Alignment and Adjustments
4-2-3 1080i Offset
ITEM
V Amp
V Shift
H EW
H Shift
V Linearity
Upper Linearity
Lower Linearity
VSC
H Parabola
Upper Corner
Lower Corner
H Trapezium
Bow
Angel
V Position
CXA Left Blk
CXA Right Blk
4-4
INITIAL DATA Range
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -15~ 15
0 -15~ 15
0 -15~ 15
0 -15~ 15
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
0 -63 ~ 63
-63 ~ 63
-63 ~ 63
EEP-ROM Copy Data
RF 480P
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
Remark
1080i
0 variable
0 variable
variable
0
0 fix
0
0
0
0
0
0
0
0
0
0
0
63
20
