Samsung ST55W3PCX/XAX Service Manual page 75

Electrical Parts List
Loc. No. Code No. Description ; Specification
5 EL565 6042-000001 EYELET;ID2.2,OD2.7,L3.1,SN,BSS3-E/EH
5 EL566 6042-000001 EYELET;ID2.2,OD2.7,L3.1,SN,BSS3-E/EH
5 EL567 6042-000001 EYELET;ID2.2,OD2.7,L3.1,SN,BSS3-E/EH
5 04VER AA41-00600E PCB-CRT;HCM4215W,FR-1,1L,E,1.6T,245X197(
5 EL03 6042-000002 EYELET;IDI.5,OD2,L3.1,SN,BSS3-E/EH
5 EL06 6042-000002 EYELET;IDI.5,OD2,L3.1,SN,BSS3-E/EH
5 GT371 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT372 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT373 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT374 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT375 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT501 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT502 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT503 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT504 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT506 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT531 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT532 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT533 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT534 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT535 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT536 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT537 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT561 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT562 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT563 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT564 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT567 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
5 GT568 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
4 RPW-SCR BP39-00004B LEAD CONNECTOR-ASSY;P55A/HCM4215W,UL3239
4 GBW-SCR BP39-00004C LEAD CONNECTOR-ASSY;P55A/HCM4215W,UL3239
4 GRW-SCR BP39-00004C LEAD CONNECTOR-ASSY;P55A/HCM4215W,UL3239
4 MODULE BP59-00005A MODULE-FOCUS PACK ASS'Y;PJT TV,F301-P03A
3 A/VM BP94-00346A ASSY PCB MISC-VM;DP,HCM5525J3S/XAA,P55A
4 RZ120 2008-001097 R-FUSIBLE(S);33OHM,5%,1/2W,AC,BK,2.5X6.5
4 CORE 3301-001201 CORE-FERRITE;AE,230.5x10.25x36mm,1500,28
4 C-Y AA33-00017A MAGNET CONVERGENCE;JH 92LT - 29G,-,29.1M
4 CNZ101 AA39-20055F LEAD CONNECTOR-ASSY;,6P,700MM,YBNH250-06
4 QZ102 AA96-00243L ASSY H/S;-,CRT,AA62-00045A,2SC2344,HERC
5 0205-000129 GREASE-SILICON;SC102,JAPAN
5 0502-000153 TR-POWER;2SC2344-D,NPN,180V,16
5 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
5 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-,
4 QZ101 AA96-00243M ASSY H/S;-,AMP,AA62-00045A,2SA1011,HERC
5 0205-000129 GREASE-SILICON;SC102,JAPAN
5 0502-000131 TR-POWER;2SA1011-D,PNP,-180V,-
5 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR
5 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-,
4 A/AUTO AA97-07230M ASSY AUTO-VM;COMMANDO
5 DZ102 0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
5 DZ105 0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
5 DZ106 0401-000005 DIODE;1N4148,100V,300mA,1V,8nS,TAPING
5 DZ101 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
5 DZ103 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
5 DZ104 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.
5 QZ103 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM
5 QZ104 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
5 QZ105 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
5 QZ106 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM
5 RZ122 2001-000019 R-CARBON(S);10ohm,5%,1/2W,AA,TP,2.4x6.4m
5 RZ102 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP
5 RZ109 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP
5 RZ101 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP
5 RZ108 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP
5 RZ117 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
5 RZ118 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
5 RZ107 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,
5 RZ116 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,
5 RZ119 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,
5 RZ121 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1
5 RZ115 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,
5 RZ104 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,
5 RZ110 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,
5 RZ105 2001-001139 R-CARBON(S);39KOHM,5%,1/2W,AA,
5 RZ106 2001-001139 R-CARBON(S);39KOHM,5%,1/2W,AA,
5 RZ114 2003-000458 R-METALOXIDE(S);100OHM,5%,2W,A
5 RZ103 2003-000713 R-METALOXIDE(S);47OHM,5%,2W,AD
7-18
Remark Loc. No. Code No.
5 RZ111
5 RZ112
5 RZ113
5 RZ123
5 RFZ101
5 CZ104
5 CZ106
5 CZ103
5 CZ105
5 CZ110
5 CZ111
5 CZ112
5 CZ102
5 CZ108
5 CZ109
5 CZ107
5 CZ101
5 LZ101
5 CNZ102
5 CNZ103
5 CNZ104
5 JZ101
5 JZ102
5 00VER
3 A/AV
4 SW101
4 CNY702A
4 CNY01A
4 JK101
4 JK102
4 -
4 CNW702A
4 BAND
4 A/JACK
5 HJACK
5 DA/V
5 INLA/V
4 A/AUTO
5 RK101
5 J702
5 J703
5 R707
5 R710
5 01VER
4 CNW01
3 A/SENSOR
4
4
4 TAPE
4
4
4 CN01
4 A/SMD
5
5 Q01
5 R02
5 R03
5 R01
5 PCB
5 D01
2 PWR/AC
3 WPVC
3 PWCORD
3 HOLD
2 D/B
2 BAND-T
2 CWIRE1
2 PCB/CPAC
2 B-T
2 SIL-SPK
2 SIL-CRTR
2 SIL-CRTG
2 SIL-CRTB
Description ; Specification
2003-000713 R-METALOXIDE(S);47OHM,5%,2W,AD
2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM
2008-001086 R-FUSIBLE(S);3.3ohm,5%,2W,AG,TP,3.9x12mm
2201-000193 C-CERAMIC,DISC;10PF,0.25PF,50V
2201-000193 C-CERAMIC,DISC;10PF,0.25PF,50V
2201-000516 C-CERAMIC,DISC;4.7NF,+100-0%,5
2201-000516 C-CERAMIC,DISC;4.7NF,+100-0%,5
2201-000604 C-CERAMIC,DISC;56PF,+100-0%,50
2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
2401-000832 C-AL;220UF,20%,25V,GP,8X11MM,5
2401-001157 C-ELECTROLYTIC;CE04WTAPG160V33
2401-001220 C-AL;4.7uF,20%,160V,GP,TP,8x11.5,5
2401-001220 C-AL;4.7uF,20%,160V,GP,TP,8x11.5,5
2401-001513 C-AL;47UF,20%,16V,WT,5X11MM,5M
2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
2701-000002 INDUCTOR-AXIAL;100UH,10%,4.2X9
3711-002642 POST-HEADER;67094-003(AUTO)
3711-002642 POST-HEADER;67094-003(AUTO)
3711-002642 POST-HEADER;67094-003(AUTO)
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
AA41-00611A PCB-VM;HCM4215W,FR-1,1L,A,1.6T,245X245,P
BP94-00518D ASSY PCB MISC-A/V FRONT;DP,HCN553W,P55A,
3404-000208 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST
3711-000447 CONNECTOR-HEADER;BOX,3P,1R,2.5MM,ANGLE,-
3711-003601 CONNECTOR-HEADER;BOX,12P,1R,2.5mm,ANGLE,
3722-000544 JACK-VHS;4P,11.5mm,AG,BLK,N
3722-001164 JACK-PIN;3P,3.4mm,SN,WH:YE:RE,#16-22
6003-001023 SCREW-TAPTITERWH,+,B,M3,L10,ZPC(YEL)
AA39-00260B LEAD CONNECTOR-ASSY;,UL1007#26,UL/CSA,3P
AA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,-
AA91-00762R ASSY-JACK SIDE;W3,SVM1132,P55A,XAC
AA61-00793F HOLDER-JACK;ABS,HB,47W3,WHT,,,SVM1132,
AA64-02085G DOOR-AV;W3,ABS,HB,WHT,SVM1132
AA64-02086F INLAY-AV;W3,PS SHEET,T0.5,P54A XAC
AA97-07429A ASSY AUTO-A/V FRONT;HCM4215WX/XAA,P55A
2001-000006 R-CARBON;2.4Kohm,5%,1/8W,AA,TP,1.8x3.2m
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
3812-000219 JUMPER-WIRE-SO,COPPER;TA0.6SN/52M/M(A
AA41-00499B PCB-FRONT A/V;SVP-54T6SR,FR-1,1L,A,1.6T,
BP39-00016B LEAD CONNECTOR;HCL4715WB,UL2547#26,UL/CS
BP95-00147D ASSY SUB PCB-SENSOR;DP,P54A,SENSOR
0202-000008 SOLDER-WIRE;S63S-D3.0,S63A,D3,63/37
0202-000187 SOLDER-WIREFLUX;-,RS60S,D1.2,6
0203-001269 TAPE-OPP MASKING;#301,T0.06,W75,L50000,N
0204-000442 SOLVENT;CH3-CH5H-CH396%IM-1000
0204-001527 FLUX;DF-201TVS,MIX,0.820,FLUX 13%, 14KG
3711-000447 CONNECTOR-HEADER;BOX,3P,1R,2.5MM,ANGLE,-
BP97-00208A ASSY SMD;0
0202-001167 SOLDER-CREAM;RX3603-2330HO,S45A,PASTE,SN
0501-000342 TR-SMALLSIGNAL;KSC1623-Y,NPN,200mW,SOT-
2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
2007-000305 R-CHIP;10Mohm,5%,1/10W,TP,1608
AA41-00853A PCB-SERSOR;SVP-42W5HRC,FR-4,2L,A,1.6T,24
BP32-00001A SENSOR PHOTO;BCS5030G1,-40 TO +85,0.42 U
AA96-20112C ASSY-POWER,CORD;-,EP2/NO,H/C250,KJ10,THA
3811-000401 WIRE-VINYLU/C;1007-10#22(S)-BLK
AA39-10006K POWER-CORD;KJ-10W,AWG SPT-2
AA61-20284A HOLDER P CORD;PP,VO,BLK,KE-002
AA26-00101A TRANS FBT;FWZ50A001E,-,-,-,-,-,-,-,-,-,-
AA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,-
AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL
AA65-30104B CLAMP WIRE; NYLON 66, V2,BLK, W2 Z5
AA63-10002B BAND-TIE;-,NYLON66V2,-,-,L140,NTR,-,-
0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE
0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE
0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE
0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE
Remark
Samsung Electronics
