F
OIL-SILICON;G746
TR-POWER;2SC4125,NPN,70W,TO-3PML,BK,8-
FET-SILICON;IRFS640B,N,200V,18A,0.18OHM,
SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
DIODE;1N4148,100V,300mA,1V,8nS,TAPING
DIODE;1N4148,100V,300mA,1V,8nS,TAPING
Remark Loc. No. Code No.
6 D436
6 D442
6 D443
6 D477
6 D478
6 D479
6 DR401S
6 DR402S
6 DS802
6 DS804
6 D384
6 D435
6 D480
6 D484
6 D501
6 D857
6 DS801
6 D440
6 D441
6 D445
6 D451
6 D433
6 D302
6 D431
6 D472
6 D474
6 D843
6 D453
6 DZ852
6 DZS802
6 DZ831
6 DZ473
6 DZ482S
6 DZ483
6 DZ474
6 DZ804
6 DZ386
6 DZ395
6 DZ413
6 DR404S
6 DZ400
6 DZ851
6 DZ301
6 DZ304
6 DZ481
6 DZS803
6 DZ305
6 DZ307
6 DZ306
6 DZS804
6 DS805
6 Q432
6 Q482
6 QR401S
6 Q301
6 Q381
6 Q382
6 Q401
6 Q402
6 Q421
6 Q451
6 Q461
6 Q471
6 Q474
6 Q481
6 Q851
6 QS801
6 QS802
6 Q422
6 Q472
6 ICR01S
6 VP801S
6 RR409S
6 R416
6 R387
6 R474
6 R308
Description ; Specification
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
0401-000006 DIODE-SWITCHING;BAV21,250MA,400MW,50NS,2
0401-000006 DIODE-SWITCHING;BAV21,250MA,400MW,50NS,2
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41
0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41
0402-000534 DIODE-RECTIFIER;RG10V,400V,1.5
0402-000534 DIODE-RECTIFIER;RG10V,400V,1.5
0402-000534 DIODE-RECTIFIER;RG10V,400V,1.5
0402-000534 DIODE-RECTIFIER;RG10V,400V,1.5
0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A,
0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
0402-001286 DIODE-RECTIFIER;RP1H,2000V,.1A,-,TP
0403-000698 DIODE-ZENER;TZP12A,12V,11.4-12.6V,1W,DO-
0403-000704 DIODEZENER;TZP7.5B,7.5V,7.5-8.
0403-000716 DIODE-ZENER;MTZJ4.7B,4.7V,4.55-4.8V,500m
0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
0403-000734 DIODE-ZENER;TZP15B,15V,14.7-16.5V,1W,DO-
0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500
0403-001316 DIODE-ZENER;MTZJ3.0A,2.85-3.07V,500mW,DO
0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO
0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO
0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D
0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D
0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D
0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D
0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D
0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,
0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,
0403-001330 DIODE-ZENER;MTZJ30A,26.99-28.39V,500mW,D
0403-001330 DIODE-ZENER;MTZJ30A,26.99-28.39V,500mW,D
0404-001056 DIODE-SCHOTTKY;RK16,60V,1.5A,DO-204AC,TP
0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM
0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM
0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
0505-001723 FET-SILICON;FQP630TSTU,N,200V,9A,0.4OHM,
0505-001723 FET-SILICON;FQP630TSTU,N,200V,9A,0.4OHM,
1203-001217 IC-POST,ADJUSTREG;431,T0-92,3P,4.58MIL,P
1405-000152 VARISTOR;560V,2500A,14X8.5MM,T
2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP,
2001-000006 R-CARBON;2.4Kohm,5%,1/8W,AA,TP,1.8x3.2m
2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,
2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,
2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP
Electrical Parts List
Remark
7-11
