Electrical Parts List
Loc. No.
Code No.
Description ; Specification
7 D08
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D09
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D10
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D11
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D12
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D13
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D14
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D15
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D16
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D17
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 D18
0401-000160
DIODE-SWITCHING;ISS314,30V,100mA,USC,TP
7 DZ01
0403-001016
DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
7 DZ02
0403-001016
DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
7 DZ03
0403-001016
DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
7 Q02
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23
7 Q03
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23
7 Q04
0501-000342
TR-SMALLSIGNAL;KSC1623-Y,NPN,200mW,SOT-
7 Q10
0501-000342
TR-SMALLSIGNAL;KSC1623-Y,NPN,200mW,SOT-
7 Q07
0505-000110
FET-SILICON;2N7002,N,60V,115MA,7.5OHM,0.
7 Q08
0505-000110
FET-SILICON;2N7002,N,60V,115MA,7.5OHM,0.
7 Q09
0505-000110
FET-SILICON;2N7002,N,60V,115MA,7.5OHM,0.
7 IC04
0801-002345
IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,4
7 IC15
0801-002345
IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,4
7 IC16
0801-002345
IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,4
7 IC08
1001-000164
IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16
7 IC13
1001-001155
IC-ANALOG MULTIPLEX;NC7SB3157P6X,CMOS,SC
7 IC05
1103-001195
IC-EEPROM;24C64,8Kx8Bit,SOP,8P,150MIL,10
7 IC12
1201-001135
IC-OP AMP;324,SOP,ST,14P,150MIL,QUAD,100
7 IC09
1201-001504
IC-OP AMP;072,SOP,8P,150MIL,DUAL,-,PLAST
7 IC10
1201-001504
IC-OP AMP;072,SOP,8P,150MIL,DUAL,-,PLAST
7 IC11
1201-001504
IC-OP AMP;072,SOP,8P,150MIL,DUAL,-,PLAST
7 IC14
1201-001504
IC-OP AMP;072,SOP,8P,150MIL,DUAL,-,PLAST
7 IC07
1201-001520
IC-VIDEO AMP;EL2250CS,SOIC,8P,150MIL,DUA
7 IC03
1203-001824
IC-VOL. DETECTOR;7042,SOT-89,3P,-,PLASTI
7 IC02
1203-002302
IC-POSI.FIXED REG.;78RM33D,D-PAK,3P,-,PL
7 IC17
1209-001163
IC-PLL;TLC2932IPWLE,SOP,14P,-,PLASTIC
7 R30
2007-000028
R-CHIP;39OHM,5%,1/10W,DA,TP,2012
7 R31
2007-000028
R-CHIP;39OHM,5%,1/10W,DA,TP,2012
7 R35
2007-000028
R-CHIP;39OHM,5%,1/10W,DA,TP,2012
7 R36
2007-000028
R-CHIP;39OHM,5%,1/10W,DA,TP,2012
7 R122
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R123
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R141
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R143
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R144
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R25
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
7 R09
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R10
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R129
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R134
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R135
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R136
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R15
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R24
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R45
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R46
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
7 R02
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R16
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R17
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R20
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R47
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R53
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R59
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R65
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R71
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R77
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R91
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
7 R03
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R101
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R11
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R110
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R37
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R38
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R39
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R40
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R41
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7 R42
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
7-6
Remark
Loc. No.
Code No.
7 R43
7 R44
7 R50
7 R52
7 R56
7 R58
7 R62
7 R64
7 R68
7 R70
7 R74
7 R76
7 R80
7 R82
7 R94
7 R98
7 R128
7 R51
7 R57
7 R63
7 R69
7 R75
7 R81
7 R109
7 R01
7 R04
7 R06
7 R07
7 R08
7 R118
7 R119
7 R121
7 R133
7 R48
7 R49
7 R54
7 R55
7 R60
7 R61
7 R66
7 R67
7 R72
7 R73
7 R78
7 R79
7 R113
7 R114
7 R115
7 R83
7 R84
7 R85
7 R86
7 R92
7 R93
7 R96
7 R97
7 R125
7 R05
7 R127
7 R100
7 R32
7 R107
7 R117
7 R28
7 R29
7 R34
7 R120
7 R33
7 R87
7 R88
7 R89
7 R90
7 R108
7 R137
7 R138
7 R139
7 R95
Description ; Specification
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000078
R-CHIP;1Kohm,5%,1/10W,TP,1608
2007-000079
R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000080
R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
2007-000082
R-CHIP;3.3Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000084
R-CHIP;4.7Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
2007-000091
R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
2007-000102
R-CHIP;100Kohm,5%,1/10W,TP,1608
2007-000109
R-CHIP;1Mohm,5%,1/10W,TP,1608
2007-000118
R-CHIP;390ohm,5%,1/16W,DA,TP,1608
2007-000119
R-CHIP;560ohm,5%,1/16W,DA,TP,1608
2007-000122
R-CHIP;1.2Kohm,5%,1/10W,TP,1608
2007-000122
R-CHIP;1.2Kohm,5%,1/10W,TP,1608
2007-000122
R-CHIP;1.2Kohm,5%,1/10W,TP,1608
2007-000122
R-CHIP;1.2Kohm,5%,1/10W,TP,1608
2007-000122
R-CHIP;1.2Kohm,5%,1/10W,TP,1608
2007-000124
R-CHIP;2.2Kohm,5%,1/10W,TP,1608
2007-000124
R-CHIP;2.2Kohm,5%,1/10W,TP,1608
2007-000133
R-CHIP;330Kohm,5%,1/10W,TP,1608
2007-000133
R-CHIP;330Kohm,5%,1/10W,TP,1608
2007-000133
R-CHIP;330Kohm,5%,1/10W,TP,1608
2007-000133
R-CHIP;330Kohm,5%,1/10W,TP,1608
2007-000381
R-CHIP;13Kohm,5%,1/16W,DA,TP,1608
2007-000402
R-CHIP;150ohm,5%,1/10W,TP,1608
2007-000402
R-CHIP;150ohm,5%,1/10W,TP,1608
2007-000402
R-CHIP;150ohm,5%,1/10W,TP,1608
2007-000704
R-CHIP;3.6Kohm,5%,1/16W,DA,TP,1608
Remark
Samsung Electronics
