Samsung ST55W3PCX/XAX Service Manual page 67

Electrical Parts List
Loc. No. Code No. Description ; Specification
7 R139 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R140 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R141 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R142 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R173 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R174 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R701 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R702 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R710 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R713 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R714 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R725 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R726 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R727 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R731 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R792 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R799 2007-001167 R-CHIP;75ohm,5%,1/16W,DA,TP,1608
7 R606 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
7 R613 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
7 C608 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
7 C614 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
7 C820 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C821 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C824 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C825 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C828 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C829 2203-000181 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
7 C602 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C619 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C634 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C641 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C651 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C657 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C663 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C705 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C707 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C709 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C721 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C722 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C804 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C805 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C807 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C810 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C811 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C814 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C815 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C818 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C833 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C835 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C902 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C904 2203-000206 C-CERAMIC,CHIP;100nF,10%,50V,X7R,TP,2012
7 C114 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C115 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C116 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C117 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C120 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C121 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C126 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C127 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C140 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C141 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C142 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C143 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C145 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C146 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C660 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C661 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608
7 C101 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C105 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C107 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C109 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C110 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C112 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C717 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
7 C653 2203-000332 C-CERAMIC,CHIP;0.012NF,5%,50V,C0G,TP,160
7 C654 2203-000332 C-CERAMIC,CHIP;0.012NF,5%,50V,C0G,TP,160
7 C605 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
7-10
Remark Loc. No. Code No.
7 C606
7 C611
7 C613
7 C655
7 C658
7 C659
7 C635
7 C636
7 C637
7 C638
7 C710
7 C711
7 C712
7 C713
7 C714
7 C715
7 C603
7 C701
7 C702
7 C703
7 C704
7 L125
7 L126
7 L601
7 L602
7 L603
7 L604
7 L701
7 L707
7 L708
7 L901
7 L902
7 L702
7 06VER
4 A/PWR
5
5
5
5
5
5 D464
5 D831
5 DZS801
5 Q423
5 PC801S
5 PC811S
5 IC431
5 IC430
5 IC471
5 ICS802
5 IC851
5 ICS801
5 NT801S
5 VX801S
5 R384
5 CY801S
5 CY802S
5 CY811S
5 CY812S
5 CY803S
5 CY804S
5 CR471S
5 CR430S
5 CR431S
5 CX801S
5 CX802S
5 CR436S
5 C491
5 CR473S
5 C832
5 CR474S
5 C870
5 C815
5 C816
5 C864
5 C863
5 C850
Description ; Specification
2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
2203-001071 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,160
2203-001071 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,160
2203-001071 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,160
2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608
2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608
2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608
2203-001211 C-CERAMIC,CHIP;8.2nF,10%,50V,X7R,TP,1608
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
2203-005590 C-CERAMIC,CHIP;330NF,10%,16V,X7R,TP,2012
2203-005590 C-CERAMIC,CHIP;330NF,10%,16V,X7R,TP,2012
2203-005590 C-CERAMIC,CHIP;330NF,10%,16V,X7R,TP,2012
2203-005590 C-CERAMIC,CHIP;330NF,10%,16V,X7R,TP,2012
2203-005590 C-CERAMIC,CHIP;330NF,10%,16V,X7R,TP,2012
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
3301-001324 CORE-FERRITE BEAD;AB,15OHM,2X1.25X0.9MM,
AA41-00597F PCB-MAIN;HCM4215W,FR-4,2L,F,1.6T,245X245
BP94-00518Q ASSY PCB MISC-PWR-DEF;ST55W3PCX/XAX,P55A
0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE
0202-000008 SOLDER-WIRE;S63S-D3.0,S63A,D3,63/37
0202-000187 SOLDER-WIREFLUX;-,RS60S,D1.2,6
0204-000442 SOLVENT;CH3-CH5H-CH396%IM-1000
0204-001527 FLUX;DF-201TVS,MIX,0.820,FLUX 13%, 14KG
0402-000236 DIODE-RECTIFIER;GI824,400V,5A,-,TP
0402-000250 DIODE-RECTIFIER;RG4C,1000V,1A,
0406-001007 DIODE-TVS;P6KE180A,171/180/189V,600W,CAS
0502-000405 TR-POWER;-,NPN,70W,TO-220,BK,10
0604-001032 PHOTO-COUPLER;TR,170-260%,300M
0604-001032 PHOTO-COUPLER;TR,170-260%,300M
1201-000191 IC;MC4558C
1203-000162 IC-POSI.ADJUST REG.;317,TO-220,3P,-,PLAS
1203-000610 IC-PWMCONTROLLER;494,DIP,16P,300MIL,PLAS
1203-001006 IC-VOLTAGEREGULATOR78R05,TO-220F,4P
1203-001400 IC-POWER PRESCALER;SE110N,T0-220(SIP),3P
1203-002177 IC-PWM CONTROLLER;VIPER12ADIP,DIP,8P,300
1404-001195 THERMISTOR-NTC;5.1ohm,15%,2900,27mW/C,BK
1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
2002-001079 R-COMPOSITION;470Kohm,5%,1/2W,AA,TP,4x10
2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T
2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T
2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T
2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T
2201-000963 C-CERAMIC;CK45Y5U400VACT102-MH
2201-000963 C-CERAMIC;CK45Y5U400VACT102-MH
2301-001091 C-FILM,MPPF;470nF,5%,400V,TP,26x21.5x14.
2301-001343 C-FILM,MPPF;3.9nF,5%,2kV,TP,29x9.5x16mm,
2301-001343 C-FILM,MPPF;3.9nF,5%,2kV,TP,29x9.5x16mm,
2306-000112 C-FILM,MPPF;100NF,20%,250V,-,1
2306-000112 C-FILM,MPPF;100NF,20%,250V,-,1
2306-000235 C-FILM;CF922P400VT564-J-40/85M
2306-000322 C-FILM;CF922P1.6KVT123-JBUP
2306-000322 C-FILM;CF922P1.6KVT123-JBUP
2301-001418 C-FILM,MPPF;1.5nF,5%,2kV,TP,29x7x13.5mm,
2306-000326 C-FILM,MPPF;4.7nF,5%,1.6KV,TP,28.5x16x9m
2401-000142 C-AL;1000UF,20%,16V,WT,10X20MM
2401-000701 C-AL;2200uF,20%,250V,GP,-,35x70mm,1
2401-000701 C-AL;2200uF,20%,250V,GP,-,35x70mm,1
2401-000787 C-AL;220uF,20%,160V,GP,TP,16x31.5mm
2401-002251 C-ELECTROLYTIC;CE04W200V470M(2
2401-003076 C-AL;3300uF,20%,50V,WP,BK,18x35.5mm
Remark
Samsung Electronics
